Image preview - the first page of the document
![Panel_AUO_G121SN01_V4_0_[DS]](/pics/5c36abcd2f897.gif)
>> Download Panel_AUO_G121SN01_V4_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
( ) Preliminary Specifications
( V ) Final Specifications
Module 12.1 Inch Color TFT-LCD
Model Name G121SN01 V4
Customer Date Approved by Date
Leader Feng 2011/08/30
Checked &
Prepared by
Approved by
Alan Chen
A 2011/08/30
Note: This Specification is subject to change General Display Business Division /
without notice. AU Optronics corporation
G121SN01 V4 rev. 1.3
Page 1/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
Contents
1. Operating Precautions.....................................................................................4
2. General Description .........................................................................................5
2.1 Display Characteristics...........................................................................................................5
2.2 Optical Characteristics ...........................................................................................................6
3. Functional Block Diagram ...............................................................................9
4. Absolute Maximum Ratings ..........................................................................10
4.1 Absolute Ratings of TFT LCD Module .................................................................................10
4.2 Absolute Ratings of Environment ........................................................................................10
5. Electrical Characteristics ..............................................................................11
5.1 TFT LCD Module .................................................................................................................. 11
5.2 Backlight Unit........................................................................................................................13
6. Signal Characteristics ...................................................................................14
6.1 Pixel Format Image ..............................................................................................................14
6.2 Scanning Direction ...............................................................................................................14
6.3 TFT-LCD Interface Signal Description .................................................................................15
6.4 The Input Data Format .........................................................................................................16
6.5 TFT-LCD Interface Timing ....................................................................................................17
6.6 Power ON/OFF Sequence ...................................................................................................18
7. Connector & Pin Assignment ........................................................................19
7.1 TFT-LCD Signal (CN1): LCD Connector .............................................................................19
7.2 LED Backlight Unit (CN2): Backlight Connector .................................................................19
8. Reliability Test Criteria ..................................................................................20
9. Mechanical Characteristics ...........................................................................21
9.1 LCM Outline Dimension (Front View) ..................................................................................21
9.2 LCM Outline Dimension (Rear View)(Pin 1 position) ..........................................................22
10. Label and Packaging....................................................................................23
10.1 Shipping Label (on the rear side of TFT-LCD display) ......................................................23
10.2 Carton Package .................................................................................................................23
11 Safety.............................................................................................................24
11.1 Sharp Edge Requirements.................................................................................................24
11.2 Materials .............................................................................................................................24
11.3 Capacitors...........................................................................................................................24
11.4 National Test Lab Requirement..........................................................................................24
G121SN01 V4 rev. 1.3
Page 2/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
Record of Revision
Version and Date Page Old description New Description
0.0 2009/02/03 All First Edition
Color / Chromaticity
1.0 2009/05/14 6 Add Min., Typ., Max.
Coordinates(Red x y, Green x y, Blue x y): TBD
13 Parameter guideline for LED backlight Add VF, IF, PLED
Dimming Duty cycle Min: TBD Dimming Duty cycle Min: 5
Add LED Backlight Unit (CN4): Light bar
19 Connector & Pin Assignment
Connector
22 LCM Outline Dimension (Rear View) Add CN4 drawing
23 Label and Packaging Add Shipping Label, Carton Package
1.1 2010/10/15 10 Add wet bulb chart
13 Remove Irush LED
18 Power ON/OFF Sequence: T3= 200ms Power ON/OFF Sequence: T3= 175ms
1.2 2011/03/23 16 Add 8 Bit signal description
1.3 2011/08/30 21 Update Drawing_add tolerance
G121SN01 V4 rev. 1.3
Page 3/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) To avoid ESD (Electro Static Discharde) damage, be sure to ground yourself before handling
TFT-LCD Module.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the LED light bar edge. Instead, press
at the far ends of the LED light bar edge softly. Otherwise the TFT Module may be
damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very
short time. Please design your display product well to avoid external force applying to module
by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time and lamp
ignition voltage.
