Image preview - the first page of the document
>> Download 1437_2137_1420_2130_2170F_TC1631TV documenatation <<
Text preview - extract from the document
CAMERON 1437, CAMERON 2137, ELENBERG 1420, ELENBERG 2130, ELENBERG 2170F
TRANSONIC
SERVICE MANUAL
TC1631TV
1. Caution.....................................................................2
2. Specification...............................................................6
3. BOM List ........................... .........................................13
4. Alignment Procedure....................................................33
5. Block Diagram............................................................40
6. Schematic Diagram......................................................41
7. PCB Layout................................................................42
8. Explode View Diagram...................................................43
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CA UTION: TO REDUCE THE RISK OF
CAUTION ELECTRICAL SHOCK, DO NOT REMOVE
RISK OF ELECTRIC
ELECTRIC COVER (OR BACK). NO USER SERVICEABLE
SHOCK DO NOT OPEN. PARTS INSIDE. REFER SER VICING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated dangerous voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION:
Read all of these instructions. Save these instructions for later use. Follow all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions- All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
FOR YOUR PERSONAL SAFETY
1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
3
PROTECTION AND LOCATION OF YOUR SET
11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in a built-in enclosure, unless proper ventilation is provided.
PROTECTION AND LOCATION OF YOUR SET
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
ANTENNA
LEAD- IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
ELECTRIC SERVICE (NEC SECTION 810-21)
EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING
NEC-NATIONAL ELECTRICAL CODE ELECTRODE SYSTEM
(NEC ART 250. PART H)
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system installer s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
4
OPERATION OF YOUR SET
18. This television set should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set off and unplug the television set from the wall outlet.
IF THE SET DOES NOT OPERATE PROPERLY
21. If you are unable to restore normal operation by following the detailed procedure in your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
FOR SERVICE AND MODIFICATION
24. Do not use attachments not recommended by the television set manufacturer as they may cause hazards.
25. When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
5
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
MasterData
Customer Id ORIENTAL PACIFIC (NZ) LIMITED
Version 0.1
BOM No 03-E2764H-AA36
Brand TRANSONIC
Reception
-Tuning - presets/channels
100 x
125
200
-Tuning - technology
PLL x
VST x
-Tuning - Indication
--- X
-Freq Bands
UVSH
Full-Cable x
-IF Freq
38MHz
38.9MHz X
45.75MHz
-TV Systems Off Air/Cable
NTSC M (3.58 - 4.5)
NTSC (4.43 - 5.5)
NTSC (4.43 - 6.5)
NTSC 3.58 x
NTSC 4.43 x
PAL B/G x
PAL D/K
PAL I
SECAM B/G
SECAM D/K
-Add Systems Ext In
NTSC 3.58
NTSC 4.43
NTSC Play Back x
PAL 60 x
-TV Systems Multi
NTSC
PAL x
-Sound Systems
AV Stereo x
NICAM
German Stereo
American Stereo
Korean Stereo
Picture - Processing
-Scan
Standard x
-Scan Modes
4:3 x
4:3 Expand
-Wide Screen Switching
-Combfilter
-Picture Control
Brightness x
Colour/Hue/ tint x
Contrast x
Color Temperature
Sharpness x
scan velocity modulation
LTI / CTI
Smart Pict. 4 Modes
Smart Pict. 5 Modes
Multiplicate picture scan mode
-Pict Enhancement
Active Control (without LNA)
Black Stretch x
dynamic skin
-Pict Noise Reduction
NR x
Page 1
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
Picture - Display
-Display Type
DV - CRT - Normal Flat x
DV-CRT-Pure Flat
DV - CRT - Super Flat
-Screen Format
4:3 x
Expand 4:3
16:9
-Size(Visual)" - size/vis. cm
14(13V) - 37/34 cm x
21(20V) - 55/51cm
25(00v) - 00/00cm
29(27v) - 72/68cm
34(00v) - 00/00cm
-Deflection System (CRT only)
1 Fh x
2 Fh
-Tube Technology (CRT only)
Iron x
Black Matrix x
Real Flat
-CRT Defl
