JACKSON II ASC ALL PARTS : BILL OF MATERIAL 07.12.2007
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCAZ111016G C:ELECTROLYTIC 100UF 10V M C-156 C088 1
AT560ZHBAE BCAZ111016G C:ELECTROLYTIC 100UF 10V M C-156 C253 1
AT560ZHBAE BCAZ111016G C:ELECTROLYTIC 100UF 10V M C-156 C418 1
AT560ZHBAE BCAZ112216G C:ELECTROLYTIC 220UF 10V M C-156 C472 1 1 BCHL112216G
AT560ZHBAE BCAZ114716G C:ELECTROLYTIC 470UF 10V M C-156 C466 1 P BCHL114716G
AT560ZHBAE BCAZ511026G C:ELECTROLYTIC 1000UF 25V M C-156 C078 1
AT560ZHBAE BCAZ512206G C:ELECTROLYTIC 22UF 25V M C-156 C293 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C006 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C021 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C064 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C079 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C080 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C234 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C243 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C296 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C309 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C311 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C314 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C316 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C318 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C322 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C337 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C433 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C477 1
AT560ZHBAE BCAZ514706G C:ELECTROLYTIC 47UF 25V M C-156 C500 1
AT560ZHBAE BCAZ514716G C:ELECTROLYTIC 470UF 25V M C-156 C072 1
AT560ZHBAE BCAZ514716G C:ELECTROLYTIC 470UF 25V M C-156 C235 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C060 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C065 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C066 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C229 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C245 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C288 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C321 1
AT560ZHBAE BCAZ811006G C:ELECTROLYTIC 10UF 50V M C-156 C327 1
AT560ZHBAE BCAZ811096G C:ELECTROLYTIC 1UF 50V M C-156 C020 1
AT560ZHBAE BCAZ811096G C:ELECTROLYTIC 1UF 50V M C-156 C247 1
AT560ZHBAE BCAZ814796G C:ELECTROLYTIC 4.7UF 50V M C-156 C227 1
AT560ZHBAE BCHB813091G C:CERAMIC TS2.5S 3PF 50V C CJ C193 1
AT560ZHBAE BCHC811014G C:CERAMIC TS5.0S 100PF 50V J CH C213 1
AT560ZHBAE BCHC811014G C:CERAMIC TS5.0S 100PF 50V J CH C371 1
AT560ZHBAE BCHC811504G C:CERAMIC TS2.5S 15PF 50V J CH C256 1
AT560ZHBAE BCHC811504G C:CERAMIC TS2.5S 15PF 50V J CH C299 1
AT560ZHBAE BCHC811514G C:CERAMIC TS5.0S 150PF 50V J CH C212 1
AT560ZHBAE BCHC811814G C:CERAMIC TS5.0S 180PF 50V J CH C202 1
AT560ZHBAE BCHC811814G C:CERAMIC TS5.0S 180PF 50V J CH C204 1
AT560ZHBAE BCHC811814G C:CERAMIC TS5.0S 180PF 50V J CH C207 1
AT560ZHBAE BCHC811814G C:CERAMIC TS5.0S 180PF 50V J CH C211 1
AT560ZHBAE BCHC812204G C:CERAMIC TS2.5S 22PF 50V J CH C203 1
24.08.2009 Bill of material 1/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCHC812714G C:CERAMIC TS5.0S 270PF 50V J CH C198 1
AT560ZHBAE BCHC812714G C:CERAMIC TS5.0S 270PF 50V J CH C199 1
AT560ZHBAE BCHC813304G C:CERAMIC TS2.5S 33PF 50V J CH C205 1
AT560ZHBAE BCHC816804G C:CERAMIC TS5.0S 68PF 50V J CH C201 1
AT560ZHBAE BCHC816804G C:CERAMIC TS5.0S 68PF 50V J CH C210 1
AT560ZHBAE BCKQ811040G C:CERAMIC TS5.0S 0.1UF 50V Z YF C214 1
AT560ZHBAE BCKQ812230G C:CERAMIC TS5.0S 0.022UF 50V Z YF C215 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C033 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C038 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C039 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C040 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C046 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C048 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C049 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C051 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C052 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C056 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C059 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C062 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C063 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C068 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C073 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C075 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C090 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C108 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C110 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C134 