Image preview - the first page of the document
>> Download _INCOMPLETE_Guildline50103Datasheet documenatation <<
Text preview - extract from the document
Model 50103
Over-Under Temperature Protector
Added Protection For Sensitive Equipment
G uildline 50103 Over-Under Temperature Protector serves
to protect fixed-temperature or programmable-
temperature fluid baths from straying out of a pre-defined
temperature range due to a malfunction of the bath
temperature control.
This protection device requires a free space on a flat surface of
40 cm (16 in.) wide by 25 cm (10 in.) deep, and within 3 m (10
ft.) of the fluid bath. The power cord from the fluid bath is
plugged into the BATH POWER receptacle of the 50103, which
in turn is plugged into a suitable 120 VAC line or output
receptacle of the 50101 Voltage adapter.
The Model 50103 is capable of connecting or disconnecting up
to a 15 A resistive load or up to a 1/3 HP inductive load.
The 50103 provides a second levelof control and
protection for sensitive equipment operating in
50103 Features the 5010 fluid bath.
> Current Rating 15A, 1/3 HP The Hampshire Controls T0 Sentry Model 125 Digital Alarm
> 0 0
Temperature Range -50 C to +50 C Module provides temperature monitoring. This monitoring
module operates over a temperature range of -50 0C to +50 0C.
> Protection completely independent of bath The lower and upper alarm limits have been factory set to 20 0C
controls and 30 0C respectively. The operation of the T0 Sentry is
> Visual status indicators covered in the Hampshire Controls T0 Sentry Model 125 Digital
Alarm Module Operating Instructions Manual.
50103 Over-Under Temperature Protector
50103 Specifications
Monitoring Temperature: Range -50 0 C to +50 0C
Resolution 0.1 0C
