Image preview - the first page of the document
![Panel_AUO_B131RW02_V0_0_[DS]](/pics/5c36acdf780c9.gif)
>> Download Panel_AUO_B131RW02_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V) Final Specifications
Module 13.1" HD+ 16:9 Color TFT-LCD
with LED Backlight design
Model Name B131RW02 V0 (H/W:0A)
Note LED Backlight with driving circuit design
Customer Date Approved by Date
Allen KC Huang 2010/12/17
Checked &
Date Prepared by Date
Approved by
Tony Kao 2010/12/17
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B131RW02 V0 Document Version : 1.0 1 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 General Specification .......................................................................................................................... 5
2.2 Optical Characteristics ........................................................................................................................ 6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module............................................................................................. 12
4.2 Absolute Ratings of Environment ..................................................................................................... 12
(OHFWULFDO &KDUDFWHULVWLFV
5.1 TFT LCD Module ............................................................................................................................. 13
5.2 Backlight Unit ................................................................................................................................... 14
6LJQDO ,QWHUIDFH &KDUDFWHULVWLF
6.1 Pixel Format Image ........................................................................................................................... 15
6.2 Integration Interface Requirement..................................................................................................... 15
6.3 Interface Timing ................................................................................................................................ 17
6.4 Power ON/OFF Sequence ................................................................................................................. 19
3DQHO 5HOLDELOLW7 HVW
7.1 Reliability Test .................................................................................................................................. 20
0HFKDQLFDO &KDUDFWHULVWLFV
8.1 LCM Outline Dimension .................................................................................................................. 21
0 6KLSSLQJ DQG 3DFNDJH
9.1 Shipping Label Format...................................................................................................................... 23
9.2 Carton Package.................................................................................................................................. 24
9.3 Shipping Package of Palletizing Sequence ....................................................................................... 25
$SSHQGL[
10.1 EDID Description............................................................................................................................ 26
B131RW02 V0 Document Version : 1.0 2 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/09/01 All First Edition for Customer
1.0 2010/12/17 All N/A Final Spec
5 Pixel Pitch 0.1506X0.1506 Pixel Pitch 0.18075X0.18075 Revised
5 Glass Thickness:0.21mm Glass Thickness:0.21mm*2=0.42mm Revised
22 No shipping label weidth value Fill shipping label weidth: 23mm Revised
B131RW02 V0 Document Version : 1.0 3 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt
the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for example),
do not twist nor bend the TFT Module even momentary. At designing the enclosure, it
should be taken into consideration that no bending/twisting forces are applied to the TFT
Module from outside. Otherwise the TFT Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock, DO
NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT module that a
LED light bar build in as a light source of back light unit. It can prevent electrostic breakdown.
B131RW02 V0 Document Version : 1.0 4 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B131RW02 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and LED backlight system. The screen format is intended to support the 16:9 HD,
1600(H) x900(V) screen and 262k colors (RGB 6-bits data driver) with LED backlight driving
circuit. All input signals are display port interface compatible.
B131RW02 V0 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 331.81
Active Area [mm] 289.2 X162.675
Pixels H x V 1600x3(RGB) x 900
Pixel Pitch [mm] 0.18075X0.18075
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=18mA) [cd/m2] 410 typ. (5 points average, gamma correction
(Note: ILED is LED current) off)
300 min. (5 points average, gamma correction
off)
Luminance Uniformity 1.82 max. (9 points)
Contrast Ratio 500 typ
Response Time [ms] 16 typ/ 30 Max (gamma correction off)
Nominal Input Voltage VDD [Volt] +2.5 typ.
Power Consumption [Watt] 3.81 typ. (Include Logic and Blu power)
Weight [Grams] 158 typ.
Physical Size [mm] Min. Typ. Max.
Include bracket & PCBA Length 298.6 299.1 299.6
Width 183.8 184.3 184.8
Thickness 2.35 2.99
Electrical Interface eDP 2Lane
Glass Thickness [mm] 0.21mm*2=0.42mm
Surface Treatment Anti-Glare, Hardness 4H,
Support Color 262K colors ( RGB 6-bit )
B131RW02 V0 Document Version : 1.0 5 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Temperature Range
Operating [oC] 0 to +50
o
Storage (Non-Operating) [ C] -20 to +60
RoHS Compliance TBD
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
White Luminance 5 points average 2
300 410 - cd/m 1, 4, 5.
ILED=18mA
R Horizontal (Right) 40 55 -
CR = 10 (Left) degree
L 40 55 -
Viewing Angle 4, 9
H Vertical (Upper) 30 50 -
L CR = 10 (Lower) 40 55 -
Luminance Uniformity 9P 9 Points - - 1.82 2, 3, 4
Contrast Ratio CR 300 500 - 4, 6
Cross talk % TBD 4, 7
Tr Rising - 3 6
Response Time Tf Falling - 13 24 msec 4, 8
TRT Rising + Falling - 16 30
Rx 0.609 0.653 0.697
Red
Ry 0.295 0.411 0.380
Gx 0.241 0.286 0.330
Color / Green
Gy 0.614 0.654 0.699
Chromaticity
Coodinates Bx CIE 1931 0.113 0.157 0.201 4
Blue
By 0.000 0.041 0.083
Wx 0.273 0.313 0.354
White
Wy 0.282 0.320 0.358
NTSC u',v' % - 104 -
B131RW02 V0 Document Version : 1.0 6 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 9 points position (Ref: Active area)
Note 3: The luminance uniformity of 5 or 9 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W9 =
Minimum Brightness of thirteen points
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting Backlight for
60 minutes in a stable, windless and dark room, and it should be measured in the center of screen.! !
B131RW02 V0 Document Version : 1.0 7 of 28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD Module
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