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C155 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C158 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C161 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C167 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C194 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C273 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C294 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C295 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C308 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C310 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C313 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C315 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C429 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C440 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C443 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C444 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C459 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C469 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C474 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C476 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C478 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C479 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C480 1
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C482 1
24.08.2009 Bill of material 2/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCML311045G C:CERAMIC M/L (1608) TAPE 0.1UF 16V K B C501 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C071 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C135 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C137 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C139 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C200 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C233 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C249 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C270 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C283 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C284 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C332 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C446 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C447 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C451 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C453 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C458 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C463 1
AT560ZHBAE BCML311055G C:CERAMIC M/L (1608) TAPE 1UF 16V K B C467 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C001 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C022 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C044 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C054 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C084 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C104 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C105 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C106 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C156 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C251 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C464 1
AT560ZHBAE BCML811025G C:CERAMIC M/L (1608) TAPE 0.001UF 50V K B C470 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C002 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C005 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C007 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C012 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C014 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C015 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C017 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C023 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C024 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C025 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C026 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C027 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C028 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C029 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C031 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C032 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C034 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C047 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C050 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C061 1
24.08.2009 Bill of material 3/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C070 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C076 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C082 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C089 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C092 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C098 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C103 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C107 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C121 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C130 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C136 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C154 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C162 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C184 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C187 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C195 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C209 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C216 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C217 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C218 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C219 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C221 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C222 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C223 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C224 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C226 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C230 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C236 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C237 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C238 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C239 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C241 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C242 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C244 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C246 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C252 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C254 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C263 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C265 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C267 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C269 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C277 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C278 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C285 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C286 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C290 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C297 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C301 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C305 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C306 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C307 1
24.08.2009 Bill of material 4/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C312 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C317 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C323 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C324 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C325 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C326 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C330 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C335 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C336 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C342 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C350 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C365 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C370 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C373 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C405 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C407 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C412 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C414 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C420 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C421 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C423 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C425 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C426 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C434 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C437 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C438 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C439 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C441 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C457 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C465 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C473 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C481 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C497 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C498 1
AT560ZHBAE BCML811035G C:CERAMIC M/L (1608) TAPE 0.01UF 50V K B C499 1
