                                                                 LARGE SIZED ALUMINUM ELECTROLYTIC CAPACITORS


       TLA Series                        105 3,000Hrs assured.
     Non-solvent proof.
     Long Life.                                                           TDA
     Equal to TDA case size                                                                    TLA
     For SMPS, Inverter                                                           Long Life.
     RoHS compliant.
     Halogen-free capacitors are also available.



SPECIFICATIONS
             Item                                                                   Characteristics
   Rated Voltage Range                                                              1 6 0 ~ 5 0 0 VDC
  Operating Temperature Range                                                        -25 ~ +105
   Capacitance Tolerance
