Image preview - the first page of the document
![Panel_AUO_B156HW01_V4_0_[DS]](/pics/5c36ab030aead.gif)
>> Download Panel_AUO_B156HW01_V4_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( V ) Preliminary Specifications
( ) Final Specifications
Module 15.6" (15.55") FHD Color TFT-LCD with LED Backlight design
Model Name B156HW01 V4 (H/W:0A)
Note ( ) R,G phosphor LED Backlight with driving circuit design
Customer Date Approved by Date
Beyond Yang 02/26/2009
Checked &
Date Prepared by
Approved by
Jeff Hou 02/26/2009
Note: This Specification is subject to change without NBBU Marketing Division /
notice. AU Optronics corporation
B156HW01 V4 Document Version : 0.1 1 of 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 General Specification ..........................................................................................................................5
2.2 Optical Characteristics ........................................................................................................................6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module.............................................................................................12
4.2 Absolute Ratings of Environment .....................................................................................................12
(OHFWULFDO FKDUDFWHULVWLFV
5.1 TFT LCD Module..............................................................................................................................13
5.2 Backlight Unit ...................................................................................................................................15
6LJQDO &KDUDFWHULVWLF
6.1 Pixel Format Image ...........................................................................................................................16
6.2 The input data format ........................................................................................................................17
6.3 Integration Interface and Pin Assignment..........................................................................................18
6.4 Interface Timing ................................................................................................................................22
&RQQHFWRU 'HVFULSWLRQ
7.1 TFT LCD Module..............................................................................................................................25
/ Y(' 'ULILQJ 6SHFL LFDWLRQ
8.1 Connector Description.......................................................................................................................26
8.2 Pin Assignment..................................................................................................................................26
9 7LEUDWLRQ DQG 6KRFN HVW
9.1 Vibration Test ....................................................................................................................................27
9.2 Shock Test Spec:................................................................................................................................27
\ 5HOLDELOLW /
0HFKDQLFDO &KDUDFWHULVWLFV 9
11.1 LCM Outline Dimension.................................................................................................................29
11.2 Screw Hole Depth and Center Position ...........................................................................................31
6KLSSLQJ DQG 3DFNDJH
12.1 Shipping Label Format ....................................................................................................................32
12.2 Carton package ................................................................................................................................33
12.3 Shipping package of palletizing sequence.......................................................................................33
$SSHQGL[, ('4' GHVFULSWLRQ
B156HW01 V4 Document Version : 0.1 2 of 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2009/02/26 All First Edition for Customer
B156HW01 V4 Document Version : 0.1 3 of 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input
connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration
or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate
nor tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13)Disconnecting power supply before handling LCD modules, it can prevent electric shock,
DO NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT
module that a LED light bar build in as a light source of back light unit. It can prevent
electrostic breakdown.
B156HW01 V4 Document Version : 0.1 4 of 35
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B156HW01 V4 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD
panel, a driver circuit, and LED backlight system. The screen format is intended to support
the FHD (1920(H) x 1080(V)) screen and 262k colors (RGB 6-bits data driver) with LED
backlight driving circuit. All input signals are LVDS interface compatible.
B156HW01 V4 is designed for a display unit of notebook style personal computer and
industrial machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 15.6W"(15.55)
Active Area [mm] 344.16 x 193.59
Pixels H x V 1920x3(RGB) x 1050
Pixel Pitch [mm] 0.17925 x 0.17925
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=15mA) [cd/m2] 270 typ. (5 points average)
(Note: ILED is LED current) 230 min. (5 points average)
Luminance Uniformity 1.25 max. (5 points)
Contrast Ratio 400 typ
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 11.5 max. (Include Logic and Blu power)
Weight [Grams] 475 max.
Physical Size without inverter, [mm] Min. Typ. Max.
bracket. Length
Width 5
Thickness
Electrical Interface 2 channel LVDS
Glass Thickness [mm] 0.5
Surface Treatment Anti-glare, Hardness 2H,Haze=42%◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