090 degr x
100 degr
110 degr
500 degr
-CRT Gun
Stand Gun x
-CRT Magn field
Neutral
S Hemisphere Australia South Hemisphere
North-Neutral
-Resolution
-Coating (only for D.V. sets)
-White Point
Sound
-Leaflet Power
01W
02W
04W x
06W
10W
12W
20W
-RMS Power Intern
1x1W
2x1W
2x2W 14"
2x3W
2x4W
2x5W
2X6W
2X10W
-RMS Power Extern
-Surround Sound
-Sound Features
AVL
Mute x
Smart Sound (4 modes)
-Sound Control
Balance
Bass
Bass Boost
Smart Sound 4 Modes
Smart Sound 5 Modes
Treble
Treble Boost
Volume x
Sound - Speakers
-Speaker configuration
2x1 x
Page 2
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
-Speakers used
Normal Range x
Full Range
User Interface
-Interface Name
Full interface A30V03-TOP
-Voice Control
-Menu
Cursor Control X
-Menu Colours
-Menu Languages
Arabic
Chinese - Simplified
Chinese - Traditional
English X
Russian
Malay
Thai
-Record Select - sources:
-Special Features
On/Off Timer x
Sleep timer x
Game x
Notebook x
Calendar x
Auto Standby x
Channel Copying x
Channel Naming
Channel Lock
Favorite Channel x
Manual Skip
channel navigation
Personal Zapping
Signal Strength Indicator
V-chip with Smart Lock
Hotel Mode x
Recall
AT
High Sensitive
-Operational Features
Alternate Channel
Surf
-PP Features
One PP for all channels x
-Tuning / Install Features
Aut Cable/Ant. Select x
Auto Channel Prog x
Auto Store x
Factory Mode x
Fine Tuning x
Language Selection x
Manual Search/Store x
Service Mode x
-Clock/Timer Functions
Sleep timer x
Alarm Timer
Crystal Clock
Real Clock
Biological Clock x
-Local Controls Front
Channel +-
Mains Switch (Flush)
Volume +-
TV/AV
Auto search
menu
-Local Controls Top
Channel +- x
Volume +- x
TV/AV x
menu x
-Indicators - screen
Page 3
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
-Indicators - front
RC Recvd LED x
SB LED x
-Numb of Loc Cont (incl Mains)
5
7 x
-Number of Ind. (incl Mains)
1
-Local Controls (Old)
Remote Control
-Remote Control - scope
TV x
-Remote Control - type
Standard x
-Remote Control - typenr
E
F x
Q
RC115
-Remote Control - features
Connectors Rear
-Scart RGB+Y/C+CVBS
-Scart RGB+CVBS
-Scart CVBS+Y/C
-Component In (Y/U/V) Cinch
Ext(1) x
-Component In (YPbPr) Cinch
-In Y/C+Cinch(CVBS+St)
1x X
-In Y/C+Cinch(CVBS+Mo)
-In Y/C+Cinch(St)
-In BNC (CVBS)
-In Cinch(CVBS+Mo)
Ext(1)
-In Cinch(CVBS+St)
Ext2
-In VGA
-Out Y/C+Cinch(CVBS+St)
-Out Cinch(CVBS+St)
1x X
-Out Cinch(CVBS+Mo)
1x
-Out Cinch Audio Stereo
-Out Cinch Audio Mono
-Out Cinch Dolby Surround
-Out Cinch Subwoofer
-Dig Audio Out
-Loudspeakers
-Control Busses
-Feature Slot
-ITV Smart Port
-Terr. Antenna in
75 Ohms (IEC type) x
Guide + IR Blaster Jack
Connectors Front
-In Y/C + Cinch(CVBS+St)
-In Y/C + Cinch(CVBS+Mo)
-In Y/C + Cinch Stereo
-In Cinch (CVBS + St)
-In Cinch (CVBS+Mo)
Yes
-Headphone Out
Mini-Jack 3.5mm
-Feature Slot
-Cinch A/V in
Connectors Side
-In Y/C + Cinch(CVBS+St)
-In Y/C + Cinch Stereo
-In Cinch (CVBS + St)
Yes x
-In Cinch (CVBS + Mo)
Yes
Page 4
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
-Headphone Out
Mini-Jack 3.5mm
-Cinch A/V in
-Cinch A/V out
Connectors Top
-In Cinch (CVBS + St)
-Headphone Out
Connectors Mechanical
-Headphone
-Cinch A/V in/out
-Cinch Component
-Cinch Y/C
Styling
-Cabinet Name 14276
-Configuration
DAS
Symm x
-Mechanics
-Speaker Visibility
Standard X
General
-Segment
Standard 4:3 X
-Chassis M28B
-Software Delivery Mode
-Software Version
-Mains Voltage
110V - 270V
90 - 260V
90-276 AutoV
160 - 260 V
230 - 240 V X
-Mains Frequency
50Hz X
-Type Mains Cord
FlatPin(Non-Polarised)
Australia SAA
Australia / New Zealand
Euro
New Zealand
VDE
Power Consumption (P)TV in On 70W
Power Consumption SB in Watts
Less than 1 X
Less than 3
Less than 6
Less than 10
Power Consumption Semi SB in W
-Power in "ON" for
-Power in Standby for
-Power in "OFF" for
-INDICATION on BACKCOVER
Made-in in Family Sheet X
FCC/Elect Shock caution label
Serial label X
Warning label on backcover X
-Channel
National Org.-NO X
Final Equipment
-Packaging - methods
2 Colour Printing
Brown Carton
White Carton
-Documents and manuals
Instruction Book (User Manual) x
Adbertising Brochure
Extended Warranty Brochure
Guarantee Doc X
Screen Sticker
Approbation Labels X
Easy installation Guide
Plastic Bag X
