Image preview - the first page of the document
APPENC


>> Download APPENC documenatation <<

Text preview - extract from the document
                                                                          C
                                                                         Appendix



FRU Parts Listing

This appendix provides you with the field replaceable unit (FRU) parts listing of the A360
Series. Refer to this appendix whenever ordering for spare parts or requesting for RMA
(Returned Merchandise Authorization) number.

                      FRU                   FIC Part Number
   CPU MODUL FCE -PGA 866MHZ                  01-10418-01
   CPU MODULE FC  -PGA 933MHZ                 01-10409-01
   CPU MODULE FC  -PGA 1GBMHZ                 01-10410-01
   CPU MODULE FC  -PGA 1.13GBMHZ              01-10820-00
   CPU CELERON  -700                          01-10407-01
   CPU CELERON  -733                          01-10429-01
   CPU CELERON  -766                          01-10430-01
   CPU CELERON  -800                          01-10818-00
   CPU CELERON  -819                          01-10819-00
   SDRAM Apacer 64MB(PC133)
          -M                                  02-33007-00
   SDRAM Pan Ram 64MB(PC133)
          -M                                  02-32060-03
   SDRAM Apacer 128MB(PC133)
          -M                                  02-33007-01
   SDRAM Pan Ram 128MB(PC133)
          -M                                  02-33004-01
   SDRAM Pan Ram 256MB(PC133)
          -M                                  02-33004-03
   Module- CD-ROM 24X QSI                     25-02396-00
                             CD-ROM 24X QSI   23-40295-00
                        CD-ROM BRACKET L1     24-50823-00
                    PLASTIC CD
                           -M -ROM PANEL      80-40423-00
   Module- CD-ROM 24X MKE                     25-02396-10
                            CD-ROM 24X MKE    23-40280-02
                        CD-ROM BRACKET L1     24-50823-00
                    PLASTIC CD
                           -M -ROM PANEL      80-40424-00
   Modu - DVD-ROM 8X QSI
       le                                     25-02397-00
                            DVD-ROM 8X QSI    23-40293-00
                        CD-ROM BRACKET L1     25-50823-00
           CD-ROM CYBERLINK POWER DVD SW 24-70110-20
                  PLASTIC DVD
                         -M     -ROM PANEL    80-40425-00




FIC A360 Series Service Manual                                                           C-1
                        FRU Parts Listing

                       FRU                        FIC Part Number
  Module - DVD-ROM 8X MKE                             25-02397-10
                             DVD-ROM 8X MKE           23-40319-00
                           CD-ROM BRACKET L1          25-50823-00
          CD-ROM CYBERLINK POWER DVD SW               24-70110-20
                  PLASTIC-M DVD-ROM PANEL             80-40426-00
  Module - CD-RW MKE                                  25-02398-00
                 DVD-ROM 8XW/4XW/24X MKE              23-40233-13
                           CD-ROM BRACKET L1          24-50823-00
             S/W ADAPTEC EASY CD CREATOR              26-00975-03
                     PLASTIC-M CD-RW PANEL            80-40427-00
  Module - CD-RW SONY                                 25-02398-20
                        CD-RW 8XW/20XR SONY           23-40323-02
                           CD-ROM BRACKET L1          24-50823-00
             S/W ADAPTEC EASY CD CREATOR              26-00975-03
                     PLASTIC-M CD-RW PANEL            80-40428-00
  Module HDD _10 GB _HIT                              25-02394-00
                                HDD 10GB HIT          23-20723-00
                                HDD BRACKET           24-51297-00
                                     F-CABLE          22-21104-00
  Module HDD _10 GB _FUJ                              25-02394-10
                                HDD 10GB FUJ          23-20725-00
                                HDD BRACKET           24-51297-00
                                     F-CABLE          22-21104-00
  Module HDD _10 GB _IBM                              25-02394-20
                                HDD 10GB IBM          23-20740-00
                                HDD BRACKET           24-51297-00
                                     F-CABLE          22-21104-00
  Module HDD _20 GB _HIT                              25-02395-00
                                HDD 20GB HIT          23-20726-00
                                HDD BRACKET           24-51297-00
                                     F-CABLE          22-21104-00
  Module HDD _20 GB _FUJ                              25-02395-10
                                HDD 20GB FUJ          23-20728-00
                                HDD BRACKET           24-51297-00
                                     F-CABLE          22-21104-00




C-2                                            FIC A360 Series Service Manual
                         FRU Parts Listing

