Image preview - the first page of the document
![Panel_AUO_B154SW01_V5_0_[DS]](/pics/5c36adac156a0.gif)
>> Download Panel_AUO_B154SW01_V5_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
QD15AL0202 Page 1 /25
AU Optronics Corp. Doc No. QD15AL0202-00
Doc. REV.: 01
SPECIFICATION
Preliminary Issue Date: 2006/8/28
Specification With RoHS
compliant
Specification for TFT LCD Module
Model No.
QD15AL0202 Rev.:01
( B154SW01 V5 )
Approval By
AU Optronics Corp.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
QD15AL0202 Page 2 /25
These specification sheets are the proprietary product of AU Optronics Corp. ("AUO") and
include materials protected under copyright of AUO. Do not reproduce or cause any third
party to reproduce them in any form or by any means, electronic or mechanical, for any
purpose, in whole or in part, without the express written permission of AUO.
The device listed in these technical literature sheets was designed and manufactured for use
in OA equipment.
In case of using the device for applications such as control and safety equipment for
transportation (aircraft, trains, automobiles, etc.), rescue and security equipment and various
safety related equipment which require higher reliability and safety, take into consideration
that appropriate measures such as fail-safe functions and redundant system design should
be taken.
Do not use the device for equipment that requires an extreme level of reliability, such as
aerospace applications, telecommunication equipment (trunk lines), nuclear power control
equipment and medical or other equipment for life support.
AUO assumes no responsibility for any damage resulting from the use of the device, which
does not comply with the instructions, and the precautions specified in these technical
literature sheets.
Contact and consult with a AUO sales representative for any questions about this device.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
QD15AL0202 Page 3 /25
Revision History
REV. Date ECN NO. Change Content
0 2006/8/21 N/A Specification Initiation
1 2006/8/28 N/A Page 4 change "QD15AL02 rev.02" to "QD15AL0202"
Page 22 change "QD15AL02 rev.02" to "QD15AL0202" on
1 2006/8/28 N/A shipping label format
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
QD15AL0202 Page 4 /25
1. Application
This specification applies to a color TFT-LCD module, QD15AL0202.
2. Overview
This module is a color active matrix LCD module incorporating amorphous silicon TFT
(Thin Film Transistor). It is composed of a color TFT-LCD panel; driver ICs, control circuit and
power supply circuit and a backlight unit. Graphics and texts can be displayed on a 1680 3
1050 dots panel with 262,144 colors by using LVDS (Low Voltage Differential Signaling) to
interface and supplying +3.3V DC supply voltage for TFT-LCD panel driving and supply
voltage for backlight.
The TFT-LCD panel used for this module has very high aperture ratio. A low-reflection and
higher-color-saturation type color filter is also used for this panel. Therefore, high-brightness
and high-contrast image, which is suitable for the multimedia use, can be obtained by using
this module.
Optimum viewing direction is 6 o'clock.
[Features]
1) High aperture panel; high-brightness or low power consumption.
2) Brilliant and high contrast image.
3) Small footprint and thin shape.
4) Light weight.
5) Wide Screen 15.4" WSXGA+
6) Lead free (Pb contain is less than 1000ppm) compliant
7) RoHS compliant
3. General Specifications
Parameter Specifications Unit
Display size 390.1 (15.4") Diagonal mm
Active area 331.2 207.0 mm
Pixel format 1680 (H) 1050 (V) Pixel
(1 pixel = R+G+B dots)
Pixel pitch 0.1971(H) 0.1971 (V) mm
Pixel configuration R, G, B vertical stripe
Display mode Normally white
Unit outline dimensions (typ.)*1, 2 344.5(W) 222.5 (H) 6. 5(T)max. mm
Mass 585 max. g
Surface treatment Glare; Hardness 3H;
*1.Note: excluding backlight cables. Outline dimensions are shown in this specification.
*2.Note: Please refer to outline drawing, the thickness spec. of screw nearby lamp side are
6.6 and 6.8mm max.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
QD15AL0202 Page 5 /25
4. Input Terminals
4-1. Signal Interface Connector
