Image preview - the first page of the document
![Panel_AUO_B141PW01_V1_0_[DS]](/pics/5c36ad9067b08.gif)
>> Download Panel_AUO_B141PW01_V1_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
( V ) Preliminary Specifications
( ) Final Specifications
Module 14.1" WXGA+ Color TFT-LCD
Model Name B141PW01 V1
Customer Date Approved by Date
2005/11/07 Joselyn Liu 2005/11/07
Checked &
Prepared by
Approved by
Kay Liu 2005/11/07
Note: This Specification is subject to change MDBU Marketing Division /
without notice. AU Optronics corporation
document version 0.3 1/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
Contents
1. Handling Precautions .............................................................................................................. 4
2. General Description ................................................................................................................. 5
2.1 General Specification...................................................................................................................... 5
2.2 Optical Characteristics.................................................................................................................... 6
3. Functional Block Diagram..................................................................................................... 11
4. Absolute Maximum Ratings .................................................................................................. 12
4.1 Absolute Ratings of TFT LCD Module......................................................................................... 12
4.2 Absolute Ratings of Backlight Unit............................................................................................... 12
4.3 Absolute Ratings of Environment ................................................................................................. 12
5. Electrical characteristics....................................................................................................... 13
5.1 TFT LCD Module ........................................................................................................................ 13
5.2 Backlight Unit .............................................................................................................................. 15
6. Signal Characteristic ............................................................................................................. 17
6.1 Pixel Format Image ...................................................................................................................... 17
6.2 The input data format ................................................................................................................... 18
6.3 Signal Description/Pin Assignment ............................................................................................... 19
6.4 Interface Timing ........................................................................................................................... 21
7. Connector Description .......................................................................................................... 23
7.1 TFT LCD Module ........................................................................................................................ 23
7.2 Backlight Unit .............................................................................................................................. 23
7.3 Signal for Lamp connector ........................................................................................................... 23
8. Vibration and Shock Test ...................................................................................................... 24
8.1 Vibration Test............................................................................................................................... 24
8.2 Shock Test Spec:.......................................................................................................................... 24
9. Reliability ................................................................................................................................ 25
10. Mechanical Characteristics ................................................................................................. 26
11. Shipping and Package......................................................................................................... 29
11.1 Shipping Label Format ............................................................................................................... 29
11.2. Carton package ......................................................................................................................... 30
11.3 Shipping package of palletizing sequence.................................................................................... 30
12. Appendix: EDID description................................................................................................ 30
document version 0.3 2/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2005/09/03 All First Edition for Customer
0.2 2005/11/07 5 Power consumption From 5.1W ( typ) to 5.5W (typ)
document version 0.3 3/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was
taken out from the container, do not press the center of the CCFL Reflector edge. Instead,
press at the far ends of the CFL Reflector edge softly. Otherwise the TFT Module may be
damaged.
10)At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12)Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow
local ordinances or regulations for disposal.
13)Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source(,
IEC60950 or UL1950), or be applied exemption.
14)The LCD module is designed so that the CCFL in it is supplied by Limited Current
Circuit(IEC60950 or UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 0.3 4/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
2. General Description
B141PW01 V1 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and backlight system. The screen format is intended to support the WXGA+
(1440(H) x 900(V)) screen and 262k colors (RGB 6-bits data driver). All input signals are LVDS
interface compatible. Inverter of backlight is not included.
B141PW01 V1 is designed for a display unit of notebook style personal computer and industrial
machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 357.7 (14.1W ")
Active Area [mm] 303.48 X 189.675
Pixels H x V 1440x3(RGB) x 900
Pixel Pitch [mm] 0.21075X0.21075
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
2
White Luminance (I CCFL=6.0mA) [cd/m ] 220 typ. (5 points average)
Note: ICCFL is lamp current 190 min. (5 points average)
(Note1)
Luminance Uniformity 1.2 max. (5 points)
Contrast Ratio 350 typ
Optical Rise Time/Fall Time [msec] 15/10 typ.
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 5.5 typ.(without inverter)
Weight [Grams] 390 typ.
Physical Size [mm] 320.5(W) x 206 (H) x 5.5(D) Max.
Electrical Interface 2 channel LVDS
Surface Treatment Haze 25, hard coating 3H,AG
Support Color 262K colors ( RGB 6-bit )
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
document version 0.3 5/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
2
White Luminance [cd/m ] 5 points average 190 220 - 1, 4, 5.
ICCFL=6.0mA
Viewing Angle [degree] Horizontal (Right) - 45 - 8
[degree] CR = 10 (Left)
- 45 -
[degree] Vertical (Upper) - 20 -
[degree] CR = 10 (Lower)
- 35 -
Luminance Uniformity 5 Points 1.2 1
Luminance Uniformity 13 Points 1.8 2
CR: Contrast Ratio 350 400 - 6
Cross talk % 1.4 7
Response Time [msec] Rising - 15 20 8
[msec] Falling - 10 15
[msec] Rising + Falling 25 35
Color / Chromaticity Red x 0.550 0.580 0.610 2,8
Coordinates Red y
(CIE 1931) 0.310 0.340 0.370
Green x 0.280 0.310 0.340
Green y 0.520 0.550 0.580
Blue x 0.125 0.155 0.185
Blue y 0.115 0.145 0.175
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
document version 0.3 6/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
Note 1: 5 points position (Display area : 303.48mm x 189.675mm)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 13 points position
W
W /4 W /4 W /4 W /4
10 10
10
1 2 3
H /4
4 5
H /4
H 6 7 8
H /4
9 10
H /4 11 12 13
10
Note 3: The luminance uniformity of 5 and 13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W13 =
Minimum Brightness of thirteen points
document version 0.3 7/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting Backlight
for 30 minutes in a stable, windless and dark room.
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
document version 0.3 8/34
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B141PW01 V1
Note 7 Definition of Cross Talk (CT)
CT = | YB ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
