Image preview - the first page of the document
![Panel_AUO_G150XG01_V0_0_[DS]](/pics/5c36ac2a83c38.gif)
>> Download Panel_AUO_G150XG01_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
AU OPTRONICS CORPORATION
Product Specification
15.0" XGA Color TFT-LCD Module
Model Name: G150XG01 V.0
Approved by Prepared by
ML Lee Daniel Chi
GDBD Marketing Division / AU Optronics corporation
Customer Checked & Approved by
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 1/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
Version: 5.1
Date: Aug 22, 2006
Product Specification
15.0" XGA Color TFT-LCD Module
Model Name: G150XG01
V.0
Final Specifications
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 2/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
Contents
1.0 HANDLING PRECAUTIONS.............................................................7
2.0 GENERAL DESCRIPTION................................................................8
2.1 Display Characteristics....................................................................................... 9
2.2 Functional Block Diagram ................................................................................ 10
3.0 ABSOLUTE MAXIMUM RATINGS .................................................. 11
4.0 OPTICAL CHARACTERISTICS ......................................................12
5.0 SIGNAL INTERFACE ......................................................................16
5.1 Module Interface Connectors ........................................................................... 16
5.2 Module Connector Pin Configuration............................................................... 16
5.3 Backlight Connectors ....................................................................................... 17
5.4 Backlight Connector Pin Configuration ............................................................ 17
5.5 Signal Electrical Characteristics....................................................................... 17
5.6 Interface Timing Characteristics....................................................................... 19
5.7 Interface Timing Definition ............................................................................... 20
6.0 PIXEL FORMAT IMAGE..................................................................21
7.0 POWER CONSUMPTION ...............................................................22
8.0 POWER ON/OFF SEQUENCE........................................................22
9.0 BACKLIGHT CHARACTERISTICS.................................................23
9.1 Signal for Lamp connector.............................................................................. 23
9.2 Parameter guide line for CCFL Inverter......................................................... 23
10.0 VIBRATION, SHOCK, AND DROP................................................24
10.1 Vibration & Shock.......................................................................................... 24
10.2 Drop ............................................................................................................... 24
11.0 ENVIRONMENT ............................................................................25
11.1 Temperature and Humidity............................................................................ 25
11.2 Atmospheric Pressure ................................................................................... 25
11.3 Thermal Shock .............................................................................................. 25
12.0 RELIABILITY ................................................................................26
12.1 Failure Criteria............................................................................................... 26
12.2 Failure Rate ................................................................................................... 26
12.3 CCFL Life....................................................................................................... 26
12.4 ON/OFF Cycle ............................................................................................... 26
13.0 SAFETY ........................................................................................27
13.1 Sharp Edge Requirements ........................................................................... 27
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 3/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
13.2 Materials ........................................................................................................ 27
14.0 OTHER REQUIREMENTS ............................................................27
14.1 Smoke Free Design ...................................................................................... 27
14.2 National Test Lab Requirement .................................................................... 27
15.0 LABEL ..........................................................................................28
16.0 CARTON PACKAGE.....................................................................28
17.0 MECHANICAL CHARACTERISTICS ............................................29
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 4/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
ii Record of Revision
Version and Date Chapter Old description New Description Remark
1.0 Feb. 6, 2004 All N/A First Edition for Customers
Anti-glare, hard coating (3H), low Surface
2.0 Aug.16, 2004 2.1 Anti-glare, hard coating (3H) reflection treatment
White
Luminance
Aug.16, 2004 4.0 Min. 320 nits Min. 300 nits
@ CCFL
6.5mA
Lamp life: 50,000 hrs (typ.)
Aug.16, 2004 9.2 Ambient temp 20 ~35 (with no
wind)
This module comforming to RoHS
directive is available starting from
3.0 Sept. 23, 2005 2.0 N/A
Q3 2005.