AT560ZHBAE BCML811535G C:CERAMIC M/L (1608) TAPE 0.015UF 50V K B C058 1
AT560ZHBAE BCML811835G C:CERAMIC M/L (1608) TAPE 0.018UF 50V K B C448 1
AT560ZHBAE BCML811835G C:CERAMIC M/L (1608) TAPE 0.018UF 50V K B C449 1
AT560ZHBAE BCML812225G C:CERAMIC M/L (1608) TAPE 0.0022UF 50V K B C045 1
AT560ZHBAE BCML812235G C:CERAMIC M/L (1608) TAPE 0.022UF 50V K B C067 1
AT560ZHBAE BCML812235G C:CERAMIC M/L (1608) TAPE 0.022UF 50V K B C220 1
AT560ZHBAE BCML812235G C:CERAMIC M/L (1608) TAPE 0.022UF 50V K B C274 1
AT560ZHBAE BCML812235G C:CERAMIC M/L (1608) TAPE 0.022UF 50V K B C340 1
AT560ZHBAE BCML812725G C:CERAMIC M/L (1608) TAPE 0.0027UF 50V K B C129 1
AT560ZHBAE BCML812725G C:CERAMIC M/L (1608) TAPE 0.0027UF 50V K B C133 1
AT560ZHBAE BCML814725G C:CERAMIC M/L (1608) TAPE 0.0047UF 50V K B C074 1
AT560ZHBAE BCML814725G C:CERAMIC M/L (1608) TAPE 0.0047UF 50V K B C131 1
AT560ZHBAE BCML814725G C:CERAMIC M/L (1608) TAPE 0.0047UF 50V K B C132 1
AT560ZHBAE BCML814725G C:CERAMIC M/L (1608) TAPE 0.0047UF 50V K B C138 1
AT560ZHBAE BCML814725G C:CERAMIC M/L (1608) TAPE 0.0047UF 50V K B C163 1
AT560ZHBAE BCML814725G C:CERAMIC M/L (1608) TAPE 0.0047UF 50V K B C287 1
24.08.2009 Bill of material 5/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCML814735G C:CERAMIC M/L (1608) TAPE 0.047UF 50V K B C053 1
AT560ZHBAE BCML814735G C:CERAMIC M/L (1608) TAPE 0.047UF 50V K B C057 1
AT560ZHBAE BCML814735G C:CERAMIC M/L (1608) TAPE 0.047UF 50V K B C099 1
AT560ZHBAE BCML814735G C:CERAMIC M/L (1608) TAPE 0.047UF 50V K B C442 1
AT560ZHBAE BCML814735G C:CERAMIC M/L (1608) TAPE 0.047UF 50V K B C452 1
AT560ZHBAE BCML814735G C:CERAMIC M/L (1608) TAPE 0.047UF 50V K B C475 1
AT560ZHBAE BCML901055G C:CERAMIC M/L (1608) TAPE 1UF 6.3V K B C141 1
AT560ZHBAE BCML901055G C:CERAMIC M/L (1608) TAPE 1UF 6.3V K B C271 1
AT560ZHBAE BCML901055G C:CERAMIC M/L (1608) TAPE 1UF 6.3V K B C430 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C087 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C262 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C264 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C275 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C419 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C422 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C427 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C432 1
AT560ZHBAE BCMM811002G C:CERAMIC M/L (1608) TAPE 10PF 50V D CH C487 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C083 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C157 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C228 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C338 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C404 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C454 1
AT560ZHBAE BCMM811014G C:CERAMIC M/L (1608) TAPE 100PF 50V J CH C461 1
AT560ZHBAE BCMM811214G C:CERAMIC M/L (1608) TAPE 120PF 50V J CH C258 1
AT560ZHBAE BCMM811504G C:CERAMIC M/L (1608) TAPE 15PF 50V J CH C302 1
AT560ZHBAE BCMM811504G C:CERAMIC M/L (1608) TAPE 15PF 50V J CH C320 1
AT560ZHBAE BCMM811504G C:CERAMIC M/L (1608) TAPE 15PF 50V J CH C406 1
AT560ZHBAE BCMM811504G C:CERAMIC M/L (1608) TAPE 15PF 50V J CH C413 1
AT560ZHBAE BCMM811514G C:CERAMIC M/L (1608) TAPE 150PF 50V J CH C019 1
AT560ZHBAE BCMM811514G C:CERAMIC M/L (1608) TAPE 150PF 50V J CH C091 1
AT560ZHBAE BCMM811514G C:CERAMIC M/L (1608) TAPE 150PF 50V J CH C272 1
AT560ZHBAE BCMM811514G C:CERAMIC M/L (1608) TAPE 150PF 50V J CH C374 1
AT560ZHBAE BCMM811514G C:CERAMIC M/L (1608) TAPE 150PF 50V J CH C416 1
AT560ZHBAE BCMM811804G C:CERAMIC M/L (1608) TAPE 18PF 50V J CH C035 1
AT560ZHBAE BCMM811804G C:CERAMIC M/L (1608) TAPE 18PF 50V J CH C304 1
AT560ZHBAE BCMM811814G C:CERAMIC M/L (1608) TAPE 180PF 50V J CH C403 1
AT560ZHBAE BCMM811814G C:CERAMIC M/L (1608) TAPE 180PF 50V J CH C417 1
AT560ZHBAE BCMM812098G C: CERAMIC M/L (1608) TAPE 2PF 50V B CH C151 1
AT560ZHBAE BCMM812098G C: CERAMIC M/L (1608) TAPE 2PF 50V B CH C248 1
AT560ZHBAE BCMM812204G C:CERAMIC M/L (1608) TAPE 22PF 50V J CH C085 1
AT560ZHBAE BCMM812204G C:CERAMIC M/L (1608) TAPE 22PF 50V J CH C153 1
AT560ZHBAE BCMM812204G C:CERAMIC M/L (1608) TAPE 22PF 50V J CH C402 1
AT560ZHBAE BCMM812204G C:CERAMIC M/L (1608) TAPE 22PF 50V J CH C431 1
AT560ZHBAE BCMM812214G C:CERAMIC M/L (1608) TAPE 220PF 50V J CH C018 1
AT560ZHBAE BCMM812214G C:CERAMIC M/L (1608) TAPE 220PF 50V J CH C369 1
AT560ZHBAE BCMM812704G C:CERAMIC M/L (1608) TAPE 27PF 50V J CH C055 1
AT560ZHBAE BCMM812704G C:CERAMIC M/L (1608) TAPE 27PF 50V J CH C292 1
AT560ZHBAE BCMM812704G C:CERAMIC M/L (1608) TAPE 27PF 50V J CH C368 1
AT560ZHBAE BCMM813098G C: CERAMIC M/L (1608) TAPE 3PF 50V B CH C041 1
