Image preview - the first page of the document



>> Download dtc115gua-gka documenatation <<

Text preview - extract from the document

                                                                                                          DTC115GUA / DTC115GKA
Transistors

100mA / 50V Digital transistors
(with built-in resistor)
DTC115GUA / DTC115GKA
  Applications                                                                          External dimensions (Unit : mm)
Inverter, Interface, Driver
                                                                                        DTC115GUA
                                                                                                                 2.0                              0.9

  Features                                                                                                                 0.3             0.2     0.7

1) The built-in bias resistors consist of thin-film                                                            (3)

   resistors with complete isolation to allow negative




                                                                                                                                    1.25

                                                                                                                                           2.1
   biasing of the input, and parasitic effects are almost                                                       (2)          (1)

   completely eliminated.




                                                                                                                                                                0.1Min.
                                                                                                           0.65 0.65                                                      (1) Emitter
2) Only the on / off conditions need to be set for                                                                                               0.15                     (2) Base
                                                                                        ROHM : UMT3              1.3                                                      (3) Collector
   operation, making the device design easy.                                            EIAJ : SC-70                                                    Each lead has same dimensions
                                                                                                                      Abbreviated symbol : K29
3) Higher mounting densities can be achieved.
                                                                                        DTC115GKA
                                                                                                                     2.9                           1.1
  Structure
                                                                                                                           0.4                     0.8
NPN epitaxial planar silicon transistor
(Resistor built-in type)                                                                                   (3)

                                                                                                                                      2.8
                                                                                                                                      1.6




 Packaging specifications                                                                                  (2)                     (1)



                                                                                                                                                                0.3Min.
                                                                                                           0.95 0.95
                Package                          UMT3                SMT3                                                                        0.15                     (1) Emitter
                Packaging type                   Taping              Taping                                      1.9                                                      (2) Base
                                                                                        ROHM : SMT3                                                                       (3) Collector
                Code                                T106              T146              EIAJ : SC-59                                                    Each lead has same dimensions
                                                                                                                      Abbreviated symbol : K29
Part No.        Basic ordering unit (pieces)        3000              3000
DTC115GUA                                                                 -
DTC115GKA                                             -


 Absolute maximum ratings (Ta=25