Page 5
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
Warning label X
Warranty Card
-Languages DFU
Arabic
English x
Local Integration
Malay
Thai
-Cables Supplied
-Antenna Supplied
-Stand Supplied
-Aux Equipm Supplied
Batteries for RC (2 x AA) x
Miscellaneous
-Approbation
CB X
EMC X
-Tests
-Local Integration
PIP/POP
-Type
---
-Features
Digital Reception
-Transmission
-Profile/Level
Digital Software
-Services
Digital Connections
-Digital Rear
Built-in Data System
-Text Standard
No Text
-(Tele)text Features
1 Page text
10 Page text
-Nbr bacgrnd page/Mem Size
-Text Technology
-Digital Data handling
-Program Guide
Built-in Clock/Timer
-Type
-Features
Built-in Radio
-Type
Built-in PC display
VGA
XGA
SVGA
SXGA
WVGA
UXGA
-PC Synch
-PC Control
Built-in TV display
50i
60i
100i
60P
75P
Built-in Media Slots/ DVD driver
-Type of Medium
-Type of Deck
-Version of Deck
-Playback Formats
-Copy Protection Compliance
Phased Out Items
-Tuner/Frontend
-Sensitivity
-CRT EHT
-Lightning Protection
-Account
Page 6
PFS (Product Functional Specification)
Date:
ProductView......:
Report by............: Linda Wen TC1631TV
Specs / Products
-XX(Radio Antenna in)
-Non Volatile Memory
-In Y/C + Cinch(CVBS+Mo)
Version of deck
Page 7
Item No. Description Quantity Req. Designator Remarks
08-01427H-CRY ASS'Y - CRT BD 1
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q510
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q501
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q502
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q503
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R501
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R504
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R507
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R522
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R524
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R502
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R505
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R508
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R525
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R523
18-CB0751-JNX RES. C.F. 750 OHM 1/6W +/-5% 1 R503
18-CB0751-JNX RES. C.F. 750 OHM 1/6W +/-5% 1 R506
18-CB0751-JNX RES. C.F. 750 OHM 1/6W +/-5% 1 R509
18-CD0104-JNX RES. C.F. 100K OHM 1/4W +/-5% 1 R521
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R514
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R515
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R518
18-FG0123-JHX RES. M.O. 12K OHM 2W +/-5% 1 R510
18-FG0123-JHX RES. M.O. 12K OHM 2W +/-5% 1 R511
18-FG0123-JHX RES. M.O. 12K OHM 2W +/-5% 1 R512
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C507
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C504
26-AMK221-KBX CAP. CER 220PF 2KV +/-10% B 1 C505
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C514
35-139730-00X FERR. BEAD BF60 2 FOR C514 (L505 & L506)
46-33624H-04X HS 3P 2468#24 270 TJC3-4Y/SCN-4Y 1 P502 FOR M. BD P402
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R526
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R527
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J501
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J502
13
Item No. Description Quantity Req. Designator Remarks
46-10967W-01X PIN BASE *1 TJC1-1A 1 P504
46-35038H-05X HS 5P24 380 TJC3-5Y/SCN-5Y 1 P501 FOR M.BD P201
25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C506
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C508
47-CRT009-CX0 SOCKET CRT 12P GZS12-4-2 1 S501
26-EBP221-JCS CAP. CER 220 pF 50V +/-5% 1 C510
26-EBP221-JCS CAP. CER 220 pF 50V +/-5% 1 C511
26-EBP221-JCS CAP. CER 220 pF 50V +/-5% 1 C512
26-EBP681-JCS CAP. CER 680 pF 50V +/-5% 1 C501
26-EBP681-JCS CAP. CER 680 pF 50V +/-5% 1 C502
26-EBP681-JCS CAP. CER 680 pF 50V +/-5% 1 C503
40-1418MH-CRB1X P.C.B. CRT BD 1
08-01418H-PW4 ASS'Y - POWER PARTS(AUST,100UF) 1
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D807
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D806
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D805
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D831
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D830
