Image preview - the first page of the document
![Panel_AUO_B141EW05_V5_0_[DS]](/pics/5c36ad8d974bc.gif)
>> Download Panel_AUO_B141EW05_V5_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
(V ) Final Specifications
Module 14.1" WXGA Color TFT-LCD with LED Backlight design
Model Name B141EW05 V5 (Dell P/N: 2H7P2)
Note ( ) LED Backlight with driving circuit design
Customer Date Approved by Date
Bonnie Chen 02/12/2010
Checked &
Date Prepared by
Approved by
Kay CY Wang 02/12/2010
Note: This Specification is subject to change NBBU Marketing Division /
without notice. AU Optronics corporation
B141EW05 V5 Document Version : 1.0 1 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .............................................................. 4
2. General Description ................................................................. 5
2.1 General Specification ...............................................................................................................................5
2.2 Optical Characteristics .............................................................................................................................6
3. Functional Block Diagram ...................................................... 11
4. Absolute Maximum Ratings ................................................... 12
4.1 Absolute Ratings of TFT LCD Module ............................................................................................... 12
4.2 Absolute Ratings of Environment ........................................................................................................ 12
5. Electrical characteristics ....................................................... 13
5.1 TFT LCD Module ................................................................................................................................. 13
5.2 Backlight Unit........................................................................................................................................ 16
6. Signal Characteristic ............................................................. 17
6.1 Pixel Format Image................................................................................................................................ 17
6.2 The input data format ............................................................................................................................ 18
6.3 Integration Interface and Pin Assignment............................................................................................ 19
6.4 Interface Timing..................................................................................................................................... 21
7. Vibration and Shock Test ....................................................... 24
7.1 Vibration Test......................................................................................................................................... 24
7.2 Shock Test Spec:.................................................................................................................................... 24
7.3 Reliability Test .................................................................... 25
8. Mechanical Characteristics .................................................... 26
8.1 LCM Outline Dimension ...................................................................................................................... 26
8.2 Screw Hole Depth and Center Position ............................................................................................... 28
9. Shipping and Package............................................................ 29
9.1 Shipping Label Format ......................................................................................................................... 29
9.2 Carton package ...................................................................................................................................... 30
9.3 Shipping package of palletizing sequence .......................................................................................... 30
10. Appendix: EDID description ................................................. 31
B141EW05 V5 Document Version : 1.0 2 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2009/07/14 All First Edition for Customer
0.2 2010/01/29 P. 6 TBD Update Chromaticity Coodinates
1.0 2010/02/12 P.27-28 Old 2D drawing New 2D drawing w/ WWAN solution
P.32-35 X31 EDID A00 EDID
1.1 2010/11/22 P.29 Shipping label New shipping label for Pol 25%
B141EW05 V5 Document Version : 1.0 3 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock, DO
NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT module
that a LED light bar build in as a light source of back light unit. High voltage is supplied to
these parts when power turn on.
B141EW05 V5 Document Version : 1.0 4 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B141EW05 V5 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and LED backlight system. The screen format is intended to support the WXGA
(1280(H) x 800(V)) screen and 262k colors (RGB 6-bits data driver) with LED backlight driving
circuit. The input signals are eDP interface compatible.
B141EW05 V5 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 357.7 (14.1W")
Active Area [mm] 303.36 X 189.6
Pixels H x V 1280x3(RGB) x 800
Pixel Pitch [mm] 0.237
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=20mA) [cd/m2] 220 typ. (5 points average)
Note: ILED is LED current 200 min. (5 points average)
(Note1)
Luminance Uniformity 1.25 max. (5 points)
Contrast Ratio 500:1 typ
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 5.1 max. (Include Logic and Blu power) (Note1)
Weight [Grams] 375 max.
Physical Size without inverter, [mm] Min. Typ. Max.
bracket. Length 319 319.5 320
Width 206 206.5 207
Thickness - - 5.5
Electrical Interface 1 channel Display Port
Surface Treatment Anti-Glare,
B141EW05 V5 Document Version : 1.0 5 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Support Color 262K colors ( RGB 6-bit )
Temperature Range
Operating [oC] 0 to +50
o
Storage (Non-Operating) [ C] -20 to +65
RoHS Compliance RoHS Compliance
Note 1. Total power consumption including LED power efficiency <4.9W max.
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
White Luminance 5 points average 2
200 220 - cd/m 1, 4, 5.
ILED=20mA
R Horizontal (Right) 40 45 -
CR = 10 (Left) degree
L 40 45 -
Viewing Angle 4, 9
H Vertical (Upper) 15 20 -
L CR = 10 (Lower) 30 40 -
Luminance
5P 5 Points - - 1.25 1, 3, 4
Uniformity
Luminance
13P 13 Points - - 1.50 2, 3, 4
Uniformity
Contrast Ratio CR 400 500 - 4, 6
Cross talk % 4 4, 7
Tr Rising - 6 -
Response Time Tf Falling - 2 - msec 4, 8
TRT Rising + Falling - 8 16
Red x 0.570 0.600 0.630
Red y 0.310 0.340 0.370
Green x 0.285 0.315 0.345
Color / Green y 0.520 0.550 0.580
Chromaticity Blue x !
CIE 1931! 0.125 0.155 0.185 4
Coodinates
Blue y 0.115 0.145 0.175
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
NTSC % - 45 -
B141EW05 V5 Document Version : 1.0 6 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 13 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
10 10
10
1 2 3
H /4
4 5
H /4
H 6 7 8
H /4
9 10
H /4 11 12 13
10
Note 3: The luminance uniformity of 5 or13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W13 =
Minimum Brightness of thirteen points
Note 4: Measurement method
B141EW05 V5 Document Version : 1.0 7 of 34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting
Backlight for 30 minutes in a stable, windless and dark room, , and it should be measured in the center of screen.! !
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