14) Continuous operating TFT-LCD display under low temperature environment may accelerate
lamp exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when LCD module is placed in landscape
position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or shuffle content periodically if fixed pattern is displayed on the screen.
G121SN01 V4 rev. 1.3
Page 4/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
2. General Description
This specification applies to the Color Active Matrix Liquid Crystal Display G121SN01 V4
composed of a TFT-LCD display, a driver and power supply circuit, and a LED backlight system.
The screen format is intended to support SVGA (800(H) x 600(V)) screen and 16.2M (RGB
8-bits) or 262k colors (RGB 6-bits).
LED driving board for backlight unit is included in G121SN01 V4 and the LED unit is replaceable.
All input signals are LVDS interface and compatible with G121SN01 V3.
G121SN01 V4 designed with wide viewing angle; wide temperature and long life LED backlight is
well suited for industial applications.
G121SN01 V4 is a RoHS product.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 12.1
Active Area [mm] 246 (H) x 184.5 (V)
Pixels H x V 800 x 3(RGB) x 600
Pixel Pitch [mm] 0.3075 x 0.3075
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 (typ.)
6.7 W
Typical Power Consumption [Watt]
All black pattern
Weight [Grams]
Gra 580 (Max.)
Physical Size [mm]
[m
m 279.0(H) x 209.0(V) x 9.0(D) (Typ.)
Electrical Interface 1 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 16.2M / 262K colors
Temperature Range
o
Operating [ C] -30 to +85
o
ratin
Storage (Non-Operating) [ C] -30 to +85
RoHS Compliance
e RoHS Compliance
G121SN01 V4 rev. 1.3
Page 5/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
2.2 Optical Characteristics
Item Unit Conditions Min. Typ. Max. Remark
IF= 80mA/1 LED Line
White Luminance [cd/m2] 330 450 - Note 1
(center point)
Uniformity % 5 Points 75 - - Note 2, 3
Contrast Ratio 500 700 - Note 4
[msec] Rising - 25 35
Response Time [msec] Falling - 10 20 Note 5
[msec] Raising + Falling - 35 55
[degree] Horizontal (Right) 70 80 -
[degree] CR = 10 (Left)
70 80 -
Viewing Angle Note 6
[degree] Vertical (Upper) 55 65 -
[degree] CR = 10 (Lower)
65 75 -
Red x 0.556 0.606 0.656
Red y 0.300 0.350 0.405
Green x 0.254 3
0.304 0.354
Color / Chromaticity Green y 0.527 0.5
0.577 0.627
Coordinates
(CIE 1931) Blue x 99
9
0.099 0.149 0.199
Blue y 0.077 0.127 0.177
White x 0
0.263 0.313 0.363
White y 0.279 0.329 0.379
Color Gamut % 55 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture
Test Point Center
Environment < 1 lux
LCD Module
SR_3 or
equivalent
Measuring distance
Module Driving Equipment
G121SN01 V4 rev. 1.3
Page 6/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121SN01 V4
Note 2: Definition of 5 points position (Display active area: 246mm (H) x 184.5mm (V))
W
W /4 W /4 W /4 W /4
H /4
1 2
H /4
H 3
H /4
4 5
H /4
Note 3: The luminance uniformity of 5 points is defined by dividing the minimum luminance values by the
maximum test point luminance
Minimum Brightness of five points
W9 =
Maximum Brightness of five points
Note 4: Definition of contrast ratio (CR):
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 5: Definition of response time:
The output signals of photo detector are measured when the input signals are changed from "White" to
"Black" (falling time) and from "Black" to "White" (rising time), respectively. The response time interval is
between 10% and 90% of amplitudes. Please refer to the figure as below.
% Tf Tr
100
90
Optical
White
e Black White
response
10
0
Note 6: Definition o vi
n of viewing angle
Viewing angl
ga
