Image preview - the first page of the document
![Panel_AUO_B160HW02_V0_0_[DS]](/pics/5c36ab9d219ed.gif)
>> Download Panel_AUO_B160HW02_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
( ) Preliminary Specifications
( V ) Final Specifications
Module 16" FHD 16:9 Color TFT-LCD
with LED Backlight design
Model Name B160HW02 V0
Customer Date Approved by Date
Allen KC Chen 2010/2/17
Checked &
Date Prepared by Date
Approved by
Tony Kao 2010/2/17
Note: This Specification is subject to change NBBU Marketing Division
without notice. AU Optronics corporation
B160HW02 V0 Document Version : 1.1 1 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 General Specification ..........................................................................................................................6
2.2 Optical Characteristics ........................................................................................................................7
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module.............................................................................................13
4.2 Absolute Ratings of Environment .....................................................................................................13
(OHFWULFDO &KDUDFWHULVWLFV
5.1 TFT LCD Module..............................................................................................................................14
5.2 Backlight Unit ...................................................................................................................................17
6LJQDO ,QWHUIDFH &KDUDFWHULVWLF
6.1 Pixel Format Image ...........................................................................................................................19
6.2 Integration Interface Requirement.....................................................................................................20
6.3 Interface Timing ................................................................................................................................22
6.4 Power ON/OFF Sequence .................................................................................................................26
3DQHO 5HOLDELOLW\ 7HVW
7.1 Vibration Test ....................................................................................................................................28
7.2 Shock Test .........................................................................................................................................28
7.3 Reliability Test...................................................................................................................................28
0HFKDQLFDO &KDUDFWHULVWLFV
8.1 LCM Outline Dimension...................................................................................................................29
6KLSSLQJ DQG 3DFNDJH
9.1 Shipping Label Format ......................................................................................................................32
9.2 Carton Package..................................................................................................................................33
9.3 Shipping Package of Palletizing Sequence........................................................................................34
$SSHQGL[
10.1 EDID Description............................................................................................................................35
B160HW02 V0 Document Version : 1.1 2 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2010/09/07 All First Edition for Customer
2
0.2 2010/11/01 5 White Luminance 2D animation/3D : 224 cd/m typ
2
230 cd/m typ
Luminance Uniformity 2D 50% typ
animation/3D : 65% typ
Power Consumption : 18.8 / 24.9 Please refer to 5.1.1 and 5.2.1
Watt max (Include Logic and BLU
power)
Module thickness : 8.5mm Module thickness : 8.95mm
Weight : 632g typ 638g typ
6 Surface Treatment : Glare Surface Treatment : Anti-Glare
Revise 2.2 Optical Characteristics Please refer to revised version
11 Update absolute ratings of TFT V DD5 : -0.3~+6.5V
LCD module V in : -0.3~(V DD33 +0.3)V
V DD5 , V in, V LED , I LED V LED : -0.3~22V
I LED : 0~30mA
Update absolute ratings of
environment: Operating Temperature : Operating Temperature : 0~50
0~50
12 Update power specification of IDD33, Please refer to p12
IDD5 and delete inrush current and
VDD ripple
15,16 Update LED characteristics and Please refer to p15~p16
backlight input signal characteristics
24,25 Update 6.5 Power ON/OFF Please refer to p24~25
Sequence
27,28 Update module appearance Please refer to p27~p28
33 Update EDID description Please refer to p33~p38
1.0 2011/1/17 All Final the spec
8 none
Note 2: Luminance measure point
9 Note 7: Definition of response time Please refer to p9
13 Update current of the Input power Please refer to p13
15 VHPD :2.25(min); 3.6(max) VHPD :1.9(min); 2.7(max)
21~2 Timing Characteristics Please refer to p21~p23
3
B160HW02 V0 Document Version : 1.1 3 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
27 Vibration: 10~500Hz Vibration: 5~500Hz
Shock: 220G, 2ms Shock: 210G, 3ms
30 Update pictures Please refer to p30
1.1 2011/2/17 7 Add light distribution Please refer to p7
16 Update the description of the Note1 Please refer to p16
and Note2
23 Update 3D timing Please refer to p23
27 Add the test and condition of the Please refer to p27
High Temperature and High Humidity
Storage
B160HW02 V0 Document Version : 1.1 4 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input
connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration
or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on
hard surface.
6) Since PMOS is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate
nor tilt the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (Notebook PC Bezel, for
example), do not twist nor bend the TFT Module even momentary. At designing the
enclosure, it should be taken into consideration that no bending/twisting forces are
applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The
LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Disconnecting power supply before handling LCD modules, it can prevent electric shock,
DO NOT TOUCH the electrode parts, cables, connectors and LED circuit part of TFT
module that a LED light bar build in as a light source of back light unit. It can prevent
electrostatic breakdown.