24.08.2009 Bill of material 6/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BCMM813098G C: CERAMIC M/L (1608) TAPE 3PF 50V B CH C042 1
AT560ZHBAE BCMM813098G C: CERAMIC M/L (1608) TAPE 3PF 50V B CH C093 1
AT560ZHBAE BCMM813098G C: CERAMIC M/L (1608) TAPE 3PF 50V B CH C260 1
AT560ZHBAE BCMM813098G C: CERAMIC M/L (1608) TAPE 3PF 50V B CH C266 1
AT560ZHBAE BCMM813098G C: CERAMIC M/L (1608) TAPE 3PF 50V B CH C303 1
AT560ZHBAE BCMM813304G C:CERAMIC M/L (1608) TAPE 33PF 50V J CH C298 1
AT560ZHBAE BCMM813304G C:CERAMIC M/L (1608) TAPE 33PF 50V J CH C456 1
AT560ZHBAE BCMM813314G C:CERAMIC M/L (1608) TAPE 330PF 50V J CH C164 1
AT560ZHBAE BCMM813314G C:CERAMIC M/L (1608) TAPE 330PF 50V J CH C462 1
AT560ZHBAE BCMM813904G C:CERAMIC M/L (1608) TAPE 39PF 50V J CH C008 1
AT560ZHBAE BCMM813904G C:CERAMIC M/L (1608) TAPE 39PF 50V J CH C010 1
AT560ZHBAE BCMM813904G C:CERAMIC M/L (1608) TAPE 39PF 50V J CH C255 1
AT560ZHBAE BCMM813904G C:CERAMIC M/L (1608) TAPE 39PF 50V J CH C289 1
AT560ZHBAE BCMM813904G C:CERAMIC M/L (1608) TAPE 39PF 50V J CH C328 1
AT560ZHBAE BCMM813914G C:CERAMIC M/L (1608) TAPE 390PF 50V J CH C159 1
AT560ZHBAE BCMM813914G C:CERAMIC M/L (1608) TAPE 390PF 50V J CH C225 1
AT560ZHBAE BCMM813914G C:CERAMIC M/L (1608) TAPE 390PF 50V J CH C455 1
AT560ZHBAE BCMM814098G C:CERAMIC M/L (1608) TAPE 4PF 50V B CH C268 1
AT560ZHBAE BCMM814098G C:CERAMIC M/L (1608) TAPE 4PF 50V B CH C415 1
AT560ZHBAE BCMM814704G C:CERAMIC M/L (1608) TAPE 47PF 50V J CH C016 1
AT560ZHBAE BCMM814704G C:CERAMIC M/L (1608) TAPE 47PF 50V J CH C043 1
AT560ZHBAE BCMM814704G C:CERAMIC M/L (1608) TAPE 47PF 50V J CH C095 1
AT560ZHBAE BCMM814704G C:CERAMIC M/L (1608) TAPE 47PF 50V J CH C261 1
AT560ZHBAE BCMM814714G C:CERAMIC M/L (1608) TAPE 470PF 50V J CH C004 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C009 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C011 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C013 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C030 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C086 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C094 1
AT560ZHBAE BCMM815098G C: CERAMIC M/L (1608) TAPE 5PF 50V B CH C096 1
AT560ZHBAE BCMM816091G C: CERAMIC M/L (1608) TAPE 6PF 50V C CH C036 1
AT560ZHBAE BCMM816091G C: CERAMIC M/L (1608) TAPE 6PF 50V C CH C097 1
AT560ZHBAE BCMM816091G C: CERAMIC M/L (1608) TAPE 6PF 50V C CH C319 1
AT560ZHBAE BCMM816814G C:CERAMIC M/L (1608) TAPE 680PF 50V J CH C450 1
AT560ZHBAE BCMM818204G C:CERAMIC M/L (1608) TAPE 82PF 50V J CH C232 1
AT560ZHBAE BCMM818204G C:CERAMIC M/L (1608) TAPE 82PF 50V J CH C257 1
AT560ZHBAE BCMM818204G C:CERAMIC M/L (1608) TAPE 82PF 50V J CH C460 1
AT560ZHBAE BCMP811804G C:CERAMIC M/L (1608) TAPE 18PF 50V J UJ C280 1
AT560ZHBAE BCMP811814G C:CERAMIC M/L (1608) TAPE 180PF 50V J UJ C279 1
AT560ZHBAE BCMP812204G C:CERAMIC M/L (1608) TAPE 22PF 50V J UJ C281 1
AT560ZHBAE BCMP812714G C:CERAMIC M/L (1608) TAPE 270PF 50V J UJ C276 1
AT560ZHBAE BCMP815604G C:CERAMIC M/L (1608) TAPE 56PF 50V J UJ C282 1
AT560ZHBAE BCMP816092G C:CERAMIC M/L (1608) TAPE 6PF 50V D UJ C231 1
AT560ZHBAE BCSH111006G C:TANTALUM CHIP TAPE 10UF 10V M C-122 TAPE C428 1
AT560ZHBAE BCSH312295G C:TANTALUM CHIP TAPE 2.2UF 16V K C-122 TAPE C410 1
AT560ZHBAE BCSH662286G CAPACITOR:TANTALUM CHIP 0.22UF 35V M C-122 TAPE C408 1
AT560ZHBAE BCXT811035G C:CERAMIC M/L (2125) TAPE 0.01UF 50V K B C376 1
AT560ZHBAE BCZG0249001 C:CERAMIC(1608) CZ-249 TMK107SD472JA-T C411 1
AT560ZHBAE BCZG0316007 C:CERAMIC CZ-316 GRM188B11C104KA01D C077 1 1 BCML811045G
AT560ZHBAE BCZG0316007 C:CERAMIC CZ-316 GRM188B11C104KA01D C081 1 1 BCML811045G
24.08.2009 Bill of material 7/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BDAG0433001 DIODE RLS4148 TE11 D201 1
AT560ZHBAE BDAG0433001 DIODE RLS4148 TE11 D203 1
AT560ZHBAE BDAG0433001 DIODE RLS4148 TE11 D205 1
AT560ZHBAE BDAG0433001 DIODE RLS4148 TE11 D211 1
AT560ZHBAE BDAG1220004 DIODE:ZENER UDZS F 5.1B TE-17 D407 1
AT560ZHBAE BDAG1220012 DIODE:ZENER UDZS F 12B TE-17 D308 1
AT560ZHBAE BDAG1220015 DIODE:ZENER UDZS F 7.5B TE-17 D024 1
AT560ZHBAE BDAG1220015 DIODE:ZENER UDZS F 7.5B TE-17 D025 1
AT560ZHBAE BDAG1220015 DIODE:ZENER UDZS F 7.5B TE-17 D409 1
AT560ZHBAE BDAG1220015 DIODE:ZENER UDZS F 7.5B TE-17 D454 1
AT560ZHBAE BDAG1220016 DIODE:ZENER UDZS F 3.0B TE-17 D452 1
AT560ZHBAE BDAG1265001 DIODE DA-1265 1SS226(TE85L,F) D131 1
AT560ZHBAE BDAG1265001 DIODE DA-1265 1SS226(TE85L,F) D403 1
AT560ZHBAE BDAG1269001 DIODE KDS114E-RTK/P D271 1
AT560ZHBAE BDAG1269001 DIODE KDS114E-RTK/P D272 1
AT560ZHBAE BDAG1269001 DIODE KDS114E-RTK/P D275 1
AT560ZHBAE BDAG1269001 DIODE KDS114E-RTK/P D398 1
