Image preview - the first page of the document
>> Download Guildline7350datasheet documenatation <<Text preview - extract from the document 7350 Series
Precision AC and DC Current Shunts
High Stability, Wide Range Precision AC/DC Current Calibration Standards
GUILDLINE INSTRUMENTS 7350 SERIES of four-terminal AC
Current Shunts are designed as higher accuracy and stability
replacements of the successful 7320 series. These patent pending
shunts have a non-inductive design. With a ruggedized and
shielded enclosure, the 7350 series shunts are constructed with
very small values of reactance. They are ideal for use over a wide
frequency range from DC to 100 kHz with low uncertainty (high
accuracy), low temperature coefficients and excellent stability.
To suit a wide range of customers and applications, the 7350 Series
shunts provide power dissipation capability of up to 10 Watts and a
maximum current capability up to 25A. For best performance, the
model 73401 Forced Convection Unit is available for forced air-
cooling.
The AC Current Shunts can be used for a variety of AC/DC current
measurement applications and have a nominal impedance range
of 0.01 to 1000 . Applications include the accurate
measurement of AC current, calibration of AC current ranges of
multi-function calibrators, high accuracy DVM's and
7350 SERIES FEATURES Transconductance amplifiers, as well as providing a traceable
current signal from a traceable voltage standard from DC to 100
kHz. These new shunts are designed to be purely resistive with
Uncertainties Low as
