   Global LCD Panel Exchange Center           www.panelook.com




                          SPECIFICATIONS FOR
                             LCD MODULE


                      CUSTOMER

             CUSTOMER PART NO.

                AMPIRE PART NO.                          AM-1024768G1TMQW-00H


                  APPROVED                 BY

                            DATE
            Approved For Specifications
            Approved For Specifications & Sample

             AMPIRE CO., LTD.
             4F., No.116, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221,
             Taiwan (R.O.C.)
             22181                                 116    4


                APPROVED BY                     CHECKED BY                 ORGANIZED BY




           Date : 2010/10/17                   AMPIRE CO., LTD.                               1



One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




                                      RECORD        OF    REVISION

            Revision Date Page                            Contents                        Editor
              2011/10/17        -                       New Release                       Rober




           Date : 2010/10/17                   AMPIRE CO., LTD.                               2



One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




           1. FEATURES
             AM-1024768G model is a 12.1" TFT-LCD module with a white LED Backlight Unit
           and a 20-pin 1ch-LVDS interface. This module supports 1024 x 768 XGA mode and
           diaplays 262k\16.2M colors. The converter for the Backlight Unit is built in.

           - Wide Viewing angle
           - High contrast ratio
           - Fast response time
           - XGA (1024 x 768 pixels) resolution
           - Wide operating temperature
           - DE (Data Enable) mode
           - LVDS (Low Voltage Differential Signaling) interface
           - Reversible-scan direction
           - RoHS Compliance
           - Lamp Replaceable


           APPLICATIONS
           - TFT LCD Monitor
           - Industrial Application
           - Amusement
           - Vehicle




           Date : 2010/10/17                   AMPIRE CO., LTD.                               3



One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
   Global LCD Panel Exchange Center           www.panelook.com




           2. PHYSICAL SPECIFICATIONS

                              Item                      Specifications               Unit     Note

                Active area                         245.76 (H)
