                                  Table of Contents

efio!121A BOM.........................................................................    1

efio!121A Sub. Assembly S.O.P.......................................................     9

efio!121A 12.1" LCD Instruction manual............................................       24

efio!121A System Setup Instruction manual.........................................       34

efio!121A (Complete set) Instruction Manual.......................................       55

efio!121A (CARRYING BAG) Packaging Instruction Manual...................                 67

efio!121A 2-IN-1 Packing S.O.P......................................................     73

efio!121A Disassembly.................................................................   82
efio!121A Notebook BOM
(Internal code: D212A)
========== ===============    ===============================================
LEVELS        ITEM NUMBER     DESCRIPTION                             QTY
    123456789 M-D212A         D212A ID2 MODEL
========== ===============    ===============================================
PCBA
.....5        82-873030-00    D212A-PCB ASS'Y-VI-K7-REV:0-W/WI            1
....4         80-690000-00D   P22AJ-PCB ASS'Y-VI-USB-REV:D                1

SYSTEM CABINET
.....5    27-300051-20        N222S1-GASKET TAPE-D4877A                    1
.....5    27-330000-00        ALL MODEL-THERMAL PAD FOR HEATSI             1
.....5    28-200022-11        2nd FAN-L=80mm-W/SPONGE                      1
.....5    29-001638-02        N222S1-RJ11 JACK HARNESS-SH638B              1
.....5    29-015340-00        P22AJ-SB-USB FPC-CA3400                      1
.....5    40-002311-00        N222S1-HARNESS COVER-C33210                  1
.....5    40-003510-11        P22AJ-HEATSINK MODULE W/FAN-SCRE             1
.....5    41-721520-03        SCREW ISOT-M2X3L-SELF-LOCKING