AT560ZHBAE BDAG1269001 DIODE KDS114E-RTK/P D399 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D005 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D012 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D014 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D015 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D017 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D019 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D023 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D061 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D132 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D152 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D202 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D207 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D214 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D218 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D225 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D273 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D274 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D408 1
AT560ZHBAE BDAG1270001 DIODE KDS160E-RTK/P D451 1
AT560ZHBAE BDAG1272001 DIODE HVC358BTRF-E D022 1
AT560ZHBAE BDAG1272001 DIODE HVC358BTRF-E D217 1
AT560ZHBAE BDAG1274001 DIODE DA-1274 MA2J72800L D018 1
AT560ZHBAE BDAG1274001 DIODE DA-1274 MA2J72800L D208 1
AT560ZHBAE BDAG1274001 DIODE DA-1274 MA2J72800L D209 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D003 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D004 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D006 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D007 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D013 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D212 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D213 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D402 1
AT560ZHBAE BDAG1280001 DIODE:VARICAP HVU307 TRU-E D405 1
24.08.2009 Bill of material 8/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D011 1
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D016 1
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D151 1
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D204 1
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D206 1
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D453 1
AT560ZHBAE BDAG1285001 DIODE HSM88AS TL-E D455 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D008 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D009 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D010 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D020 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D021 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D215 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D301 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D302 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D303 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D304 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D456 1
AT560ZHBAE BDAG1326001 DIODE 1SS184( TE85L,F) D457 1
AT560ZHBAE BDAG1383001 DIODE GD 1N5401-B5-GP D051 1
AT560ZHBAE BDAG1387001 DIODE:VARICAP HVU200A-TRU-E D401 1
AT560ZHBAE BDAG1387001 DIODE:VARICAP HVU200A-TRU-E D404 1
AT560ZHBAE BDAG1471001 DIODE DA-1471 HSU277 TRF-E D001 1
AT560ZHBAE BDAG1471001 DIODE DA-1471 HSU277 TRF-E D002 1
AT560ZHBAE BDBJ0950558 TRANSISTOR DB-095 2SA950-Y(F) Q302 1
AT560ZHBAE BDBJ0950558 TRANSISTOR DB-095 2SA950-Y(F) Q303 1
AT560ZHBAE BDBJ1235730 TRANSISTOR DB-089 2SA1235A-T112-1F Q155 1
AT560ZHBAE BDBJ1235730 TRANSISTOR DB-089 2SA1235A-T112-1F Q206 1
AT560ZHBAE BDBJ1235730 TRANSISTOR DB-089 2SA1235A-T112-1F Q214 1
AT560ZHBAE BDBJ1235730 TRANSISTOR DB-089 2SA1235A-T112-1F Q224 1
AT560ZHBAE BDBJ1235730 TRANSISTOR DB-089 2SA1235A-T112-1F Q454 1
AT560ZHBAE BDBL0941112 TRANSISTOR DB-1212 2SC941TM-Y(TPE2,F) Q202 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q013 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q014 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q017 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q021 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q026 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q071 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q131 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q132 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q154 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q157 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q205 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q212 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q272 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q327 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q330 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q333 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q334 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q351 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q352 1
