Image preview - the first page of the document



>> Download Samyoung [radial thru-hole] NLA Series documenatation <<

Text preview - extract from the document

                                                         MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS


    NLA Series              105 4,000~10,000Hrs assured.                           Solvent-
                                                                                    proof
    Low impedance.
    Long Life.
    For SMPS, IP-Board, Adaptor
                                                             LXA                    NLA
    RoHS compliant.
    Halogen-free capacitors are also available.                      Low Imp.
                                                                     Long life


SPECIFICATIONS
              ltem                                                                Characteristics

      Rated Voltage Range                                                         6.3 ~ 50 VDC
  Operating Temperature Range                                                     -55 ~ +105
     Capacitance Tolerance
