Image preview - the first page of the document

>> Download Panel_AUO_G156XW01_V1_2_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

Product Specification G156XW01 V1
AU OPTRONICS CORPORATION

() Preliminary Specification
( V ) Final Specification

Module 15.6" Color TFT-LCD

Model Name G156XW01 V1

Customer Date Approved by Date

Debblie Chiu 2012/8/3

Approved by Prepared by

Christine Huang 2012/8/3

Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation

document version 1.1 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G156XW01 V1
AU OPTRONICS CORPORATION

Contents

1.0 Handling Precautions............................................................. 4
2.0 General Description ............................................................... 5
2.1 Display Characteristics.................................................................................................................... 5
2.2 Optical Characteristics .................................................................................................................... 6
3.0 Functional Block Diagram .................................................... 10
4.0 Absolute Maximum Ratings ................................................. 11
4.1 TFT LCD Module............................................................................................................................ 11
4.2 Absolute Ratings of Environment ................................................................................................ 11
5.0 Electrical characteristics...................................................... 12
5.1 TFT LCD Module............................................................................................................................ 12
5.1.1 Power Specification.............................................................................................. 12
5.1.2 Signal Electrical Characteristics.............................................................................. 13
5.2 Backlight Unit.................................................................................................................................. 14
6.0 Signal Characteristic............................................................ 15
6.1 Pixel Format Image........................................................................................................................ 15
6.2 The input data format .................................................................................................................... 15
6.3 Signal Description.......................................................................................................................... 16
6.4 Timing Characteristics ................................................................................................................... 18
6.5 Timing diagram ..................................................................................................... 19
6.6 Power ON/OFF Sequence ........................................................................................................... 20
7.0 Connector & Pin Assignment ............................................... 21
7.1 TFT LCD Module............................................................................................................................ 21
7.1.1 Pin Assignment ................................................................................................... 21
7.2 Backlight Unit.................................................................................................................................. 22
7.2.1 LED Driver Connector Pin Assignment ..................................................................... 22
8.0 Reliability Test..................................................................... 23
9.0 Shipping Label ..................................................................... 24
9.1 Carton Package ............................................................................................................................. 25
10.0 Mechanical Characteristics ................................................ 26

document version 1.1 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G156XW01 V1
AU OPTRONICS CORPORATION

Record of Revision
Version and Date Page Old description New Description Remark
0.0 2011/5/24 First Edition for Customer N/A

1.0 2011/7/19 5 All input signals are LVDS interface All input signals are LVDS interface
and this module doesn't contain an and this module contains with an LED
inverter board for backlight. driver for backlight.
o
5 Operating: 0 to +50 Operating: 0 to +60(+60 C as panel
surface temperature)
11 Operating Temperature max: +50 Operating Temperature max: +60

11 NA Note 4

14 Parameter guideline for LED Inverter Parameter guideline for LED driver is
o o
is under stable conditions at 25 C under stable conditions at 25 C
23 THO: Ta= 50 oC, 50%RH, 300hours THO: Ta= 60 oC, 300hours

1.1 2012/8/3 26 No Packaging Spec Add Carton Package information

document version 1.1 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G156XW01 V1
AU OPTRONICS CORPORATION

1.0 Handling Precautions

1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken
out from the container, do not press the center of the LED reflector edge. Instead, press at the
far ends of the LED Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very
short time. Please design your display product well to avoid external force applying to module
by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time.
14) Continuous operating TFT-LCD Module under high temperature environment may accelerate
LED light bar exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when TFT-LCD module is placed in
landscape position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or moving content periodically if fixed pattern is displayed on the screen.

document version 1.1 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G156XW01 V1
AU OPTRONICS CORPORATION

2.0 General Description
This specification applies to the 15.6 inch-wide Color a-Si TFT-LCD Module G156XW01.The
display supports the HD - 1366(H) x 768(V) screen format and 16.7M colors (RGB 6-bits + Hi-FRC
data). All input signals are LVDS interface and this module contains with an LED driver for
backlight.

2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:

ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 15.6"
Active Area [mm] 344.232 (H) x 193.536 (V)
Pixels H x V 1366(x3) x 768
Pixel Pitch [um] 252 (per one triad)