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D831A
10-0RU3AM-F0X DIODE RU3AM (FAST RECOVERY) 1 D824
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D811
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D812
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D813
10-79C3V9-DBX DIODE ZENER 3V9 1/2W 5% 1 D808A
10-79C5V6-DBX DIODE ZENER 5V6 1/2W 5% 1 D808
10-79C9V1-DBX DIODE ZENER 9V1 1/2W 5% 1 D809
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q801
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q802
11-SC1959-YBX TRANSISTOR 2SC1959Y 1 Q803
11-SC5586-0AX TRANSISTOR 2SC5586 1 Q804
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R807
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R817
18-CD0103-JNX RES. C.F. 10K OHM 1/4W +/-5% 1 R805
18-CD0272-JNX RES. C.F. 2.7K OHM 1/4W +/-5% 1 R806
18-CD0331-JNX RES. C.F. 330 OHM 1/4W +/-5% 1 R811
18-CD0392-JNX RES. C.F. 3.9K OHM 1/4W +/-5% 1 R808
18-CD0472-JNX RES. C.F. 4.7K OHM 1/4W +/-5% 1 R812
14
Item No. Description Quantity Req. Designator Remarks
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5% 1 R831
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5% 1 R832
18-EF0228-JGX RES. FUS. 0.22 0HM 1W +/-5% 1 R831A
18-CF0224-JHX RES. C.F. 220K OHM 1W +/-5% 1 R803
18-CF0224-JHX RES. C.F. 220K OHM 1W +/-5% 1 R803A
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R824
18-FJ0390-JJX RES. M.O. 39 OHM 5W +/-5% 1 R816
18-GJ0339-KUX RES. WIRE ROUND 3.3 OHM 5W +/-10% 1 R801
18-KE0475-JNX RES. GLASS GLAZE 4.7M OHM 1/2W +/-5% 1 R835
18-KE0475-JNX RES. GLASS GLAZE 4.7M OHM 1/2W +/-5% 1 R835A
20-TR102H-5CX TRIMMER B1K HORIZ TYPE 1 VR801
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C845
25-BCB330-M1X CAP. ELEC 33 UF 16V +/-20% 1 C812
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C842
25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% 1 C810
25-BHB100-M1X CAP. ELEC 10 UF 100V +/-20% 1 C811
25-BJG101-M1X CAP. ELEC 100 UF 160V +/-20% 1 C827
26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C840
26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C843
26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C843A
26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C805A
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C826
26-AIM103-KBX CAP. CER 0.01UF 500V +/-10% B 1 C814
26-AMK331-JZX CAP. CER 330 pF 2KV +/-5% SL 1 C830
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E 1 C835
26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F 1 C804
26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F 1 C805
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C844
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C841
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C844A
27-ALQ222-J0X CAP. M.PP 2200 PF 1.6KV +/-5% 1 C809
27-AQT224-MVH CAP. M.PP 0.22 UF 275VAC 20% 1 C801
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C808
27-MBC333-J0X CAP. M.P.E 0.033UF 63V +/-5% 1 C807
27-MHM104-K0X CAP. METAL P.E. 0.1UF 400V 10% 1 C803
34-A608K6-1BX COIL CHOKE 0.6 UH +/-10% 1 L801
34-R101K2-1BX COIL CHOKE 100 UH +/-10% 1 L804
15
Item No. Description Quantity Req. Designator Remarks
35-139730-00X FERR. BEAD BF60 2 FOR D831A
35-139730-00X FERR. BEAD BF60 2 FOR D824
35-139730-00X FERR. BEAD BF60 2 FOR D831
35-139730-00X FERR. BEAD BF60 2 FOR D830
35-237250-00X FERR. BEAD HF70 4.5X5.0 2 FOR R815
36-LIF004-AX0 LINE FILTER 1 T801
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J825
41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J826
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 L802
41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 L803
41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J801
41-WJ0170-B00 WIRE BARE JUMPER 17MM 1 J830
41-WJ0170-B00 WIRE BARE JUMPER 17MM 1 J829
41-WJ0185-B00 WIRE BARE JUMPER 18.5MM 1 J831
41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J828
41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J827
48-POW001-AX0 SWITCH POWER 1 SW801
50-02000D-1GS1 FUSE 2.0AT 250VAC 5mmX20mm 1 F801
51-JC0243-0PB01 POWER CORD 1
64-P30100-104 M/C SCREW P 3 X 10 1 MTG Q804
65-Z30050-23M NUT M 3 1 FOR Q804
66-20516X-0B0 FUSE HOLDER 2 FOR FUSE
