Image preview - the first page of the document



>> Download MRV700VR17_Magnavox_DVDR600_Philips documenatation <<

Text preview - extract from the document

                                                                                                        CAUTION
                                                                                                                                                                                           CAUTION !
                                                                                           F            FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,
                                                                                                                                                                                           Fixed voltage ( or Auto voltage selectable ) power supply circuit is used in this unit.
                                                                                                        REPLACE ONLY WITH THE SAME TYPE FUSE.
                    NOTE :                                                             A       V                                                                                           If Main Fuse (F1001) is blown, check to see that all components in the power supply
                                                                                                        ATTENTION : POUR UNE PROTECTION CONTINUE LES RISQES
                    The voltage for parts in hot circuit is measured using                                                                                                                 circuit are not defective before you connect the AC plug to the AC power supply.
                                                                                                        D'INCELE N'UTILISER QUE DES FUSIBLE DE MEMO TYPE.
                    hot GND as a common terminal.                                                                                                                                          Otherwise it may cause some components in the power supply circuit to fail.
                                                                                                        RISK OF FIRE -REPLACE FUSE AS MARKED.
                    "    " = SMD                                                                            "This symbol means fast operating fuse."
                                                                                                            "Ce symbole repr
