Image preview - the first page of the document
![Panel_AUO_B133XW02_V2_0_[DS]](/pics/5c36ad2032f45.gif)
>> Download Panel_AUO_B133XW02_V2_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V ) Final Specifications
Module 13.3" HD Color TFT-LCD
Model Name B133XW02 V2(H/W:3A)
Note ( ) LED Backlight with driving circuit design
Customer Date Approved by Date
Beyond Yang 2009/09/01
Checked &
Date Prepared by
Approved by
Vicki Chai 2009/09/01
Note: This Specification is subject to change NBBU Marketing Division /
without notice. AU Optronics corporation
B133XW02 V2 Document version: 1.1 1 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions........................................................................................... 4
2. General Description.............................................................................................. 5
2.1 General Specification......................................................................................................... 5
2.2 Optical Characteristics....................................................................................................... 6
3. Functional Block Diagram ................................................................................. 11
4. Absolute Maximum Ratings............................................................................... 12
4.1 Absolute Ratings of TFT LCD Module ............................................................................. 12
4.2 Absolute Ratings of Environment..................................................................................... 12
5. Electrical characteristics ................................................................................... 13
5.1 TFT LCD Module ............................................................................................................. 13
5.2 Backlight Unit................................................................................................................... 15
6. Signal Characteristic.......................................................................................... 16
6.1 Pixel Format Image.......................................................................................................... 16
6.2 The input data format....................................................................................................... 17
6.3 Integration Interface and Pin Assignment ........................................................................ 18
6.4 Interface Timing ............................................................................................................... 21
7. Connector Description ....................................................................................... 23
7.1 TFT LCD Module ............................................................................................................. 23
8. Vibration and Shock Test................................................................................... 24
8.1 Vibration Test ................................................................................................................... 24
8.2 Shock Test Spec: ............................................................................................................. 24
9. Reliability............................................................................................................. 25
10. Mechanical Characteristics ............................................................................. 26
10.1 LCM Outline Dimension................................................................................................. 26
10.2 Screw Hole Depth and Center Position ......................................................................... 27
11. Shipping and Package ..................................................................................... 28
11.1 Shipping Label Format................................................................................................... 28
11.2 Carton package.............................................................................................................. 29
11.3 Shipping package of palletizing sequence..................................................................... 29
12. Appendix: EDID description ............................................................................ 30
B133XW02 V2 Document version: 1.1 2 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
1.0 2009/07/21 All First Edition for Customer
1.1 2009/09/01 21 Modify Timing Characteristics
B133XW02 V2 Document version: 1.1 3 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input
connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration
or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate
nor tilt the Interface Connector of the TFT Module.
10) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
11) Small amount of materials having no flammability grade is used in the LCD module.
The LCD module should be supplied by power complied with requirements of
Limited Power Source (IEC60950 or UL1950), or be applied exemption.
12) Disconnecting power supply before handling LCD modules, it can prevent electric
shock, DO NOT TOUCH the electrode parts, cables, connectors and LED circuit
part of TFT module that a LED light bar build in as a light source of back light unit.
It can prevent electrostatic breakdown.
B133XW02 V2 Document version: 1.1 4 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B133XW02 V2 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD
panel, a driver circuit, and LED backlight system. The screen format is intended to support
the High Definition (1366(H) x 768(V)) screen and 262k colors (RGB 6-bits data driver) with
LED backlight driving circuit. All input signals are LVDS interface compatible.
B133XW02 V2 is designed for a display unit of notebook style personal computer and
industrial machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 336.6 (13.25W")
Active Area [mm] 293.42 X 164.97
Pixels H x V 1366x3(RGB) x 768
Pixel Pitch [mm] 0.2148X0.2148
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=20mA) [cd/m2] 220 typ. (5 points average)
(Note: ILED is LED current) 200 min. (5 points average)
Luminance Uniformity 1.25 max. (5 points)
Contrast Ratio 500 typ
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 4.5W max
Weight [Grams] 350 max.
Physical Size [mm] L W T
Max 308.1 183.6 5.2
Typical - - -
Min - - -
Electrical Interface 1 channel LVDS
Glass thickness [mm] 0.5
Surface Treatment Glare, Hardness 3H,
Reflection 4.3%
Support Color 262K colors ( RGB 6-bit )
B133XW02 V2 Document version: 1.1 5 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Unit Conditions Min. Typ. Max. Note
White Luminance [cd/m2] 5 points average 200 220 - 1, 4, 5.
(ILED=20mA)
Viewing Angle [degree] Horizontal - 45 - 4, 9
[degree] (Right)
- 45 -
CR = 10 (Left)
[degree] Vertical - 15 -
[degree] (Upper)
- 35 -
CR = 10 (Lower)
Luminance 5 Points - - 1.25 1, 3, 4
Uniformity 13 Points - - 1.5 2, 3, 4
CR: Contrast Ratio 400 500 - 4, 6
Cross talk % 4 4, 7
Response Time [msec] Rising + Falling - 8 16
Red x 0.560 0.590 0.620
Red y 0.310 0.340 0.370
Green x 0.295 0.325 0.355
Chromaticity of
color Green y 0.545 0.575 0.605 4, 9
Coordinates Blue x 0.125 0.155 0.185
(CIE 1931) Blue y 0.105 0.135 0.165
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
B133XW02 V2 Document version: 1.1 6 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 13 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
10 10
10
1 2 3
H /4
4 5
H /4
H 6 7 8
H /4
9 10
H /4 11 12 13
10
Note 3: The luminance uniformity of 5 or13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W13 =
Minimum Brightness of thirteen points
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature
change during measuring. In order to stabilize the luminance, the measurement should be executed after
B133XW02 V2 Document version: 1.1 7 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
lighting Backlight for 30 minutes in a stable, windless and dark room. !
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
