Image preview - the first page of the document



>> Download AO4466 - N-Channel Enhancement Mode Field Effect Transistor documenatation <<

Text preview - extract from the document

  AO4466
  N-Channel Enhancement Mode Field Effect Transistor


 General Description                                        Features

 The AO4466 uses advanced trench technology to              VDS (V) = 30V
 provide excellent RDS(ON) and low gate charge. This        ID = 9.4A        (V GS = 10V)
 device is suitable for use as a load switch or in PWM      RDS(ON) < 23m     (VGS = 10V)
 applications. The source leads are separated to allow      RDS(ON) < 35m     (VGS = 4.5V)
 a Kelvin connection to the source, which may be
 used to bypass the source inductance. Standard
 Product AO4466 is Pb-free (meets ROHS & Sony
 259 specifications). AO4466L is a Green Product
 ordering option. AO4466 and AO4466L are
 electrically identical.



                                                                                          D
                    S                D
                    S                D
                    S                D
                    G                D
                                                                                G
                           SOIC-8                                                         S



Absolute Maximum Ratings TA=25
