Image preview - the first page of the document
![Panel_AUO_A150XN01_V0_0_[DS]](/pics/5c36ac9742d33.gif)
>> Download Panel_AUO_A150XN01_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification A150XN01 V0
AU OPTRONICS CORPORATION
( V ) Preliminary Specification
( ) Final Specification
Module 15" XGA TFT-LCD Semi-Module
Model Name A150XN01 V0
Checked &
Customer Date Date
Approved by
FY Gan 03/18/2008
Approved by Prepared by Date
Joyce Kuo 03/18/2008
Note: This Specification is subject to change without Audio-Video Display Business Unit /
notice. AU Optronics corporation
document version 0.3 1/23
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification A150XN01 V0
AU OPTRONICS CORPORATION
Contents
Handling Precautions ...................................................................................................................... 4
2. General Description ..................................................................................................................... 5
2.1 Display Characteristics ........................................................................................................................ 5
3. Functional Block Diagram........................................................................................................... 8
4. Absolute Maximum Ratings........................................................................................................ 9
4.1 Absolute Ratings of TFT LCD Module ............................................................................................... 9
4.2 Absolute Ratings of Backlight Unit ..................................................................................................... 9
4.3 Absolute Ratings of Environment ...................................................................................................... 10
5. Electrical characteristics ..........................................................................................................11
5.1 TFT LCD Module ............................................................................................................................. 11
6. Signal Characteristic .................................................................................................................13
6.1 Pixel Format Image ........................................................................................................................... 13
6.2 The Input Data Format ...................................................................................................................... 14
6.4 Interface Timing................................................................................................................................. 16
6.5 Color Input Data Reference ............................................................................................................... 18
6.6 Power ON/OFF Sequence................................................................................................................. 19
7. Connector & Pin Assignment ...................................................................................................20
7.1 TFT LCD Module ............................................................................................................................. 20
8. Reliability Test ............................................................................................................................21
9. Outline Drawing..........................................................................................................................22
10. Packing Form............................................................................................................................23
document version 0.3 2/23
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification A150XN01 V0
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description
0.1 2007/04/19 All First Draft All
9 4.1 Absolute Ratings of TFT LCD module:
4.1 Absolute Ratings of TFT LCD module: Logic
Logic LCD drive voltage VDD 0.3(min),
0.2 2007/04/25 LCD drive voltage VDD -0.3(min), 4.0(Max)
3.6(Max)
Add 6.5 Color Input Data Reference
18 --
5 2.1 Cell transmittance, Power consumption, 2.1 Cell transmittance: (8.8), Power consumption:
Weight : TBD 2.5, Weight: 315
6 2.2 Cell transmittance: TBD 2.2 Cell transmittance: (8.8)
10 4.3 Absolute Ratings of Environment TOP, TST 4.3 Absolute Ratings of Environment TOP 65C,
TBD TST 80C
0.3 2007/09/27
11 5.1.1 IDD, Irush, PDD TBD 5.1.1 IDD: 750, Irush:930, PDD: 2.5
12 5.1.2 VID, VICM spec 5.1.2 VID: 250(min), 350(typ), 450(Max). VICM:
1.0(min), 1.25(typ), 2(Max)
22 9. Outline Drawing 9. Update Outline Drawing
23 10. Packing Form 10. Update Packing Form
0.4 2008/02/27 22 9. outline drawing 9. update outline drawing
11 VDD current =750mA Updated VDD current =600mA
12,13 --- Add LVDS Setup/Hold time
0.5 2008/03/18
Add Cycle Jitter
Add Clock Cycle Rate of Change
0.6 2008/ 6 Transmittance min.: NA Transmittance min.: 7.8%
document version 0.3 3/23
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification A150XN01 V0
AU OPTRONICS CORPORATION
Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
9) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no bending/twisting
forces are applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
document version 0.3 4/23
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification A150XN01 V0
AU OPTRONICS CORPORATION
2. General Description
This specification applies to the 15 inch Color TFT-LCD Semi-Module A150XN01 V0
The display supports the XGA (1024(H) x 768(V)) screen format and 16.2M colors. All input signals are 1 Channel LVDS
interface compatible.
This module does not contain the backlight.
.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Active Area [mm] 304.128 (H) x 228.096
Pixels H x V 1024(x3) x 768
Pixel Pitch [mm] 0.297 (per one triad) x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN mode, Normally White
Cell Transmittance [%] (8.8)
Contrast Ratio 500:1
Optical ResponseTime [msec] 12 (Typ, on/off)
Nominal Input Voltage VDD [Volt] +3.3 (Typ)
Power Consumption(Black Pattern) [Watt] 2.5 (Typ)
Weight [Grams] 315 (Typ)
Physical Size (H x V x D) [mm] 316.23(W) x 242.55(H) x 1.9(D) (Typ)
Electrical Interface one Channel LVDS
Surface Treatment Glare type, Hardness 3H
Support Colors 16.2M colors (RGB 6-bits+FRC)
RoHS Compliance RoHS Compliance
document version 0.3 5/23
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification A150XN01 V0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 80
-
CR > 10 (Left) 80
Viewing Angle [degree] 1
Vertical (Up) 80
-
CR > 10 (Down) 80
Optical Response Time [msec] Rising + Falling 12 3
Color / Chromaticity White x 0.310
Coordinates 2
(CIE 1931) White y 0.330
Cell Transmittance
(At CCFL= mA) [% ] (7.8) (8.8) - 2
Contrast Ratio 500:1 - 4
Optical Equipment: BM-5A, BM-7, PR880, or equivalent
Note 1: Definition of viewing angle
