Image preview - the first page of the document
![Panel_AUO_G121XN01_V0_0_[DS]](/pics/5c36abdd9e60a.gif)
>> Download Panel_AUO_G121XN01_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G121XN01 V0
( ) Preliminary Specifications
( V ) Final Specifications
Module 12.1 Inch Color TFT-LCD
Model Name G121XN01 V0
Customer Date Approved by Date
Debbie Chiu 2010/06/18
Checked &
Prepared by
Approved by
Vivian Huang 2010/06/18
Note: This Specification is subject to change General Display Business Division /
without notice. AU Optronics corporation
G121XN01 V0 rev. 1.1
Page 1/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121XN01 V0
Contents
1. Operating Precautions.....................................................................................4
2. General Description .........................................................................................5
2.1 Display Characteristics...........................................................................................................5
2.2 Optical Characteristics ...........................................................................................................6
3. Functional Block Diagram ...............................................................................9
4. Absolute Maximum Ratings ..........................................................................10
4.1 Absolute Ratings of TFT LCD Module .................................................................................10
4.2 Absolute Ratings of Environment ........................................................................................10
5. Electrical Characteristics ..............................................................................11
5.1 TFT LCD Module .................................................................................................................. 11
5.2 Backlight Unit........................................................................................................................13
6. Signal Characteristics ...................................................................................14
6.1 Pixel Format Image ..............................................................................................................14
6.2 Scanning Direction ...............................................................................................................14
6.3 TFT-LCD Interface Signal Description .................................................................................15
6.4 The Input Data Format .........................................................................................................16
6.5 TFT-LCD Interface Timing ....................................................................................................17
6.6 Power ON/OFF Sequence ...................................................................................................18
7. Connector & Pin Assignment ........................................................................19
7.1 TFT-LCD Signal (CN1): LCD Connector .............................................................................19
7.2 LED Backlight Unit (CN2): Backlight Connector .................................................................19
8. Reliability Test Criteria ..................................................................................20
9. Mechanical Characteristics ...........................................................................21
9.1 LCM Outline Dimension (Front View) ..................................................................................21
9.2 LCM Outline Dimension (Rear View)(Pin 1 position) ..........................................................21
10. Label and Packaging....................................................................................23
10.1 Shipping Label (on the rear side of TFT-LCD display) ......................................................23
10.2 Carton Package .................................................................................................................23
11 Safety.............................................................................................................24
11.1 Sharp Edge Requirements.................................................................................................24
11.2 Materials .............................................................................................................................24
11.3 Capacitors...........................................................................................................................24
11.4 National Test Lab Requirement..........................................................................................24
G121XN01 V0 rev. 1.1
Page 2/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121XN01 V0
Record of Revision
Version and Date Page Old description New Description
0.0 2009/09/14 All First Edition
0.1 2009/12//11 21 LCM outline dimension (Front view) Update mounting help position
22 LCM outline dimension (Rear view) Update pin assignment
0.2 2010/01/08 16 The input data format Update SEL68 input data format
1.0 2010/04/26 5 Typical power consumption: TBD Typical power consumption: 9.15W
Temperature Range Temperature Range
o o
5 Operating : -30 to +80 C Operating : -30 to +85 C
o o
Storage (Non-Operating): -30 to +80 C Storage (Non-Operating): -30 to +85 C
6 White Luminance condition: IF= 120mA White Luminance condition: IF= 110mA
Color / Chromaticity
6 Add Min., Typ., Max.
Coordinates : TBD
Absolute Ratings of Environment Absolute Ratings of Environment
10 o o
Temperature : Max 80 C Temperature : Max 85 C
LCD Input Current: TBD
11 Add Typ., Max.
LCD Power consumption: TBD
LCD Inrush Current: TBD
11 Add Max.
Allowable Logic/LCD Drive Ripple Voltage: TBD
12 Differential Input Common Mode Voltage: TBD Add Typ.
13 Parameter guideline for LCD: TBD Add Typ., Max.
15 TFT-LCD Interface Signal Description Add Note 4, Note 5
16 CLK Data Clock frequency 40MHz CLK Data Clock frequency 65 MHz
23 Label and Packaging Add Shipping Label, Carton Package
1.1 2010/06/18 10 Add wet bulb chart
G121XN01 V0 rev. 1.1
Page 3/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121XN01 V0
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) To avoid ESD (Electro Static Discharde) damage, be sure to ground yourself before handling
TFT-LCD Module.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the LED light bar edge. Instead, press
at the far ends of the LED light bar edge softly. Otherwise the TFT Module may be
damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very
short time. Please design your display product well to avoid external force applying to module
by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time and lamp
ignition voltage.
14) Continuous operating TFT-LCD display under low temperature environment may accelerate
lamp exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when LCD module is placed in landscape
position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or shuffle content periodically if fixed pattern is displayed on the screen.
G121XN01 V0 rev. 1.1
Page 4/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121XN01 V0
2. General Description
This specification applies to the Color Active Matrix Liquid Crystal Display G121XN01 V0
composed of a TFT-LCD display, a driver and power supply circuit, and a LED backlight system.
The screen format is intended to support XGA (1024(H) x 768(V)) screen and 16.2M (RGB 8-bits)
or 262k colors (RGB 6-bits).
LED driving board for backlight unit is included in G121XN01 V0 and the LED unit is replaceable.
All input signals are LVDS interface and compatible with G121SN01 V3 and G121SN01 V4.
G121XN01 V0 designed with wide viewing angle; wide temperature and long life LED backlight is
well suited for industial applications.
G121XN01 V0 is a RoHS product.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 12.1
Active Area [mm] 245.76 (H) x 184.32 (V)
Pixels H x V 1024 x 768
Pixel Pitch [mm] 0.24 x 0.24
Pixel Arrangement R.G.B.W Rectangle
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 (typ.)
9.15(typ.)
Typical Power Consumption [Watt]
All black pattern
Weight [Grams] 495 (Max.)
Physical Size [mm] 279.0(H) x 209.0(V) x 9.0(D) (Max.)
Electrical Interface 1 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 16.2M / 262K colors
Temperature Range
o
Operating [ C] -30 to +85
o
Storage (Non-Operating) [ C] -30 to +85
RoHS Compliance RoHS Compliance
G121XN01 V0 rev. 1.1
Page 5/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G121XN01 V0
2.2 Optical Characteristics