24.08.2009 Bill of material 9/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q450 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q457 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q458 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q459 1
AT560ZHBAE BDBL2412117 TRANSISTOR DB-1278 2SC2412KT146R Q460 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q001 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q003 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q004 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q005 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q006 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q011 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q012 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q151 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q153 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q156 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q158 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q203 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q204 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q209 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q217 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q222 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q228 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q271 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q273 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q326 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q402 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q405 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q406 1
AT560ZHBAE BDBL2714124 TRANSISTOR DB-718 2SC2714-Y (TE85L,F) Q409 1
AT560ZHBAE BDBL3243105 TRANSISTOR DB-1211 2SC3243-T111-E Q332 1
AT560ZHBAE BDBL5065124 TRANSISTOR DB-1169 2SC5065-Y(TE85R,F) Q404 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q007 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q015 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q016 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q025 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q208 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q210 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q453 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q455 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q456 1
AT560ZHBAE BDBM1048732 TRANSISTOR DB-467 2SD1048-6-TB-E Q461 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q305 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q306 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q308 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q310 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q311 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q315 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q316 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q317 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q318 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q319 1
24.08.2009 Bill of material 10/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q320 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q321 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q322 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q323 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q324 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q325 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q411 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q412 1
AT560ZHBAE BDBN1124001 TRANSISTOR DB-1124 DTC114EKA T146 Q464 1
AT560ZHBAE BDBN1231124 TRANSISTOR DB-1231 3DG471A Q331 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q010 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q019 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q020 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q022 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q023 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q024 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q027 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q152 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q207 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q211 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q213 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q215 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q216 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q218 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q219 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q220 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q223 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q225 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q226 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q227 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q229 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q230 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q231 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q233 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q335 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q336 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q337 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q338 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q413 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q451 1