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR T802
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR T801
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 3 FOR RT801
67-H28649-1A0 HEAT SINK 1 FOR Q804
71-DYP000-WX1 LABEL 1 STICK ON H.SINK(Q804)
25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% 1 C845A
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 4 FOR L804,D830
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 6 FOR C801,C827,D824
46-28559W-02X PIN BASE *2 TJC1-2A 1 P802
46-10962W-02X PIN BASE *2 TJC2-2A 1 P801
18-RG0338-JFX RES. WIRE ROUND 0.33 OHM 2W +/-5% 1 R815
25-BMJ101-M1X CAP. ELEC 100 UF 400V +/-20% 1 C806
10-0RL255-EBX DIODE RL255 OR RL206(POWER RECTIFIER) 1 D801
10-0RL255-EBX DIODE RL255 OR RL206(POWER RECTIFIER) 1 D802
10-0RL255-EBX DIODE RL255 OR RL206(POWER RECTIFIER) 1 D803
16
Item No. Description Quantity Req. Designator Remarks
10-0RL255-EBX DIODE RL255 OR RL206(POWER RECTIFIER) 1 D804
22-PTC200-XX0 POSISTOR 20 OHM (25-34) 1 RT801
18-FH0270-JLX RES. M.O. 27 OHM 3W +/-5% 1 R814
36-TRF130-AX0 TRANSFORMER BCK-3559 1 T802
18-GJ0229-KUX RES. CEMENT 2.2 OHM 5W +/-10% 1 R804
18-FF0229-JGX RES. M.O. 2.2 OHM 1W +/-5% 1 R813
66-343740-0B0 HOLLOW RIVET (2.3mmx4.0mmx3.5mm) 8 FOR R801,R804,C806,P801
90-0DSTG1-SR1 HEAT SINK DSTG-1 0.0003
08-01427H-AVY ASS'Y - SIDE AV BD 1
40-2175MU-SIC P.C.B. SIDE AV BD 1
46-30790H-06X HS 6P24 400 TJC3-6Y/SCN-6Y 1 P1104B FOR M. BD P904
47-RCA020-XX1 RCA SOCKET Y/W/R 1 P1101 FOR P1101 & P1102 & P1103
08-02113H-AUY ASS'Y - AUDIO STEREO 1
11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q606
11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q607
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q603
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q608
13-000040-66P IC 4066 (ANALOG SW.) 1 IC603
13-TDA705-7AS IC TDA7057AQ (R/L AUDIO O/P) 1 IC601
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R033
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R604A
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R610
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R622
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R019
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R611
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R614
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R612
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R613
18-CB0822-JNX RES. C.F. 8.2k OHM 1/6W +/-5% 1 R006
18-CD0479-JNX RES. C.F. 4.7 OHM 1/4W +/-5% 1 R640
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C635
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20% 1 C604
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C622
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C624
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C601
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C602
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C603
17
Item No. Description Quantity Req. Designator Remarks
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C636
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C610
27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C607
27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C608
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J110
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J916
41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J919
41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J920
41-WJ0115-B00 WIRE BARE JUMPER 11.5MM 1 J604
64-P30100-104 M/C SCREW P 3 X 10 2 FOR IC601
67-H34423-CA0 HEAT SINK 1 FOR IC601
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R633
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R636
08-0E276H-FC4 ASS'Y - FRONT CAB(AUST,0AN) 1
02-GND014-XX0 ASS"Y - CRT GND WIRE&HOUSE 1
42-50916D-XX0 SPEAKER 16 OHM 5W (50mmX90mm) 1 W601
42-50916D-XX0 SPEAKER 16 OHM 5W (50mmX90mm) 1 W602
46-13902H-02X HS 2P 2468#22 360 S11-2Y/7mm 1 P601H FOR M. BD P601
46-20600H-04X HS 4P A/B 360/13 RBGW TJC1-4Y 1 P401H FOR D.Y COIL
46-27250H-02X HS 2P24 450/5 F/W TJC3-02H 1 P602H FOR M. BD P602
54-113970-0U0 PVC TUBE #5 L=ROLL 0.32 FOR SPK HOUSING
54-205140-000 SPACER CRT MOUNTING T=2MM 4 FOR CRT & FRONT CAB.
