Image preview - the first page of the document
>> Download Guildline9211BDatasheet documenatation <<
Text preview - extract from the document
Model 9211B
New and Improved - Multi-Tap, 300A
Precision DC Current Shunt
World's Best Selling Precision Multiple Value DC Current Shunt
GUILDLINE INSTRUMENTS 9211B DC PRECISION CURRENT
SHUNT continues to improve the world's most widely
fielded multi-tap shunt available, the model 9211A.
Like the model 9211A, the 9211 "B" Version is a four-
terminal precision shunt designed to measure current in
nine ranges from 10 A to 300 A while continuing to
provide the same, high performance specifications.
Voltage output at full rated current on all ranges is 0.1
volt. The 9211B is now available in either a bench
version or a rack mount version.
New style cable connections are accessible on the front
panel allowing for quick, secure and repeatable lead
changes. The 9211B bench model now comes with side
handles and can easily be converted to a rack mount
unit. Improved markings allow operators to easily
determine current ranges and ohmic values. And a new
style case replaces the old formic case. This new case is
designed to vastly improve air flow across the resistive
elements.
Separate current and potential terminals are provided.
9211B FEATURES Range selection is made by means of two brass plugs
inserted in pairs on the panel.
Accuracy Low as ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
