Image preview - the first page of the document



>> Download vp2106 documenatation <<

Text preview - extract from the document

                                                                                                                                                  VP2106

                                                      P-Channel Enhancement-Mode
                                                      Vertical DMOS FET
Features                                                                                    General Description
       Free from secondary breakdown                                                        The Supertex VP2106 is an enhancement-mode (normally-
       Low power drive requirement                                                          off) transistor that utilizes a vertical DMOS structure
       Ease of paralleling                                                                  and Supertex's well-proven silicon-gate manufacturing
       Low CISS and fast switching speeds                                                   process. This combination produces a device with the
       High input impedance and high gain                                                   power handling capabilities of bipolar transistors, and the
                                                                                            high input impedance and positive temperature coefficient
       Excellent thermal stability
                                                                                            inherent in MOS devices. Characteristic of all MOS
       Integral source-to-drain diode
                                                                                            structures, this device is free from thermal runaway and
Applications                                                                                thermally-induced secondary breakdown.

       Motor controls                                                                       Supertex's vertical DMOS FETs are ideally suited to a
       Converters                                                                           wide range of switching and amplifying applications where
       Amplifiers                                                                           very low threshold voltage, high breakdown voltage, high
       Switches                                                                             input impedance, low input capacitance, and fast switching
       Power supply circuits                                                                speeds are desired.
       Drivers (relays, hammers, solenoids, lamps,
       memories, displays, bipolar transistors, etc.)



Ordering Information
                                             Package Option                                                              RDS(ON)                      ID(ON)
                                                                                           BVDSS/BVDGS
           Device                                                                                                         (max)                       (min)
                                                     TO-92                                       (V)
                                                                                                                           ()                         (mA)
          VP2106                                VP2106N3-G                                      -60                         12                        -500
-G indicates package is RoHS compliant (`Green')



                                                                                          Pin Configuration


                                                                                                                                  DRAIN


                                                                                                                        SOURCE


Absolute Maximum Ratings
                                                                                                                                      GATE
    Parameter                                                               Value                                       TO-92 (N3)
    Drain-to-source voltage                                                 BVDSS
    Drain-to-gate voltage                                                   BVDGS         Product Marking
    Gate-to-source voltage