Add shipping label figure
2.1 N/A Weight 1150g (max)
2.1 Low reflection Remove low reflection
2.1/4.0 Contrast Ratio 400:1 (typ) Contrast Ratio 500:1 (typ)
Operating Humidity 8~90%
Operating Humidity 20~80%
3.0 Storage Humidity 8~90%
Storage Humidity 5~95%
Update wet bulb temperature chart
4.0 N/A Add optical characteristic notes
9.2 Lamp life typical 50,000 hrs Lamp life minumn 50,000 hrs
Green Design (RoHS) version label
2.0/15.0 Non green design label sample
sample
4.0 Nov. 21, 2005 2.1 View Angle 60/60/40/60 View Angle 65/65/65/55
Color Gamut 60% (Typ.) of NTSC Color Gamut 65% (Typ.) of NTSC
coverage coverage
4.0 Optical Characteristics Optical Characteristics
Conditions Min. Typ. Max. Conditions Min. Typ. Max.
Horizontal Horizontal
CR 10 CR 10
(Right) 50 60 (Right) 55 65
(Left) (Left)
50 60 55 65
- -
CR 5 60 75 CR 5 65 75
(Right) (Right)
(Left) 60 75 (Left) 65 75
Vertical Vertical
CR 10 30 40 CR 10 55 65
(Upper) (Upper)
50 60 45 55
(Lower) - (Lower) -
CR 5 45 50 CR 5 65 75
(Upper) (Upper)
(Lower) 65 75 (Lower) 55 65
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 5/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
4.0 Raising Time
Ton - 4 6 Raising Time - 8.8 -
( 10%-90% )
Falling Time Toff
- 12 17 Falling Time - 3.2 -
( 90%-10% )
Raising + Falling - 16 23 Raising + Falling - 12 -
Red x 0.587 0.617 0.647 Red x 0.610 0.640 0.670
Red y 0.317 0.347 0.377 Red y 0.300 0.330 0.360
Green x 0.260 0.290 0.320 Green x 0.270 0.300 0.330
Green y 0.563 0.593 0.623 Green y 0.560 0.590 0.620
Blue x 0.118 0.148 0.178 Blue x 0.120 0.150 0.180
Blue y 0.070 0.100 0.130 Blue y 0.070 0.100 0.130
White x 0.283 0.313 0.343 White x 0.280 0.310 0.340
White y 0.299 0.329 0.359 White y 0.300 0.330 0.360
Note 3: Definition of Response time Note 3: Definition of Response time
"Black" to "White" (falling time), "Full Black" to "Full White" (falling time),
"White" to "Black" (rising time) "Full White" to "Full Black" (rising time)
5.0 Feb. 27, 2006 2.1 Description for Brightness Uniformity,
Move to Chapter 4.0
Crosstalk, White Luminance
2.0 Product Shipping Label Move to Chapter 15.0
15.0 Mechanical Characteristics Move to Chapter 16.0
5.1 Aug. 22, 2006 16.0 Add "16.0 Carton Package"
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 6/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
1.0 Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open nor modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out from the
container, do not press the center of the CCFL Reflector edge. Instead, press at the far ends of the CFL
Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure (LCD monitor housing, for example), do not twist nor
bend the TFT Module even momentary. At designing the enclosure, it should be taken into consideration
that no bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local ordinances
or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (2.11, IEC60950 or
UL1950), or be applied exemption.
14) The LCD module is designed so that the CFL in it is supplied by Limited Current Circuit (2.4, IEC60950 or
UL1950). Do not connect the CFL in Hazardous Voltage Circuit.
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 7/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
2.0 General Description
This specification applies to the 15.0 inch Color TFT-LCD Module G150XG01.
The display supports the XGA (1024(H) x 768(V)) screen format and 262,144 colors (RGB 6-bits data).
All input signals are 1 Channel LVDS interface compatible.
This module does not contain an inverter card for backlight.
This module comforming to RoHS directive is available starting from Q3 2005.
Features
-XGA 1024(H) x 768(V) resolution
- 50,000 hours lamp life
-2 CCFLs (Cold cathode Fluorescent Lamp)
-High contrast ratio, high aperture ratio
-Wide viewing angle
-High-speed response
-Low power consumption
Application
Industrial Applications
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 8/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen diagonal [mm] 381 (15")
Outline dimension [mm] 326.5 (Typ.) x 253.5 (Typ.) x 12.0 (Max.)
Display Area [mm] 304.128 (H) x 228.096(38.1cm diagonal)
Resolution 1024(R,G,B x 3) x 768
Pixel Pitch [mm] 0.297 x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN mode, Normally White
2
Typical white Luminance. [cd/m ] 350nit (Typ.) @ 6.5mA
Contrast Ratio 500 : 1 (Typ.)
