               SG2100 EASY INSTALLATION
                     INSTRUCTION




     For South Hemishpere, please change South to North and exchange East
     and West in the following instruction.

DMS International - http://www.dmsiusa.com
STEP 1.
Make sure the pole/stand is exactly vertical to ground. Use a plumb and a level to do the vertical and
level correction. Good pole/stand alignment is the first and the most essential step for the installation.




                          Level




                                                                              Plumb




  DMS International - http://www.dmsiusa.com
STEP 2.
Mount the motor onto the pole/stand. Align the centre of the motor, bracket and the pole/stand to the
True South. To get the True South, use a compass to determine the Magnetic South and deduct the
Magnetic Declination.
Find the Magnetic Declination of your location via:
http://www.geolab.nrcan.gc.ca/geomag/magdec_e.shtml


                  True
                  South
       Magnetic
        South




                  Magnetic Declination

                                                                                       True
                                                                                       South




 DMS International - http://www.dmsiusa.com
STEP 3.
Mount the dish onto the motor's tube and wire it up; then set the elevation on motor's bracket as well as
the declination on dish's bracket according to your latitude.




                       See the Elevation and Declination                                    Elevation setting
                       angels table in the SG2100 Manual.




                                                                                            Declination setting




  DMS International - http://www.dmsiusa.com
STEP 4.
Drive the motor via motor's manual button or the receiver to aim a satellite with stronger single, which is
better not far from the True South.
GotoX function can help calculate the degree the motor should rotate to.

 STEP 5.
 In the angle mentioned above, there should be signal, and fine-tune the elevation / declination / azimuth
 angle / True South (Rotate the whole motor+dish) to get the best reception signal.
 Then, scan the satellite and store the channels.

 STEP 6.
 Repeat step 4 & 5 for other satellites.


  STEP 7.
  After completing the installation, mark the current position just in case.




   DMS International - http://www.dmsiusa.com
                                      TROUBLESHOOTING & FAQ

        Symptoms or Questions                                              Check points or Answers



                                                The direction in which the compass points is referred to as Magnetic South in
  What is Magnetic South                        stead of True South.
  and True South?                               In fact, there is an angle difference called Magnetic Declination between these
                                                two.
                                                Find the Magnetic Declination of your location via:
                                                http://www.geolab.nrcan.gc.ca/geomag/magdec_e.shtml


  After fine tune, there is still weak signal   1.Make sure the coaxial cable is well connected.
 or no signal at all in the aimed satellite
                                                2.Make sure all the satellite equipments work properly. Also make sure all the
 position.
                                                 receiver's setting (LNB, Frequency, Symbol rate....) is correct.

                                                3.Make sure the pole/stand is straight and vertical to the ground.


 Only one or two satellites' signal are         It might be the reception arc does not correspond to the satellites arc. Make sure
 receivable.                                    the pole/stand is straight and vertical to the ground, and fine-turn the elevation /
                                                declination / azimuth angle patiently.



 What is GotoX function?                        It is a standard DiSEqC 1.2 command that drives motor to needed angle. Some
                                                receivers support this function and even can calculate the right angle to the
                                                aimed satellite according to your longitude and latitude.