AT560ZHBAE BDBN1266001 TRANSISTOR DB-1266 DTC143ZKA T146 Q452 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q159 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q232 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q301 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q304 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q307 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q309 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q312 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q313 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q314 1
AT560ZHBAE BDBN1267001 TRANSISTOR DB-1267 DTA114YKA T146 Q328 1
24.08.2009 Bill of material 11/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BDCK0210303 FIELD EFFECT TRANSISTOR DC-310 2SK210-GR(TE85L,F) Q002 1
AT560ZHBAE BDCK0210303 FIELD EFFECT TRANSISTOR DC-310 2SK210-GR(TE85L,F) Q009 1
AT560ZHBAE BDEG2769003 INTEGRATED CIRCUIT BU2630F-E2 IC401 1
AT560ZHBAE BDEG3654003 INTEGRATED CIRCUIT NJM12904M-TE3--#ZZZB IC003 1
AT560ZHBAE BDEG3654003 INTEGRATED CIRCUIT NJM12904M-TE3--#ZZZB IC131 1
AT560ZHBAE BDEG3654003 INTEGRATED CIRCUIT NJM12904M-TE3--#ZZZB IC202 1
AT560ZHBAE BDEG3654003 INTEGRATED CIRCUIT NJM12904M-TE3--#ZZZB IC402 1
AT560ZHBAE BDEG4219003 INTEGRATED CIRCUIT NJM4558M-TE3-#ZZZB IC451 1
AT560ZHBAE BDEG4219003 INTEGRATED CIRCUIT NJM4558M-TE3-#ZZZB IC452 1
AT560ZHBAE BDEG4222003 INERGRATED CIRCUIT TK83361MTL-G IC002 1
AT560ZHBAE BDEG4251003 INTEGRATED CIRCUIT RH5RL50AA-T1-FA IC304 1
AT560ZHBAE BDEG4454003 INTEGRATED CIRCUIT NJM2746M-TE1-#ZZZB IC001 1
AT560ZHBAE BDEG4458003 INTEGRATED CIRCUIT NJM13403V-TE1-#ZZZB IC403 1
AT560ZHBAE BDEG4622003 INTEGRATED CIRCUIT AT24C02BN-10SU-1.8-SL383 IC302 1
AT560ZHBAE BDEG4680003 INTEGRATED CIRCUIT XC6109C43ANR IC303 1
AT560ZHBAE BDEG4807003 INTEGRATED CIRCUIT TC4S66F(TE85L,F) IC453 1
AT560ZHBAE BDEG4807003 INTEGRATED CIRCUIT TC4S66F(TE85L,F) IC454 1
AT560ZHBAE BDEG4808001 INTEGRATAD CIRCUIT UPD78F0058GK-9EU-A IC301 1
AT560ZHBAE BDEG4809003 INTEGRATED CIRCUIT NJM2594M-TE1-#ZZZB IC271 1
AT560ZHBAE BFLG0852001 FILTER:CERAMIC FL-852 LTS455HTW FT003 1
AT560ZHBAE BFLG1087001 FILTER:CRYSTAL FL-1087 10M07AZ FT001 1
AT560ZHBAE BFLG1132001 FILTER:CRYSTAL FL-1132 10M04DS FT002 1
AT560ZHBAE BJKG1249003 JACK JK-1249 IMSA-9210B-1-03Z058-PT1 J301 1
AT560ZHBAE BJKG1310001 JACK:EARPHONE JK-1310 PJ-305C J001 1
AT560ZHBAE BJKG1435001 JACK:MIC JK-1435 EJM-3-0125N J003 1
AT560ZHBAE BLBG1225001 COIL LB-1225 #7002BE-A0026HM L017 1
AT560ZHBAE BLBG1237001 COIL LB-1237 KS2579N L003 1
AT560ZHBAE BLBG1239001 COIL LB-1239 KS2585N L004 1
AT560ZHBAE BLBG1252001 COIL LB-1252 KS2562RC L007 1
AT560ZHBAE BLBG1263001 COIL LB-1263 L273 1
AT560ZHBAE BLBG1263001 COIL LB-1263 L275 1
AT560ZHBAE BLBG1263001 COIL LB-1263 L401 1
AT560ZHBAE BLBG1263001 COIL LB-1263 L405 1
AT560ZHBAE BLBG1266001 COIL LB-1266 L005 1
AT560ZHBAE BLBG1266001 COIL LB-1266 L006 1
AT560ZHBAE BLBG1268001 COIL LB-1268 L002 1
AT560ZHBAE BLBG1268001 COIL LB-1268 L214 1
AT560ZHBAE BLBG1268001 COIL LB-1268 L215 1
AT560ZHBAE BLBG1269001 COIL LB-1269 L014 1
AT560ZHBAE BLBG1270001 COIL LB-1270 L271 1
AT560ZHBAE BLBG1271001 COIL LB-1271 L008 1
AT560ZHBAE BLBG1272001 COIL LB-1272 L015 1
AT560ZHBAE BLBG1272001 COIL LB-1272 L016 1
AT560ZHBAE BLBG1273001 COIL LB-1273 L009 1
AT560ZHBAE BLBG1273001 COIL LB-1273 L151 1
AT560ZHBAE BLBG1274001 COIL LB-1274 L402 1
AT560ZHBAE BLDG0087001 COIL LD-087 L5RH3X5X1 L018 1
AT560ZHBAE BLDG0087001 COIL LD-087 L5RH3X5X1 L020 1
AT560ZHBAE BLDG0087001 COIL LD-087 L5RH3X5X1 L022 1
AT560ZHBAE BLDG0087001 COIL LD-087 L5RH3X5X1 L023 1
AT560ZHBAE BLDG0087001 COIL LD-087 L5RH3X5X1 L208 1
24.08.2009 Bill of material 12/29
ASSY CODE PARTS CODE DESCRIPTION SPEC REF NO QTY REMARKS RP REP1 REP2
AT560ZHBAE BLDG0087001 COIL LD-087 L5RH3X5X1 L210 1
AT560ZHBAE BLDG0252001 COIL LD-252 3A1737RH L501 1
AT560ZHBAE BLDG0252001 COIL LD-252 3A1737RH L502 1
AT560ZHBAE BLDG0332001 COIL LD-332 TRM-499 L220 1
AT560ZHBAE BLDG0332001 COIL LD-332 TRM-499 L221 1
AT560ZHBAE BLDG0348001 COIL LD-348 7B2-TRB-18◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
