Image preview - the first page of the document
![Panel_AUO_G150XG03_V1_1_[DS]](/pics/5c36ac01941fa.gif)
>> Download Panel_AUO_G150XG03_V1_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
AU OPTRONICS CORPORATION
Product Specification
15.0" XGA Color TFT-LCD Module
Model Name: G150XG03 V.1
Approved by Prepared by
Peter ML Lee Daniel Chi
GDBD Marketing Division / AU Optronics corporation
Customer Checked & Approved by
G150XG03 V1 ver 0.0 1/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
Document Version: 0.0
Total Pages: 33
Date: 6/30/2006
Product Specification
15.0" XGA Color TFT-LCD Module
Model Name: G150XG03
V.1
( ) Preliminary Specifications
( ) Final Specifications
Note: This Specification is subject to change without notice.
G150XG03 V1 ver 0.0 2/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
Contents
1.0 Handling Precautions .........................................................................................5
2.0 General Description............................................................................................6
2.1 Display Characteristics .............................................................................................................. 6
2.2 Optical Characteristics ............................................................................................................... 7
3.0 Functional Block Diagram................................................................................11
4.0 Absolute Maximum Ratings.............................................................................12
4.1 TFT LCD Module ...................................................................................................................... 12
4.2 Backlight Unit ............................................................................................................................ 12
4.3 Absolute Ratings of Environment ............................................................................................ 12
5.0 Electrical characteristics..................................................................................13
5.1 TFT LCD Module ...................................................................................................................... 13
5.2 Parameter Guideline for CCFL Inverter ................................................................................. 15
6.0 Signal Characteristic ........................................................................................16
6.1 Pixel Format Image................................................................................................................... 16
6.2 Input Data Format ..................................................................................................................... 17
6.3 Signal Description .................................................................................................................... 18
6.4 Interface Timing ........................................................................................................................ 19
6.5 Power ON/OFF Sequence ....................................................................................................... 21
7.0 Connector & Pin Assignment ..........................................................................22
7.1 TFT LCD Module ...................................................................................................................... 22
7.2 Backlight Unit ............................................................................................................................ 24
7.3 Signal for Lamp Connector ...................................................................................................... 24
8.0 Reliability ...........................................................................................................25
9.0 Shipping and Packing.......................................................................................26
9-1 Shipping Label Format............................................................................................................. 26
9-2 Carton Package ........................................................................................................................ 26
10.0 Safety ...............................................................................................................27
10.1 Sharp Edge Requirements .................................................................................................... 27
10.2 Materials .................................................................................................................................. 27
10.3 Capacitors ............................................................................................................................... 27
11.0 Other Requirement .........................................................................................27
11.1 National Test Lab Requirement ............................................................................................. 27
12.0 Mechanical Characteristics............................................................................28
G150XG03 V1 ver 0.0 3/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
Record of Revision
Version and
Page Old description New Description Remark
Date
0.0 2006/06/30 All First Edition
G150XG03 V1 ver 0.0 4/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press or pat the panel surface by fingers,hand or tooling.
9) Do not press the reflector sheet at the back of the module to any directions.
10) In case if a module has to be put back into the packing container slot after once it was taken out from the
container, do not press the center of the CCFL reflector edge. Instead, press at the far ends of the CCFL
reflector edge softly. Otherwise the TFT module may be damaged.
11) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT module.
12) After installation of the TFT module into an enclosure (Desktop monitor Bezel, for example), do not twist
nor bend the TFT Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT module from outside. Otherwise the
TFT module may be damaged.
G150XG03 V1 ver 0.0 5/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
2.0 General Description
This specification applies to the 15.0 inch Color TFT/LCD Module G150XG03 V1.
This module is designed for industrial applications.
The display supports the XGA (1024 (H) x 768(V)) screen format and 16.2M colors (RGB 6-bits + FRC data)/262K
(RGB 6-bit) selectable.
All input signals are 1 Channel LVDS interface compatible.
This module does not contain an inverter card for backlight.
All the design rules of this module can correspond to PSWG standared.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 381 (15")
Active Area [mm] 304.128 (H) x 228.096
Pixels H x V 1024(x3) x 768
Pixel Pitch [mm] 0.297 (per one triad) x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN mode, Normally White
White Luminance [cd/m2] 250 (Typ) @ 6.0mA
Contrast Ratio 500
Response Time [msec] 12 (Typ) (Note 1)
Color Saturation 65% NTSC (Typ)
Nominal Input Voltage VDD [Volt] +3.3 V
Power Consumption [Watt] 10.7 W (Typ.) @6.0mA (Gray Bar Pattern)
(VDD line + CCFL line)
Weight [Grams] 1150 (Typ)
Physical Size [mm] Min. Typ. Max.
Horizatal(H) 326.0 326.5 327.0
Vertical(V) 253.0 253.5 254.0
Depth(D) - - 12.0
Electrical Interface 1 Channel LVDS
Support Color 16.2M colors (RGB 6-bit + FRC data)/262k(RGB 6-bit)
selectable
Temperature Range
o
Operating [ C] 0 to +50
o
Storage (Shipping) [ C] -20 to +60
Surface Treatment Hard-coating (3H), anti-glare treatment
ROHS RoHS Compliance
Note 1 :System should warm up for at least one hour
G150XG03 V1 ver 0.0 6/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 60 70
- -
CR = 10 (Left) 60 70
Vertical (Up) 55 65
-
CR = 10 (Down) 45 55
Viewing Angle [degree]
Horizontal (Right) 65 75
-
CR = 5 (Left) 65 75
Vertical (Up) 65 75
-
CR = 5 (Down) 65 75
Contrast ratio Normal Direction 400 500 - -
Rising Time - 8.5 11
Response Time [msec] Falling Time - 3.5 5 Note 1
Rising + Falling - 12 -
Red x 0.612 0.642 0.672
Red y 0.307 0.337 0.367
Color / Chromaticity Green x 0.276 0.306 0.336
Coordinates (CIE) Green y 0.551 0.581 0.611
Blue x 0.114 0.144 0.174
Blue y 0.071 0.101 0.131
Color Coordinates (CIE) White x 0.283 0.313 0.343
White White y 0.299 0.329 0.359
White Luminance @ IRCFL [cd/m ]
2
6mA (center) 200 250 -
Luminance Uniformity [%] 75 80 Note 2
Crosstalk (in 75Hz) [%] 1.2 1.5 Note 3
Flicker dB -20 Note 4
Equipment: Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (PR 880, BM-5A ,
BM 7 ,CS-1000, CA210, SR_3 & EZ Contrast(ELDIM)* )
Aperture 1 with 50cm viewing distance
Test Point Center (VESA point 9)
Environment < 1 lux
LCD Module
PR-880 /
BM5A /
BM7
measuring distance
Module Driving Equipment
* EZ Contrast is a different measurement tool with very close viewing distance.
G150XG03 V1 ver 0.0 7/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG03 V.1
Product Specification
Note 1: Definition of Response time
The output signals of photo detector are measured when the input signals are changed from"Full Black" to "Full
White" (rising time), and from "Full White" to "Full Black" (falling time), respectively. The response time is interval
between the 10% and 90% of amplitudes.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
Note 2: Brightness uniformity of these 9 points is defined as below
90 % 50 % 10 %
10 %
50 %
90 %
Minimum Luminance in 9 points (1 - 9)