Support Colors 262,144 colors (6-bit for R,G,B)
Chromaticity(CIE1931)
White-x 0.313
White-y 0.329
Color Gamut 65% (Typ.) of NTSC coverage
Viewing angle (L/R/U/D) 65/65/65/55 (CR 10)
Response Time [msec] 12ms (Typ.) (Tr +Tf)
Nominal Input Voltage VDD [Volt] +3.3 V
Power Consumption [Watt] 11.5 W (Typ.) @6.5mA (All Black Pattern)
(VDD line + CCFL line)
Electrical Interface LVDS (1 Ch)
Frame rate [Hz] 60Hz (Typ.), 75Hz (Max.)
Weight [Grams] 1100 (Typ.) 1150 (Max.)
Mounting method Side mounting
Surface treatment Anti-glare, hard coating (3H)
Temperature Range
Operating [oC] 0 to +50
Storage (Shipping) [oC] -20 to +60
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 9/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
2.2 Functional Block Diagram
The following diagram shows the functional block of 15.0 inches Color TFT-LCD Module:
LVDS
AU ASIC
G1
+ 3.3 V
Timing TFT-LCD
Y-Driver IC
Controller
1024*(3)*768
LVDS
Pixels
Connector
Receiver
RSDS
Transmitter
X-Driver IC
G768
D1 D3072
2 CCFL
DC/DC Gamma
Converter Correc
tion
DC POWER
Inverter
DF-14H-20P-1.25H (Hirose) JST BHR-03VS-1
CWY20G-A0D1T (PTWO)
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 10/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
3.0 Absolute Maximum Ratings
Absolute maximum ratings of the module is as following:
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VDD -0.3 +3.6 [Volt]
Input Voltage of Signal Vin -0.3 +3.6 [Volt]
CCFL Current ICFL 2.5 8.5 [mA] rms Note 1
Operating Temperature TOP 0 +50 [oC] Note 2
Operating Humidity HOP 8 90 [%RH] Note 2
o
Storage Temperature TST -20 +60 [ C] Note 2
Storage Humidity HST 8 90 [%RH] Note 2
Vibration - 1.5 / 10-200 [G / Hz]
Shock - 50/20 [G / ms] Half sine wave
Note 1: CCFL life time will drop dramatically if exceeding 6.5 mA; It will have safety concern if exceeding 8.5 mA.
Note 2: Maximum Wet-Bulb should be 39 and No condensation.
Note 3: For quality performance, please refer to AUO IIS (Incoming Inspection Standard). Please refer to the graph
below for corresponding of temperature and humidity.
Wet bulb temperature chart
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 11/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
4.0 Optical Characteristics
Optical characteristics are determined after the unit has been `ON' and stable for approximately 30 minutes in a dark
environment at 25 . The values specified are at an approximate distance 50cm from the LCD surface at a viewing
angle of and equal to 0 .
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right)
1
55 65
CR 10 (Left)
55 65
Viewing Angle [degree] -
(Right) 65 75
65 75
CR 5 (Left)
Vertical (Upper)
55 65
CR 10 (Lower)
45 55
[degree] -
(Upper) 65 75
CR 5 (Lower) 55 65
Contrast ratio Normal Direction 400 500 - 2
Response Time( Note 1) [msec] Raising Time - 8.8 - 3
[msec] Falling Time - 3.2 -
[msec] Raising + Falling - 12 -
Color / Chromaticity Red x 0.610 0.640 0.670
Coordinates (CIE) Red y 0.300 0.330 0.360
Green x 0.270 0.300 0.330
Green y 0.560 0.590 0.620
Blue x 0.120 0.150 0.180
Blue y 0.070 0.100 0.130
Color Coordinates (CIE) White White x 0.280 0.310 0.340
White y 0.300 0.330 0.360
Brightness Uniformity [%] 75 80 - 4,6
Crosstalk ( in 60Hz) [%] - - 1.2 5
2
White Luminance @ CCFL 6.5mA [cd/m ] 300 350 - 6
(C) Copyright AU Optronics, Inc. G150XG01 V.0
2006 All Rights Reserved. Spec version 5.1
No Reproduction and Redistribution Allowed 12/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V0
Note 1. Viewing Angle:
Viewing angle is the measurement of contrast ratio, at the screen center, over a 180◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
