Image preview - the first page of the document
![Panel_AUO_B131HW02_V0_1_[DS]](/pics/5c36acdc3cf71.gif)
>> Download Panel_AUO_B131HW02_V0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V ) Final Specifications
Module 13.1" FHD 16:9 Color TFT-LCD
with LED Backlight design
Model Name B131HW02 V0 (H/W:0A)
Note LED Backlight with driving circuit design
Customer Date Approved by Date
WesHsiang Lo 2011/11/04
Checked &
Date Prepared by Date
Approved by
Michael WJ Sun 2011/11/04
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B131HW02 V0 Document Version : 1.2 1 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .............................................................. 4
2. General Description................................................................. 5
2.1 General Specification ..................................................................................................................... 5
2.2 Optical Characteristics.................................................................................................................... 6
3. Functional Block Diagram...................................................... 11
4. Absolute Maximum Ratings ................................................... 12
4.1 Absolute Ratings of TFT LCD Module..........................................................................................12
4.2 Absolute Ratings of Environment ..................................................................................................12
5. Electrical Characteristics ....................................................... 13
5.1 TFT LCD Module .........................................................................................................................13
5.2 Backlight Unit ...............................................................................................................................14
6. Signal Interface Characteristic .............................................. 14
6.1 Pixel Format Image .......................................................................................................................14
6.2 Integration Interface Requirement .................................................................................................15
6.3 Interface Timing ............................................................................................................................17
6.4 Power ON/OFF Sequence .............................................................................................................19
7. Panel Reliability Test............................................................. 20
7.1 Reliability Test ..............................................................................................................................20
8. Mechanical Characteristics .................................................... 21
8.1 LCM Outline Dimension ...............................................................................................................21
9. Shipping and Package ........................................................... 23
9.1 Shipping Label Format ..................................................................................................................23
9.2 Carton Package.............................................................................................................................24
9.3 Shipping Package of Palletizing Sequence .....................................................................................25
10. Appendix ............................................................................. 26
10.1 EDID Description .......................................................................................................................26
B131HW02 V0 Document Version : 1.2 2 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/09/01 All First Edition for Customer
0.2 2010/10/18 26 Old EDID setting New EDID setting Revised
1.0 2010/12/17 All N/A Final Spec
1.1 2011/08/30 5 Glass Thickness: 0.5mm Glass Thickness: 0.21mm*2=0.42mm Revised
1.2 2011/11/04 12 Max Current capacity = 4.0A
1.2 2011/11/04 12 Max LED input reverse voltage = 5V
1.2 2011/11/04 12 Max LED input forward current = 30mA
B131HW02 V0 Document Version : 1.2 3 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input
connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration
or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate
nor tilt the Interface Connector of the TFT Module.
11)After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock,
DO NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT
module that a LED light bar build in as a light source of back light unit. It can prevent
electrostic breakdown.
B131HW02 V0 Document Version : 1.2 4 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B131HW02 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD
panel, a driver circuit, and LED backlight system. The screen format is intended to support
the 16:9 HD, 1920(H) x1080(V) screen and 16.7M colors (RGB 24-bits data driver) with LED
backlight driving circuit. All input signals are display port interface compatible.
B131HW02 V0 is designed for a display unit of notebook style personal computer and
industrial machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 331.76
Active Area [mm] 289.152X162.648
Pixels H x V 1920x3(RGB) x 1080
Pixel Pitch [mm] 0.1506X0.1506
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=19mA) [cd/m2] 300 typ. (5 points average, gamma correction
(Note: ILED is LED current) off)
210 min. (5 points average, gamma correction
off)
Luminance Uniformity 1.82 max. (9 points)
Contrast Ratio 500 typ
Response Time [ms] 16 typ/ 30 Max (gamma correction off)
Nominal Input Voltage VDD [Volt] +2.5 typ.
Power Consumption [Watt] 4.65 typ. (Include Logic and Blu power)
Weight [Grams] 158 typ.
Physical Size [mm] Min. Typ. Max.
Include bracket & PCBA Length 298.6 299.1 299.6
Width 183.8 184.3 184.8
Thickness 2.35 2.99
Electrical Interface eDP 2Lane
Glass Thickness [mm] 0.21mm*2=0.42mm
Surface Treatment Anti-Glare, Hardness 4H,
B131HW02 V0 Document Version : 1.2 5 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Support Color 16.7M colors ( RGB 24-bit )
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
White Luminance 5 points average 2
210 300 - cd/m 1, 4, 5.
ILED=19mA
R Horizontal (Right) 40 55 -
degree
L CR = 10 (Left) 40 55 -
Viewing Angle 4, 9
H Vertical (Upper) 30 50 -
L CR = 10 (Lower) 40 55 -
Luminance Uniformity 9P 9 Points - - 1.82 2, 3, 4
Contrast Ratio CR 300 500 - 4, 6
Cross talk % TBD 4, 7
Tr Rising - 3 6
Response Time Tf Falling - 13 24 msec 4, 8
TRT Rising + Falling - 16 30
Rx 0.639 0.685 0.731
Red
Ry 0.283 0.338 0.394
Gx 0.184 0.230 0.276
Color / Green
Gy 0.642 0.697 0.753
Chromaticity
Coodinates Bx CIE 1931 0.109 0.155 0.201 4
Blue
By 0.020 0.076 0.131
Wx 0.268 0.311 0.353
White
Wy 0.278 0.332 0.387
Adobe % - 96 -
B131HW02 V0 Document Version : 1.2 6 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 9 points position (Ref: Active area)
Note 3: The luminance uniformity of 5 or 9 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W9 =
Minimum Brightness of thirteen points
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature
change during measuring. In order to stabilize the luminance, the measurement should be executed after
lighting Backlight for 60 minutes in a stable, windless and dark room, and it should be measured in the center
B131HW02 V0 Document Version : 1.2 7 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
of screen.! !
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
CT = | YB ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
