Image preview - the first page of the document



>> Download 2sb1694 documenatation <<

Text preview - extract from the document

                                                                                                                                                          2SB1694
Transistors


General purpose amplification (-30V, -1A)
2SB1694

 Application                                                        Dimensions (Units : mm)
Low frequency amplifier
Driver




                                                                                                                          (1)

                                                                                                                                 0.65 0.65


                                                                                                                                                   2.0
                                                                                                                                             1.3
                                                                                                                          (2)
                                                                                                         (3)
                                                                                       0.3
                                                                                                                1.25
  Features                                                                                                        2.1

1) A collector current is large.




                                                                                                                           0.2
                                                                                        0.15
2) Collector saturation voltage is low.




                                                                                                                                             0.9
                                                                                                                                 0.7
   VCE(sat)  -380mV




                                                                                                               0~0.1
                                                                                               0.1Min.

   At IC = -500mA / IB = -25mA                                                                                          Each lead has same dimensions

                                                                         ROHM : UMT3     Abbreviated symbol : ES                                         (1) Emitter
                                                                         EIAJ : SC-70                                                                    (2) Base
                                                                         JEDEC : SOT-323                                                                 (3) Collector




 Absolute maximum ratings (Ta=25