B160HW02 V0 Document Version : 1.1 5 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
B160HW02 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD
panel, a driver circuit, and LED backlight system. The screen format is intended to support
the 16:9 FHD, 1920(H) x1080(V) screen and 262k colors (RGB 6-bits data driver) with LED
backlight driving circuit. All input signals are eDP interface compatible.
B160HW02 V0 is designed for a display unit of notebook style personal computer and
industrial machine.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 406.4
Active Area [mm] 354.24X199.26
Pixels H x V 1920x3(RGB) x 1080
Pixel Pitch [mm] 0.1845X0.1845
Pixel Format R.G.B. Vertical Stripe
Display Mode Normally White
2
White Luminance 2D still picture [cd/m ] 345 typ.
(ILED=20mA)
2
White Luminance 2D animation/3D [cd/m ] 224 typ.
(ILED=27mA / 45% duty)
Luminance Uniformity 2D still picture [%] 65 typ.
Luminance Uniformity 2D [%] 50 typ.
animation/3D
Contrast Ratio 500 typ.
Response Time [ms] 4 Max
Nominal Input Voltage VDD [Volt] +3.3 / +5.0 typ.
Weight [Grams] 638 typ.
Physical Size [mm] Min. Typ. Max.
Include bracket & PCBA Length - 375.0 -
Width - 218.0 -
Thickness - - 8.95
Electrical Interface eDP
Glass Thickness [mm] 0.5
Surface Treatment Anti-Glare
B160HW02 V0 Document Version : 1.1 6 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Support Color 262K colors ( RGB 6-bit )
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Symbol Conditions Min. Typ. Max. Unit Note
2
Luminance 2D still [cd/m ] = 1, 2
242 345 ILED = 20mA(rms)
[cd/m ]
2
= 1, 2
Luminance 2D
animation/3D
157 224 ILED = 27mA(rms),
45%duty
R Horizontal (Right) 80 - -
CR = 10 (Left) degree
L 80 - -
Viewing Angle 5, 8
H Vertical (Upper) 80 - -
CR = 10 (Lower) -
L 80 - -
Vertical 29.5 34.5 degree
Light distribution L = 1/2 Lstill
Horizontal 47.0 52.0 degree
Luminance Uniformity 2D Lstill = 55 65
still picture 1, 3, 4
Luminance Uniformity 2D L3D = 40 50
animation/3D 1, 3, 4
Contrast Ratio CR 300 500 - 5, 6
Tr Rising - - -
Response Time Tf Falling - - - msec 5, 7
TRT Rising + Falling - - 4
Rx 0.5981 0.6481 0.6977
Red
Ry 0.2867 0.3366 0.3847
Gx 0.2464 0.2964 0.3460
Color / Green
Gy 0.5922 0.6421 0.6902
Chromaticity
Coodinates Bx CIE 1931 0.0927 0.1427 0.1923 5
Blue
By 0.0000 0.0383 0.0864
Wx 0.2675 0.3175 0.3671
White
Wy 0.2680 0.3179 0.3660
NTSC (u'v') % - 100 -
2D Image sticking There must not be image sticking in
Immediately after againg 9
the entire checker pattern
B160HW02 V0 Document Version : 1.1 7 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Gray(L31) is displayed for Using 13% ND
30minutes after againg No image sticking
filter
3D Image sticking There must not be image sticking in
Immediately after againg 9
the entire checker pattern
Gray(L31) is displayed for Using 13% ND
30minutes after againg No image sticking
filter
Note 1: Turn off the white balance and measure it.
Note 2: Luminance measure point
2D still: The average value of the brightness of five points.
2D animation/ 3D: The brightness of center point
Note 3: The above test limit must be applied for initial use. Characteristics will be shifted by long period
operation, but it is not irregular phenomena. Theoretically brightness characteristics will be decreased due to
LED degradation and color shift due to optical components change.
Note 4: 9 positions position (Ref: Active area)
B160HW02 V0 Document Version : 1.1 8 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 5: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting
Backlight for 30 minutes in a stable, windless and dark room, and it should be measured in the center of screen. ! !
Photo detector
Field=2
50 cm
LCD Panel TFT-LCD Module
Note 6 Definition of contrast ratio:
Center of the screen
Contrast ratio is calculated with the following formula.
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 7: Definition of response time: measured by Westar TRD-100A
The output signals of photo detector are measured when the input signals are changed from "Black" to "White"
(rising time, TrR), and from "White" to "Black" (falling time, TfF), respectively. The response time is interval
B160HW02 V0 Document Version : 1.1 9 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
between the 10% and 90% of amplitudes. Refer to figure as below.
B160HW02 V0 Document Version : 1.1 10 of 40
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Note 8. Definition of viewing angle
Viewing angle is the measurement of contrast ratio 10, at the screen center, over a 180◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
