Image preview - the first page of the document
![Panel_AUO_B133XTN01-0_0_[DS]](/pics/5c36acf65dec2.gif)
>> Download Panel_AUO_B133XTN01-0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( V ) Preliminary Specifications
( ) Final Specifications
Module 13.3"(13.25") HD 16:9 Color TFT-LCD
with LED Backlight design
Model Name B133XTN01.0 (H/W:0A)
Note LED Backlight with driving circuit design
Customer Date Approved by Date
Marcus Yen 2011/11/18
Checked &
Date Prepared by
Approved by
Doremi Fang 2011/11/18
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B133XTN01.0 Document Version : 0.1 1 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
2.1 General Specification .......................................................................................................................... 5
2.2 Optical Characteristics ........................................................................................................................ 6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module............................................................................................. 12
4.2 Absolute Ratings of Environment ..................................................................................................... 12
(OHFWULFDO &KDUDFWHULVWLFV
5.1 TFT LCD Module ............................................................................................................................. 13
5.2 Backlight Unit ................................................................................................................................... 15
6LJQDO ,QWHUIDFH &KDUDFWHULVWLF
6.1 Pixel Format Image ........................................................................................................................... 16
6.2 The Input Data Format ...................................................................................................................... 17
6.3 Integration Interface Requirement..................................................................................................... 18
6.4 Interface Timing ................................................................................................................................ 20
6.5 Power ON/OFF Sequence ................................................................................................................. 21
3DQHO 5HOLDELOLW7 HVW
7.1 Vibration Test .................................................................................................................................... 22
7.2 Shock Test ......................................................................................................................................... 22
7.3 Reliability Test .................................................................................................................................. 22
0HFKDQLFDO &KDUDFWHULVWLFV
8.1 LCM Outline Dimension .................................................................................................................. 23
S 6KL LQJ DQG 3DFNDJH
9.1 Shipping Label Format...................................................................................................................... 25
9.2 Carton Package.................................................................................................................................. 26
9.3 Shipping Package of Palletizing Sequence ....................................................................................... 27
/ $ HQGL[
10.1 EDID Description............................................................................................................................ 28
B133XTN01.0 Document Version : 0.1 2 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2011/11/18 All First Edition for Customer
B133XTN01.0 Document Version : 0.1 3 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt
the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for example),
do not twist nor bend the TFT Module even momentary. At designing the enclosure, it
should be taken into consideration that no bending/twisting forces are applied to the TFT
Module from outside. Otherwise the TFT Module may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock,
DO NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT
module that a LED light bar build in as a light source of back light unit. It can prevent
electrostic breakdown.
B133XTN01.0 Document Version : 0.1 4 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B133XTN01.0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel,
a driver circuit, and LED backlight system. The screen format is intended to support the 16:9
HD, 1366(H) x768(V) screen and 262k colors (RGB 6-bits data driver) with LED backlight
driving circuit. All input signals are LVDS interface compatible.
B133XTN01.0 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 336.6
Active Area [mm] 293.42 X 164.97
Pixels H x V 1366x3(RGB) x 768
Pixel Pitch [mm] 0.2148X0.2148
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=20mA) 200 typ. (5 points average)
[cd/m2]
(Note: ILED is LED current) 170 min. (5 points average)
Luminance Uniformity 1.25 max. (5 points)
Contrast Ratio 500 typ.
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 3.0 max. (Include Logic and BLU power)
Weight [Grams] 260 max.
Min. Typ. Max.
Length 313.6 314.1 314.6
Physical Size
[mm] Width 188.2 188.7 189.2
Include bracket
Thickness - - 3.0
(3.2 at PCB)
Electrical Interface 1 channel LVDS
Glass Thickness [mm] 0.4
Glare, Hardness 3H
Surface Treatment
Reflection 4.3%
Support Color 262K colors ( RGB 6-bit )
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
B133XTN01.0 Document Version : 0.1 5 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
White Luminance 5 points average 2
170 200 - cd/m 1, 4, 5.
ILED=20mA
R Horizontal (Right) 40 45 -
L CR = 10 (Left) 40 45 -
Viewing Angle degree 4, 9
H Vertical (Upper) 10 15 -
L CR = 10 (Lower) 30 35 -
Luminance
5P 5 Points - - 1.25 1, 3, 4
Uniformity
Luminance
13P 13 Points - - 1.60 2, 3, 4
Uniformity
Contrast Ratio CR 400 500 - 4, 6
Cross talk % 4 4, 7
Tr Rising - 3 -
Response Time Tf Falling - 5 - msec 4, 8
TRT Rising + Falling - 8 16
Rx 0.550 0.580 0.610
Red
Ry 0.305 0.335 0.365
Gx 0.300 0.330 0.360
Color / Green
Gy 0.535 0.565 0.595
Chromaticity
Coodinates Bx CIE 1931 0.125 0.155 0.185 4
Blue
By 0.110 0.140 0.170
Wx 0.283 0.313 0.343
White
Wy 0.299 0.329 0.359
NTSC % - 45 -
B133XTN01.0 Document Version : 0.1 6 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 13 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
10 10
10
1 2 3
H /4
4 5
H /4
H 6 7 8
H /4
9 10
H /4 11 12 13
10
Note 3: The luminance uniformity of 5 or13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W13 =
Minimum Brightness of thirteen points
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting Backlight for
30 minutes in a stable, windless and dark room. Measurement should be executed in the center of screen unless
otherwise noted. ! !
B133XTN01.0 Document Version : 0.1 7 of 30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD Module
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
