Image preview - the first page of the document
![Panel_AUO_G150XG01_V4_1_[DS]](/pics/5c36ac43cc465.gif)
>> Download Panel_AUO_G150XG01_V4_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
( V ) Preliminary Specifications
( ) Final Specifications
Module 15 Inch Color TFT-LCD
Model Name G150XG01 V4
Customer Date Approved by Date
Vito Huang 2011/04/11
Checked &
Prepared by
Approved by
Linda Lee 2011/04/11
Note: This Specification is subject to change Audio-Video Business Unit /
without notice. AU Optronics corporation
G150XG01 V4 rev 0.1
1/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
Contents
1. Operating Precautions.....................................................................................4
2. General Description .........................................................................................5
2.1 Display Characteristics...........................................................................................................5
2.2 Touch
Characteristics...........................................................................................................6
2.3 Optical Characteristics ...........................................................................................................7
3. Functional Block Diagram .............................................................................11
4. Absolute Maximum Ratings ..........................................................................12
4.1 Absolute Ratings of TFT LCD Module .................................................................................12
4.2 Absolute Ratings of Environment ........................................................................................12
5. Electrical Characteristics ..............................................................................13
5.1 TFT LCD Module ..................................................................................................................13
5.2 Backlight Unit........................................................................................................................15
5.3 Touch
Unit..........................................................................................................................15
6. Signal Characteristic .....................................................................................16
6.1 Pixel Format Image ..............................................................................................................16
6.2 Scanning Direction ...............................................................................................................16
6.3 Signal Description ................................................................................................................17
6.4 The Input Data Format .........................................................................................................18
6.5 Interface Timing ....................................................................................................................20
6.6 Power ON/OFF Sequence ...................................................................................................21
7. Connector & Pin Assignment ........................................................................23
7.1 TFT-LCD Signal: LVDS Interface Connector .......................................................................23
7.2 LED Backlight Unit: LED Driver Connector .........................................................................25
7.3 LED Driver Connector Pin Assignment ...............................................................................25
8. Reliability Test Criteria ..................................................................................26
9. Mechanical Characteristics ...........................................................................27
9.1 LCM Outline Dimension (Front View) ..................................................................................27
9.2 LCM Outline Dimension (Rear View)...................................................................................28
10. Label and Packaging....................................................................................29
10.1 Shipping Label (on the rear side of TFT-LCD display) ......................................................29
10.2 Carton Package .................................................................................................................29
11 Safety.............................................................................................................30
11.1 Sharp Edge Requirements.................................................................................................30
11.2 Materials .............................................................................................................................30
11.3 Capacitors...........................................................................................................................30
11.4 National Test Lab Requirement..........................................................................................30
G150XG01 V4 rev 0.1
2/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
Record of Revision
Version and Date Page Old description New Description
Rev 0.1 2011/4/11 All First Edition
G150XG01 V4 rev 0.1
3/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the LED Reflector edge. Instead,
press at the far ends of the LED Reflector edge softly. Otherwise the TFT Module may
be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very
short time. Please design your display product well to avoid external force applying to module
by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time.
14) Continuous operating TFT-LCD Module under high temperature environment may accelerate
LED light bar exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when TFT-LCD module is placed in
landscape position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or moving content periodically if fixed pattern is displayed on the screen.
G150XG01 V4 rev 0.1
4/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
2. General Description
G150XG01 V4 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD display, a
touch sensor glass, a driver circuit, and a backlight system. The screen format is intended to
support XGA (1024(H) x 768(V)) screen and 16.2M (RGB 8-bits) or 262k colors (RGB 6-bits). All
input signals are LVDS interface compatible. All design rules of this module can correspond
to PSWG standard.
G150XG01 V4 is designed for industrial display applications.
2.1 Display Characteristics
o
The following items are characteristics summary on the table under 25 C condition:
Item Unit Specifications
Screen Diagonal [inch] 15
Active Area [mm] 304.128(H) x 228.096(V)
Pixels H x V 1024x2, 768x2 (RGBW)
Pixel Pitch [mm] 0.297 x 0.297
Pixel Arrangement R.G.B.W. Rectangle
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ.
Typical Power Consumption [Watt] 9.63 ( 64 Gray Bar pattern)
Weight [Grams] 1120g (max.)
Physical Size [mm] 326.5(H)x 253.5(V) x 15.5(D) (max.)
Electrical Interface 1 channel LVDS
Support Color 16.2M / 262K colors
Temperature Range
Operating [oC] -10 to +60
Storage (Non-Operating) [oC] -30 to +85
RoHS Compliance RoHS Compliance
G150XG01 V4 rev 0.1
5/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
2.2 Touch Characteristics
o
The following items are characteristics summary on the table under 25 C condition:
Item Unit Specifications
Type of Touch Sensor Charge-Sensing (Capacitive) Type
Panel Size [mm] 323.5(W) x 250.5 (H) x 0.7 (T)
Sensor Active Area [mm] 304.128 (W) x 228.096 (H)
Interface USB
IC Driver ( Sensor) TangoF32
Channel [ch] X:42 Y:31
Surface hardness [H] 7
1 (10mm Cover Lens)
Maximum touch points
2 (3 mm Cover Lens)
Touch Resolution [ppi] 3.44
Touch Active Area [mm] 304.128 (W) x 228.096 (H)
Touch Sensor Pitch [mm] 7.256 (W) X 7.378 (H)
Touch Method [mm] Capacitance sensor
Single/Multi-points Accuracy [mm] +/-1.5mm
Jitter [mm] +/- 4mm
Offset [mm] +/- 1mm
The smallest distance between 2
[mm] 2.2mm
points
60HZ (1 finger)
Sample rate at 10/5/1 point [Hz]
45HZ (2 finger)
Touch sensing height [mm] Up to 10mm
Interface USB
TP Controller 3TangoF32+ATmega32U2
Number of X / Y Channel 42 /31
Resolution X / Y [Dot] 21504 / 15872
1 Finger (10 mm Cover Lens) /
Support Point
2 Finger (3 mm Cover Lens)
Power Consumption [mWatt] 91 (typ.)
Electrical Interface PIXCIR- 500kbps USB Type
OS Support Win7 / WinXP (Figure 1)
o
Operating Temperature Range [ C] -10 to +60
Transparency [%] 90
G150XG01 V4 rev 0.1
6/30
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XG01 V4
Figure 1:
Except Window 7 application, the driver is necessary to be installed before operating. Available drivers are listed as
below.
Driver
OS Kernal USB Remark
Hardware Software
Windows CE 6.0 ARM11 / Cotex-A8 6.0 Note 1
Windows XP X86 SP3 Note 1
Windows Vista X86 Embedded Note 1
Windows 7 start X86 Win 7 start No driver is required
2.6.28 X86/ARM Ubuntu 9.04 Note 1
2.6.31 X86/ARM Ubuntu 9.10 Note 1
Linux
2.6.32 X86/ARM Ubuntu 10.04 Note 1
X86/ARM Fedora Note 1
2.6.29. ATOM-X86 Android 1.6-X86 Support Single Touch
Android 2.6.29. ARM9 Android 2.0/2.1
Note 1
2.6.29. ARM11 Android 2.0/2.1
Note 1:
The default code is used for one point touch with 10 mm (thick) vandal glass.
