Image preview - the first page of the document
![Panel_AUO_B150XG07_V3_0_[DS]](/pics/5c36ab99e56c1.gif)
>> Download Panel_AUO_B150XG07_V3_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
B150XG07 V3
( ) Preliminary Specifications
( V ) Final Specifications
Module 15" XGA Color TFT-LCD
Model Name B150XG07 V3(QD15XL0404)
Customer Date Approved by Date
Jaff Huang 2007/09/12
Checked &
Prepared by
Approved by
Jaff Huang 2007/09/12
Note: This Specification is subject to change MDBU Marketing Division /
without notice. AU Optronics corporation
document version 0.2 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification 1
AU OPTRONICS CORPORATION
B150XG07 V3
These specification sheets are the proprietary product of AU Optronics ( "AUO") and include
materials protected under copyright of AUO. Do not reproduce or cause any third party to
reproduce them in any form or by any means, electronic or mechanical, for any purpose, in
whole or in part, without the express written permission of AUO.
The device listed in these technical literature sheets was designed and manufactured for use in
OA equipment.
In case of using the device for applications such as control and safety equipment for
transportation (aircraft, trains, automobiles, etc.), rescue and security equipment and various
safety related equipment which require higher reliability and safety, take into consideration that
appropriate measures such as fail-safe functions and redundant system design should be
taken.
Do not use the device for equipment that requires an extreme level of reliability, such as
aerospace applications, telecommunication equipment (trunk lines), nuclear power control
equipment and medical or other equipment for life support.
AUO assumes no responsibility for any damage resulting from the use of the device which does
not comply with the instructions and the precautions specified in these technical literature
sheets.
Contact and consult with a AUO sales representative for any questions about this device.
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification 2
AU OPTRONICS CORPORATION
B150XG07 V3
Revision History
REV. Date ECN NO. Change Content
0 08/19/2005 N/A Specification Initial Release
1 09/12/2007 N/A QDI model name transform to AU model name
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification 3
AU OPTRONICS CORPORATION
B150XG07 V3
1. Application
This specification applies to a color TFT-LCD module, B150XG07 V3(QD15XL0403).
2. Overview
This module is a color active matrix LCD module incorporating amorphous silicon TFT
(Thin Film Transistor). It is composed of a color TFT-LCD panel, driver ICs, control circuit, and
power supply circuit and a backlight unit. Graphics and texts can be displayed on a 1024 3 768
dots panel with 262,144 colors by using LVDS (L ow Voltage Differential Signaling) to interface
and supplying +3.3V DC supply voltage for TFT-LCD panel driving and supply voltage for
backlight.
The TFT-LCD panel used for this module has very high aperture ratio. A low-reflection and
higher-color-saturation type color filter is also used for this panel. Therefore, high-brightness
and high-contrast image, which is suitable for the multimedia use, can be obtained by using
this module.
Optimum viewing direction is 6 o'clock.
[Features]
1) High aperture panel; high-brightness or low power consumption.
2) Brilliant and high contrast image.
3) Small footprint and thin shape.
4) Light weight.
5) 100% SPWG, style B
6) Lead-Free & RoHS Compliant
3. Mechanical Specifications
Parameter Specifications Unit
Display size 15" Diagonal inch
Active area 304.13 228.10 mm
Pixel format 1024 (H) 768 (V) Pixel
(1 pixel = R+G+B dots)
Pixel pitch 0.297(H) 0.297 (V) mm
Pixel configuration R, G, B vertical stripe
Display mode Normally white
Unit outline dimensions (typ.)*1 317.3(W) 242.0 (H) 5.9(D) mm
6.0 Max
Mass 575 max. with inverter g
Surface treatment Anti-glare and hard-coating 3H
Low reflection ( 5%)
*1.Note: excluding backlight cables. Outline dimensions is shown in this specification
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification 4
AU OPTRONICS CORPORATION
B150XG07 V3
4. Input Terminals
4-1. TFT-LCD panel driving
