Fig.6: Install the parts on the PC board as shown here but don't install IC2 or IC3 until after the initial checks described in
the text have been made.

detected a problem. In that case, go to the   are supplied with these sockets. As           metal panel, thereby short-circuiting
"Fault Codes" panel to find out what to       shown in Fig.7, these must be installed       them! Also refer to Fig.11 for correct
check for.                                    between the lugs and the front panel, not     socket mounting.
  At this point, you can mount the test       under the tops of the sockets. Many con-        Next, mount the pushbutton switch,
lead sockets onto the front panel
