Image preview - the first page of the document
![Panel_AUO_B156XW02_V3_0_[DS]](/pics/5c36ab7902dbe.gif)
>> Download Panel_AUO_B156XW02_V3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V ) Final Specifications
Module 15.6"(15.55") HD 16:9 Color TFT-LCD
with LED Backlight design
Model Name B156XW02 V3 (H/W:4A)
Note ( ) LED Backlight with driving circuit design
Customer Date Approved by Date
Emerson Huang 07/19/2010
Checked &
Date Prepared by Date
Approved by
Hsiang-Chi Liu 07/19/2010
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B156XW02 V3 Document Version : 1.4 1 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 General Specification ..........................................................................................................................5
2.2 Optical Characteristics ........................................................................................................................6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module.............................................................................................12
4.2 Absolute Ratings of Environment .....................................................................................................12
(OHFWULFDO &KDUDFWHULVWLFV
5.1 TFT LCD Module..............................................................................................................................13
5.2 Backlight Unit ...................................................................................................................................15
6LJQDO ,QWHUIDFH &KDUDFWHULVWLF
6.1 Pixel Format Image ...........................................................................................................................16
6.2 The Input Data Format ......................................................................................................................17
6.3 Integration Interface Requirement.....................................................................................................18
6.4 Interface Timing ................................................................................................................................19
3DQHO 5HOLDELOLW7 HVW
7.1 Vibration Test ....................................................................................................................................22
7.2 Shock Test .........................................................................................................................................22
7.3 Reliability Test...................................................................................................................................22
0HFKDQLFDO &KDUDFWHULVWLFV
8.1 LCM Outline Dimension...................................................................................................................23
8.2 Screw Hole Depth and Center Position.............................................................................................26
6KLSSLQJ DQG 3DFNDJH
9.1 Shipping Label Format ......................................................................................................................27
9.2 Carton Package..................................................................................................................................28
9.3 Shipping Package of Palletizing Sequence........................................................................................29
$SSHQGL[1 (',' 'HVFULSWLRQ
B156XW02 V3 Document Version : 1.4 2 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.0 2009/06/23 All First Edition for Customer
0.1 2009/09/07 26 Modify Label Add CT Label
1.0 2009/10/28 Final Specifications
1.1 2009/12/14 26 Modify Label Add Label format
1.2 2009/12/21 15 PWM Input Frequency PWM Input Frequency Modify
1.3 2009/12/28 15 Update 5.2.1 LED characteristics Update
Parameter Symbol Min Typ Max
Backlight
Power PLED - 4.0 4.4
Consumption
` 15 Update 5.2.2 Backlight input signal Update
characteristics
Max Uni
Parameter Symbol Min Typ
ts
PWM Input
Hz
Frequency FPWM 700 1K 2K
1.4 2010/7/19 21 Update 6.5 Power ON/OFF Sequence Update
T3:min 200ms
1.4 2010/07/19 25 8.1 LCM Outline Dimension Add
2D drawing: Z30/Z40
1.4 2010/07/19 27 9.1 Shipping Label Format Add
Z30/Z40
B156XW02 V3 Document Version : 1.4 3 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input
connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration
or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure
human earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate
nor tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock,
DO NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT
module that a LED light bar build in as a light source of back light unit. It can prevent
electrostic breakdown.
B156XW02 V3 Document Version : 1.4 4 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B156XW02 V3 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel,
a driver circuit, and LED backlight system. The screen format is intended to support the 16:9
HD, 1366(H) x768(V) screen and 262k colors (RGB 6-bits data driver) with LED backlight
driving circuit. All input signals are LVDS interface compatible.
B156XW02 V3 is designed for a display unit of notebook style personal computer and
industrial machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 394.91
Active Area [mm] 344.23 X193.54
Pixels H x V 1366x3(RGB) x 768
Pixel Pitch [mm] 0.252X0.252
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ILED=20mA) [cd/m2] 200 typ. (5 points average)
(Note: ILED is LED current) 170 min. (5 points average)
Luminance Uniformity 1.25 max. (5 points)
Contrast Ratio 400 typ
Response Time [ms] 8 typ / 16 Max
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] 5.6 max. (Include Logic and Blu power)
Weight [Grams] 450 max.
Physical Size [mm] Min. Typ. Max.
Include bracket Length - 359.3 360
Width - 209.5 210
Thickness - - 5.5
Electrical Interface 1 channel LVDS
Glass Thickness [mm] 0.5
Surface Treatment Anti Glare, Hardness 3H,
Support Color 262K colors ( RGB 6-bit )
B156XW02 V3 Document Version : 1.4 5 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Temperature Range
o
Operating [ C] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
White Luminance 5 points average 2
- 200 - cd/m 1, 4, 5.
ILED=20mA
R Horizontal (Right) 40 45 -
degree
L CR = 10 (Left) 40 45 -
Viewing Angle 4, 9
H Vertical (Upper) 10 15 -
L CR = 10 (Lower) 30 35 -
Luminance
5P 5 Points - - 1.25 1, 3, 4
Uniformity
Luminance
13P 13 Points - - 1.65 2, 3, 4
Uniformity
Contrast Ratio CR - 400 - 4, 6
Cross talk % 4 4, 7
Tr Rising - 6 -
Response Time Tf Falling - 2 - msec 4, 8
TRT Rising + Falling - 8 16
Rx 0.593 0.623 0.653
Red
Ry 0.321 0.351 0.381
Gx 0.306 0.336 0.366
Color / Green
Gy 0.544 0.574 0.604
Chromaticity
Coodinates Bx CIE 1931 0.118 0.148 0.178 4
Blue
By 0.023 0.053 0.083
Wx 0.263 0.313 0.343
White
Wy 0.279 0.329 0.359
NTSC % - 60 -
B156XW02 V3 Document Version : 1.4 6 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 1: 5 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 2: 13 points position (Ref: Active area)
W
W /4 W /4 W /4 W /4
10 10
10
1 2 3
H /4
4 5
H /4
H 6 7 8
H /4
9 10
H /4 11 12 13
10
Note 3: The luminance uniformity of 5 or13 points is defined by dividing the maximum luminance values by the
minimum test point luminance
Maximum Brightness of five points
W5 =
Minimum Brightness of five points
Maximum Brightness of thirteen points
W13 =
Minimum Brightness of thirteen points
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting
B156XW02 V3 Document Version : 1.4 7 of 32
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Backlight for 30 minutes in a stable, windless and dark room, and it should be measured in the center of screen.! !
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD Module
Center of the screen
Note 5 Definition of Average Luminance of White (YL):
Measure the luminance of gray level 63 at 5 points YL = [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
L (x) is corresponding to the luminance of the point X at Figure in Note (1).
Note 6 Definition of contrast ratio:
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7 Definition of Cross Talk (CT)
