Image preview - the first page of the document



>> Download NEA_ARP_Avatar_Patch_Panel_Installation_Manual_orig documenatation <<

Text preview - extract from the document

ARP AVATAR PATCH PANEL
 INSTRUCTION MANUAL
Introduction
      Thank you for purchasing an Avatar Patch Panel Kit! These instruc-
      tions are intended to guide you through installing and using this kit.
      Before we get started, let's go over a few guidelines:

      Never open the Avatar or perform any service on it when the unit is
      plugged in to AC power. Take your time when drilling in to the front
      panel and when making cuts to traces on the circuit boards. Careless
      work can damage your instrument and diminish its resale value. This
      work should be performed by persons experienced with electronics
      and mechanical construction. This modification is considered ad-
      vanced and should not be undertaken by the novice. Please consider
      hiring a professional technician or engineer to do this work if you are
      not comfortable. This kit will take 8-10 hours for an experienced tech-
      nician to install

Kit Contents
