                                                                  LARGE SIZED ALUMINUM ELECTROLYTIC CAPACITORS


        RLS Series                 8 5  3 , 0 0 0 H r s a s s u r e d .
      Non-solvent proof.
      Downsized of RDA series.
      For SMPS, Inverter                                              RDC                        RLS
      RoHS compliant.                                                             Long Life
      Halogen-free capacitors are also available.


SPECIFICATIONS
                    ltem                                                                      Characteristics

      Rated Voltage Range                                                                 160  450 VDC
  Operating Temperature Range                                                                 -25  +85
      Capacitance Tolerance