                        FRU                         FIC Part Number
  Module HDD _20 GB _IBM                              25-02395-20
                                   HDD 20GB IBM       23-20741-00
                                   HDD BRACKET        24-51297-00
                                        F-CABLE       22-21104-00
  Battery Pack NI-MH 3800MA                           21-91081-00
  Module-FAX_MODEM US                                 71-40103-00
  Module-FAX_MODEM EUR                                71-40104-00
  Module-FAX_MODEM UK                                 71-40105-00
  Battery Pack NI-MH 4500MA                           21-91082-00
  Battery Pack LI-LON 3800MA                          21-91083-00
  FAX/MODEM MODULE                                    71-40170-00
  LAN MODULE                                          71-40172-00
  COMBO MODULE                                        71-40195-00
  Main Module                                            N/A
                                       Main Board     51-70650-XX
                       BOTTOM CASE FDD Module         80-40419-00
                                 Module TOP CASE      80-40420-00
                                       K/B Cover      80-40422-00
                                      TOP PLATE       80-50122-00
                                W/O CARE COVER        24-42293-00
                                 SPEAKER COVER        24-42260-00
  Audio DJ/SW Module                                  80-00058-00
                     F-CABLE FFC FOR AUDIO-DJ         22-21101-00
                       CASE BUTTON AUDIO-DJ-R         24-42137-00
                       CASE BUTTON AUDIO-DJ-L         24-42138-00
                CASE BUTTON AUDIO-DJ (ON/OFF)         24-42139-00
                                 AUDIO DJ COVER       80-40464-00
                       RUBBER AUDIO-DJ BTTON          24-82341-00
                                DJ SWITCH BOARD       51-70656-00
  Module FDD_NEC                                      25-02413-00
                                    FDD 3.5" NEC      23-10274-00
                                F-CABLE FDD FPC       22-21102-00
                                     FDD PLATE        24-51299-00




FIC A460Series Service Manual                                         C-3
                        FRU Parts Listing

                       FRU                             FIC Part Number
  Module PALM REST                                         25-02399-00
             F-CABLE GLIDE PAD TO SW CABLE                 22-21099-00
             F-CABLE GLIDE PAD TO M/B CABLE                22-21100-00
                                       FRAME G/P           24-51298-00
                                     GLIDE PAD/B           51-71080-21
                                       GLIDE PAD           71-20186-00
                  PLASTIC-M PALM-REST Module               80-40421-00
  Module LCD TFT 12.1" Hann Star                           56-10450-00
                              LCD 12.1" Hann Star          71-10582-00
                                       INVETER/B           12-01368-01
                                     CABLE INVT.           22-10680-00
                           LCD MICRO-COAXIAL               22-10691-00
                             LCD BEZEL COVER               80-40415-00
                              LCD COVER BACK               80-40418-00
                                   FRAME HINGE-R           24-51308-00
                                   FRAME HINGE-L           24-51307-00
                             FRAME BRACKET R               24-51294-00
                             FRAME BRACKET L               24-51293-00


  Module LCD TFT 13.3" ADT                                 56-10451-00
                                    LCD 13.3" ADT          71-10546-03
                                       INVETER/B           12-01368-01
                           LCD MICRO-COAXIAL               22-10660-00
                             LCD BEZEL COVER               80-40416-00
                              LCD COVER BACK               80-40418-00
                                   FRAME HINGE-R           24-51308-00
                                   FRAME HINGE-L           24-51307-00
                             FRAME BRACKET R               24-51292-00
                             FRAME BRACKET L               24-51291-00
  Module LCD TFT 14.1" ADT                                 56-10463-00
                                    LCD 14.1" ADT          71-10574-01
                                       INVETER/B           12-01368-01
                           LCD MICRO-COAXIAL               22-10732-00
                             LCD BEZEL COVER               80-40417-00
                              LCD COVER BACK               80-40418-00
                                   FRAME HINGE-R           24-51308-00
                                   FRAME HINGE-L           24-51307-00


C-4                                                 FIC A360 Series Service Manual
                         FRU Parts Listing

                        FRU                         FIC Part Number
  Module LCD TFT 14.1" CPT                            56-10452-00
                                    LCD 14.1" CPT     71-10547-02
                                      INVETER/B       12-01368-01
                            LCD MICRO-COAXIAL         22-10693-00
                                LCD BEZEL COVER       80-40417-00
                                LCD COVER BACK        80-40418-00
                                  FRAME HINGE-R       24-51308-00
                                  FRAME HINGE-L       24-51307-00
  AC ADAPTOR (3 PIN)                                  12-01305-21
  Keyboard(US)                                        71-30411-00
  Keyboard(UK)                                        71-30411-02
  Keyboard(JAP)                                       71-30411-03




FIC A460Series Service Manual                                         C-5