54-314740-0X0 CRT FIBRE SHEET (22mmX22mmX0.8mm) 8 FOR CRT & FRONT CAB.
56-E276FB-0HA PUSH BUTTON 1
56-E276LE-0HC DISPLAY LENS 1
56-E276PK-0HA POWER KNOB 1
58-1418SI-4UI INLAY SIDE AV 1
59-130460-00X RUBBER PAD (25mmX7mm) 2 STICK FOR FOOTING CABINET
59-312160-000 SPEAKER RUBBER CUSHION 8 FOR SPK
62-345690-1UN ASSISTANT RAIL HIPS-KINGFA 113 (VO) 1 FOR M.BD TRACK(F. CAB.)
63-B30080-AB4 S/T SCREW B 3 X 8 AB 1 MTG LENS & F. CAB.
63-H50250-BF4 S/T SCREW H 5 X 25 BF 4 MTG CRT & FRONT CAB.
63-W30080-AB4 S/T SCREW W 3 X 8 AB 2 MTG SIDE AV BD & F. CAB.
63-W30080-AB4 S/T SCREW W 3 X 8 AB 2 MTG M.BD TRACK & F. CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 3 MTG PUSH BUTTON & F. CAB.
63-W30120-AB4 S/T SCREW W 3 X 12 AB 8 MTG SPK & F. CAB.
65-A50200-20E WASHER 5 X 20 X 2MM 4 MTG CRT
18
Item No. Description Quantity Req. Designator Remarks
67-X12668-0E0 SPRING CRT 6mmX40mmX0.5mm 1
67-X22898-0E0 SPRING - KNOB 1
44-14OFLS-IR2A CRT 37SX110Y22-DC05(AUST) 1 CRT01
57-10654X-00F TWIST TIE NY66 10
62-216340-0UN HOLDER POWER CORD HIPS-KINGFA 113(VO) 1
62-262660-0HN POWER SW.ADAPTER 1
36-DEG140-AX0 DEGAUSSING COIL 1080+20MM 1
55-E276FC-1AA FRONT CABINET 1
08-0E276H-RC5 ASS'Y - REAR CAB(Y/C,YUV,OAN) 1
54-114000-00X FELT TAPE (150mmX19mmX0.3mm) 4 STICK ON REAR CAB.
58-2106RI-BUI INLAY REAR AV 1
58-E276MP-JKT PLATE MODEL NO. 1
59-130460-00X RUBBER PAD (25mmX7mm) 2 STICK ON REAR CAB. (FOOTING)
62-314340-0UN FBT SUPPORTER HIPS-KINGFA 113 (VO) 1
62-345700-0UN ATTACHMENT RAIL PIPS-KINGFA 113 (VO) 1 FOR M.BD TRACK(R. CAB.)
63-B40200-AB3 S/T SCREW B 4 X 20 AB 4 MTG FRONT & REAR CAB.
63-F30100-BT3 S/T SCREW F 3 X 10 BT (BLACK) 2 MTG RCA JACK & REAR CAB.
63-W30080-AB4 S/T SCREW W 3 X 8 AB 2 MTG M.BD TRACK & REAR CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 2 MTG SUPPORTER BKT & R.CAB.
