B&K MODEL
TUBE TESTER
OFFICIAL INSTRUCTIONS
"A" Circuit
The Model 650 is a dynamic mutual conductance tube tester, built
.
in two chassis The first chassis consists of the main panel which contains
of the necessary voitages required to test the tubes and all 33 test
sockets.
voltages required for the auxiliary socket panel appear on the
contact conneetor located on the bridge panel . The terminals of
this contact a
