Image preview - the first page of the document



>> Download AOD452 - N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document

  AOD452
  N-Channel Enhancement Mode Field Effect Transistor

 General Description                                             Features

 The AOD452 uses advanced trench technology and                  VDS (V) =25V
 design to provide excellent RDS(ON) with low gate               ID = 55 A (VGS = 10V)
 charge. This device is suitable for use in PWM, load
 switching and general purpose applications.                     RDS(ON) < 8.5 m (VGS = 10V)
 Standard product AOD452 is Pb-free (meets ROHS &                RDS(ON) < 14 m (VGS = 4.5V)
 Sony 259 specifications). AOD452L is a Green
 Product ordering option. AOD452 and AOD452L are
 electrically identical.

                            TO-252
                            D-PAK
                                                                                      D


                                          Top View
                                          Drain Connected to
                                          Tab
                                                                            G
                                                                                      S


                        G     D       S

Absolute Maximum Ratings TA=25