55-1475RC-5AN REAR CABINET 1
08-E2764H-MA5 ASS'Y - MAIN BD(Y/C,YUV) 1
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D401
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D402
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D403
10-1N4001-EBX DIODE 1N4001 (RECTIFIER) 1 D301
10-1N4002-EBX DIODE 1N4002 (RECTIFIER) 1 D405
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D005
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D206
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D006
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D007
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D601
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D008
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D002
10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D001
10-79C6V2-DBX DIODE ZENER 6V2 1/2W 5% 1 D404
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D205
10-CW574C-DJX DIODE CW574CD 1 D102
19
Item No. Description Quantity Req. Designator Remarks
11-2N3904-0BX TRANSISTOR 2N3904 (NPN) 1 Q103
11-C124ES-0BX TRANSISTOR PDTC124ES (NPN) 1 Q604
11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q204
11-DD1555-0AX TRANSISTOR 3DD1555 1 Q402
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q003
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q202
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q005
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q209
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q210
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q605
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q203
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q206
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q208
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q905
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q609
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q207
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q401
11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) 1 Q101
13-00M24C-08P IC EEPROM 8K M24C08 (WRITE) 1 IC001
13-0STV93-02S IC STV9302 1 IC301
13-HA178L-05T IC HA178LNA 5V 1 Q002
13-L7809C-VAP IC L7809CV 1 IC401
14-LED05R-XX1 LED RED FB205 1 D051
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R001A
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R034
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R047
18-CB0101-JNX RES. C.F. 100 OHM 1/6W +/-5% 1 R218
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R005
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R013
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R015
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R029
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R116
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R239
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R240
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R241
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R415
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R637
20
Item No. Description Quantity Req. Designator Remarks
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R901
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R912
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R961
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R962
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 C226
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R009
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R001
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R309
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R030
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R032
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R240A
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R406
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R017
18-CB0104-JNX RES. C.F. 100K OHM 1/6W +/-5% 1 R031
18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R212
18-CB0123-JNX RES. C.F. 12k OHM 1/6W +/-5% 1 R310
18-CB0132-JNX RES. C.F. 1.3K OHM 1/6W +/-5% 1 R010
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R217
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R115
18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R117
18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R311
18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R022
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R111
18-CB0153-JNX RES. C.F. 15k OHM 1/6W +/-5% 1 R112
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5% 1 R023
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R201
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R202
18-CB0221-JNX RES. C.F. 220 OHM 1/6W +/-5% 1 R203
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R014
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R215
18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R235
18-CB0273-JNX RES. C.F. 27k OHM 1/6W +/-5% 1 R414
18-CB0224-JNX RES. C.F. 220k OHM 1/6W +/-5% 1 R206
18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% 1 R233
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R024
18-CB0273-JNX RES. C.F. 27k OHM 1/6W +/-5% 1 R922A
18-CB0303-JNX RES. C.F. 30K OHM 1/6W +/-5% 1 R205
21
Item No. Description Quantity Req. Designator Remarks
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R220
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R219
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R228
18-CB0331-JNX RES. C.F. 330 OHM 1/6W +/-5% 1 R227
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R218A
18-CB0332-JNX RES. C.F. 3.3k OHM 1/6W +/-5% 1 R046
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R110
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R602
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R922
18-CB0333-JNX RES. C.F. 33K OHM 1/6W +/-5% 1 R232
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R312
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R213
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R307
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R214
18-CB0392-JNX RES. C.F. 3.9K OHM 1/6W +/-5% 1 R007
18-CB0432-JNX RES. C.F. 4.3K OHM 1/6W +/-5% 1 R025
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R002
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R018
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R119
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R238
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R243
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R401
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R923
18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R020
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R041
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R244
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R308
18-CB0472-JNX CARBON RES. C.F. 4.7K OHM 1/6W +/-5% 1 R011
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R109
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R216
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R245
