Image preview - the first page of the document
![LH NOVA-Fenghua [radial thru-hole] LZ Series](/pics/5c2dcd1a5a42d.gif)
>> Download LH NOVA-Fenghua [radial thru-hole] LZ Series documenatation <<
Text preview - extract from the document
LZ FEATURE
: 105 5000
Life time:105 5000 hours ( D 12.5)
Ultra low impedance
For switching power supplies and other industrial
electronic products applications
SPECIFICATIONS
Item Performance Characteristics
6.3V.DC 50V.DC
Rated Voltage Range
-40 +105
Operating Temperature Range
33 F 6800 F
Nominal Capacitance Range
Capacitance Tolerance 20%(M,+20 ,120Hz)
2 I 0.01CV 3 A( )20
After application of rated voltage for 2 minutes: I 0.01CV or 3 A(Whichever is greater)20
Leakage Current C: ( F) C: Nominal Capacitance in F;
V: (V) V: Rated Working Voltage in V
(V) Rated Working Voltage 6.3 10 16 25 35 50
(tan ) tan (MAX) (20 ,120Hz) 0.18 0.16 0.14 0.12 0.12 0.10
Dissipation Factor
1000 F 1000 F 0.02
When capacitance is over 1000 F, tan shall be added 0.02 with increase of every 1000 F
(V)
6.3~50
Rated Working Voltage
Temperature Stability (Z-25 /z+20 ) 2
Impedance Ratio(120Hz) (Z-40 /z+20 ) 3
+105 :
After applying rated voltage at +105 , Capacitors meet the characteristics
requirements measured at +20 listed below;
25% (hrs)
Load Life Capacitance Change Case Dia Life Time
Within 25% of the initial measured value
D 6.3 2000
Leakage current Less than the initial specified value
D=8.10 3000
200%
Tan Less than 200% the initial specified value D 12.5 5000
+105 1000
After application of rated working voltage and maximum permissible ripple current specified at +105
Shelf Life for 1000 hours , Capacitors meet the characteristics requirements measured at +20 listed below:
MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Freq(Hz) 50(60) 100(120) 1K 10K 100K
Cap( F)
5.6~33 0.30 0.40 0.70 0.90 1.00
39~270 0.35 0.50 0.73 0.92 1.00
330~680 0.40 0.55 0.77 0.94 1.00
820~1800 0.45 0.60 0.80 0.96 1.00
2200~6800 0.50 0.70 0.85 0.98 1.00
Case Size D L(mm)
56
ALUMINUM ELECTROLYTIC CAPACITOR(CD288 LZ)
CASE SIZE TABLE
0.5 1.0
D 5 6.3 8 10 12.5 16 18
F 0.5 2.0 2.5 3.5 5 7.5
d 0.1 0.5 0.6 0.8
L 16 1.5 L 16 2.0
LZ
DIMENSIONS, RATED VOLTAGE AND CAPACITANCE
WV(V) 6.3(LA) 10(LB) 16(LC) 25(LD) 35(LE)
Cap
( F) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3) (1) (2) (3)
22(220)
33(330) 5X11 250 0.30
47(470) 5X11 250 0.30 5X11 250 0.30 6.3X11 405 0.13
100(101) 5X11 250 0.30 6.3X11 270 0.23 6.3X11 405 0.13 8X12 600 0.11
120(121) 6.3X11 405 0.13
150(151) 5X11 250 0.30 6.3X11 270 0.23 6.3X11 405 0.13 8X12 600 0.11 8X12 760 0.072
180(181)
220(221) 6.3X11 270 0.23 6.3X11 405 0.13 8X12 600 0.11 8X12 760 0.072 10X12 1030 0.053
270(271) 8X20 1250 0.041
330(331) 6.3X11 405 0.13 8X12 600 0.11 8X12 760 0.072 10X12 1030 0.053 10X16 1430 0.038
470(471) 8X12 600 0.11 8X12 760 0.072 10X12 1030 0.053 10X16 1430 0.038 10X20 1820 0.023
560(561) 8X12 760 0.072 10X12 850 0.065 10X16 1200 0.045 10X16 1500 0.027 10X20 2150 0.022
680(681) 10X12 850 0.065 10X12 1030 0.053 10X16 1430 0.038 10X20 1820 0.023 12.5X20 2360 0.021
820(821) 8X16 955 0.056 10X20 2150 0.022
1000(102) 10X12 1030 0.053 10X16 1430 0.038 10X20 1820 0.023 12.5X20 2360 0.021 12.5X25 2770 0.018
1200(122) 8X20 1250 0.041 10X20 1820 0.023 10X20 2150 0.022 12.5X30 3290 0.016
1500(152) 10X20 1820 0.023 10X20 2150 0.022 12.5X20 2360 0.021 12.5X25 2770 0.018 12.5X35 3400 0.015
1800(182) 12.5X30 3290 0.016 16X25 3460 0.016
2200(222) 10X20 2150 0.022 12.5X20 2150 0.021 12.5X25 2770 0.018 12.5X35 3400 0.015
2700(272) 12.5X30 3290 0.016 16X25 3460 0.016
3300(332) 12.5X20 2360 0.021 12.5X25 2770 0.018 12.5X35 3400 0.015
3900(392) 12.5X25 2770 0.018 12.5X25 3290 0.016 16X25 3460 0.016
4700(472) 12.5X30 3290 0.016 12.5X30 3400 0.015
5600(562) 16X20 3140 0.018 16X25 3460 0.016
6800(682) 16X25 3460 0.016
WV(V) 50(LF) WV(V) 63(LG) 100(MA)
Cap Cap( F)
( F) (1) (2) (3) (1) (2) (3) (1) (2) (3)
22(220) 5X11 238 0.34 22(220)
33(330) 6.3X11 265 0.35
33(330) 6.3X11 270 0.23
47(470) 8X12 270 0.23 10X12 288 0.43
47(470) 6.3X11 385 0.14
68(680) 8X16 490 0.21 10X16 357 0.31
100(101) 8X12 724 0.074 100(101) 10X16 650 0.17 10X20 520 0.22
120(121) 8X16 950 0.061 120(121) 8X20 820 0.12
150(151) 10X12 979 0.061 150(151) 10X16 945 0.11 12.5X25 650 0.14
180(181) 8X20 1190 0.046 180(181) 10X20 1100 0.080
220(221) 10X20 520 0.23 16X20 1040 0.091
220(221) 10X16 1370 0.042
270(271)
270(271) 10X20 1580 0.030
330(331) 12.5X25 784 0.12 18X20 1240 0.080
330(331) 10X20 1870 0.028
390(391)
470(471) 12.5X20 2050 0.027 470(471) 16X20 905 0.091 18X30 1630 0.047
560(561) 12.5X25 2410 0.023 560(561)
680(681) 12.5X30 2860 0.021 680(681) 18X20 1180 0.071 18X35 1790 0.040
820(821) 12.5X35 2960 0.019 820(821)
1000(102) 16X25 3010 0.021 1000(102) 18X30 1630 0.047
100KHz Impedance ( at +20 ,100KHz)
Max allowable ripple current (mA r.m.s./105 ,100KHz)
Case Size D L(mm)
57