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R927
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R926
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R924
18-CB0473-JNX RES. C.F. 47k OHM 1/6W +/-5% 1 R925
18-CB0512-JNX RES. C.F. 5.1k OHM 1/6W +/-5% 1 R042
18-CB0560-JNX RES. C.F. 56 OHM 1/6W +/-5% 1 R114
22
Item No. Description Quantity Req. Designator Remarks
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R209
18-CB0564-JNX RES. C.F. 560K OHM 1/6W +/-5% 1 R210
18-CB0622-JNX RES. C.F. 6.2k OHM 1/6W +/-5% 1 R026
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R028
18-CB0683-JNX RES. C.F. 68k OHM 1/6W +/-5% 1 R211
18-CB0750-JNX RES. C.F. 75 OHM 1/6W +/-5% 1 R904
18-CB0820-JNX RES. C.F. 82 OHM 1/6W +/-5% 1 R914
18-CB0821-JNX RES. C.F. 820 OHM 1/6W +/-5% 1 R118
18-CB0822-JNX RES. C.F. 8.2k OHM 1/6W +/-5% 1 R237
18-CD0100-JNX RES. C.F. 10 OHM 1/4W +/-5% 1 R027
18-CE0229-JNX RES. C.F. 2.2 OHM 1/2W +/-5% 1 R314
18-CE0152-JNX RES. C.F. 1.5k OHM 1/2W +/-5% 1 R316
18-CE0152-JNX RES. C.F. 1.5k OHM 1/2W +/-5% 1 R315
18-CE0331-JNX RES. C.F. 330 OHM 1/2W +/-5% 1 R409
18-CE0560-JNX RES. C.F. 56 OHM 1/2W +/-5% 1 R317
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R403
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R405
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R418
18-EF0109-JGX RES. FUS. 1 OHM 1W +/-5% (LS) 1 R416
18-EG0688-JHX RES. FUS. 0.68 OHM 2W +/-5% 1 R407
18-FE0120-JNX RES. M.0. 12 OHM 1/2W +/-5% 1 R236
18-FF0103-JGX RES. M.O. 10k OHM 1W +/-5% 1 R410
18-FF0122-JGX RES. M.O. 1.2k OHM 1W +/-5% 1 R441
18-FF0123-JGX RES. M.O. 12k OHM 1W +/-5% 1 R408
18-FF0279-JGX RES. M.O. 2.7 OHM 1W +/-5% 1 R313
18-FF0391-JGX RES. M.O. 390 OHM 1W +/-5% 1 R336
18-FF0560-JGX RES. M.O. 56 OHM 1W +/-5% 1 R108
18-FG0153-JHX RES. M.O. 15k OHM 2W +/-5% 1 R404
18-RG0228-JHX RES. WIRE ROUND 0.22 OHM 2W +/-5% 1 R620
25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C416A
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C004
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C023
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C227
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C242
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C907
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C220
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C908
23
Item No. Description Quantity Req. Designator Remarks
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C240
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C605
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 1 C211
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C909
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C016
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 1 C015
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C231
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C217
25-BCB221-M1X CAP. ELEC 220 UF 16V +/-20% 1 C903
25-BCB331-M1X CAP. ELEC 330 UF 16V +/-20% 1 C009
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C423
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C202
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C108
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C081
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C418
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C232
25-BDA102-M1X CAP. ELEC 1000 UF 25V +/-20% 1 C308
25-BEA221-M1X CAP. ELEC 220 UF 35V +/-20% 1 C302
25-BEA471-M1X CAP. ELEC 470 UF 35V +/-20% 1 C413
25-BEB101-M1X CAP. ELEC 100 UF 35V +/-20% 1 C303
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C208
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C203
25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% 1 C214
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% 1 C008A
25-BFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% 1 C307
25-BFB478-M1X CAP. ELEC 0.47 UF 50V +/-20% 1 C218
25-GFB478-K1X CAP. ELEC 0.47 UF 50V +/-10% 1 C234
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C305
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C101
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C103
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C216
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C030
25-BHB100-M1X CAP. ELEC 10 UF 100V +/-20% 1 C420
25-BJA470-M1X CAP. ELEC 47 UF 160V +/-20% 1 C411
25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C408
25-GFB228-K1X CAP. ELEC 0.22 UF 50V +/-10% 1 C205
25-GFB478-K1X CAP. ELEC 0.47 UF 50V +/-10% 1 C236
24
Item No. Description Quantity Req. Designator Remarks
26-AIC102-KBX CAP. CER 1000 PF 500V +/-10% B 1 C401
26-AIC102-KBX CAP. CER 1000 PF 500V +/-10% B 1 C404
26-AIC332-KBX CAP. CER 3300 PF 500V +/-10% B 1 C407
26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C409
26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C412
26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C414
26-AMK331-JZX CAP. CER 330 pF 2KV +/-5% SL 1 C406B
26-EBP100-JCX CAP. CER 10PF 50V +/-5% CH 1 C304
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C219
26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C306
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C212
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C109
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C019
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C114
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C024
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C201
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C241
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C005
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C228
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C230
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C233
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C425
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C417
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C110
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C239
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C020
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C017
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C221
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C931
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C135
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C082
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C237
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C415
27-AGQ394-JSX CAP. M.PP 0.39UF 250VAC +/-5% 1 C421
27-AGQ563-J0X CAP. M.PP 0.056 UF 250V +/-5% 1 C410B
27-ALR922-J0X CAP. M.PP 0.0092UF 1.6KV +/-5% 1 C402
27-MBC103-J0X CAP. M.P.E 0.01UF 63V+/-5% 1 C215
25
Item No. Description Quantity Req. Designator Remarks
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C106
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C301
27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C309
27-PBC152-J0X CAP. P.E 0.0015UF ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
