Image preview - the first page of the document
![Panel_AUO_G150XTN03-0_1_[DS]](/pics/5c36ac5faff3e.gif)
>> Download Panel_AUO_G150XTN03-0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
(V) Preliminary Specifications
() Final Specifications
Module 15 Inch Color TFT-LCD
Model Name G150XTN03.0
Customer Date Approved by Date
Vito Huang 2012/4/12
Checked &
Prepared by
Approved by
Wennie Lee 2012/4/12__
Note: This Specification is subject to change General Display Business Division /
without notice. AU Optronics corporation
G150XTN03.0rev. 0.0
1/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
Contents
1. Operating Precautions.....................................................................................4
2. General Description .........................................................................................5
2.1 Display Characteristics...........................................................................................................5
2.2 Optical Characteristics ...........................................................................................................6
3. Functional Block Diagram ...............................................................................9
4. Absolute Maximum Ratings ..........................................................................10
4.1 Absolute Ratings of TFT LCD Module .................................................................................10
4.2 Absolute Ratings of Environment ........................................................................................10
5. Electrical Characteristics ..............................................................................11
5.1 TFT LCD Module .................................................................................................................. 11
5.2 Backlight Unit........................................................................................................................13
6. Signal Characteristic .....................................................................................14
6.1 Pixel Format Image ..............................................................................................................14
6.2 Scanning Direction ...............................................................................................................14
6.3 Signal Description ................................................................................................................15
6.4 The Input Data Format .........................................................................................................16
6.5 Interface Timing ....................................................................................................................17
6.6 Power ON/OFF Sequence ...................................................................................................18
7. Connector & Pin Assignment ........................................................................19
7.1 TFT LCD Module: LVDS Connector.....................................................................................19
7.2 LED Backlight Unit: LED Driver Connector .........................................................................20
7.2 LED Backlight Unit: LED Driver Connector .........................................................................21
7.3 LED Driver Connector Pin Assignment ...............................................................................21
8. Reliability Test Criteria ..................................................................................22
9. Mechanical Characteristics ...........................................................................23
9.1 LCM Outline Dimension (Front View) ..................................................................................23
9.2 CM Outline Dimension (Rear View) .....................................................................................24
10. Label and Packaging....................................................................................25
10.1 Shipping Label (on the rear side of TFT-LCD display) ......................................................25
10.2 Carton Package .................................................................................................................25
11 Safety.............................................................................................................26
11.1 Sharp Edge Requirements.................................................................................................26
11.2 Materials .............................................................................................................................26
11.3 Capacitors...........................................................................................................................26
11.4 National Test Lab Requirement..........................................................................................26
G150XTN03.0rev. 0.0
2/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
Record of Revision
Version and Date Page Old description New Description
0.0 2012/5/16 All First Edition
G150XTN03.0rev. 0.0
3/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
1. Operating Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the LED Reflector edge. Instead,
press at the far ends of the CFL Reflector edge softly. Otherwise the TFT Module may
be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor
tilt the Interface Connector of the TFT Module.
11) 11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module
in a very short time. Please design your display product well to avoid external force
applying to module by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module.
The TFT-LCD module should be supplied by power complied with requirements of
Limited Power Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time.
14) Continuous operating TFT-LCD Module under high temperature environment may
accelerate LED light bar exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when TFT-LCD module is placed in
landscape position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to
use screen saver or moving content periodically if fixed pattern is displayed on the
screen.
G150XTN03.0rev. 0.0
4/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
2. General Description
G150XTN03.0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD display, a
driver circuit, and a backlight system. The screen format is intended to support XGA (1024(H) x
768(V)) screen and 16.2M (RGB 8-bits) coloars. All input signals are LVDS interface
compatible. All design rules of this module can correspond to PSWG standard.
G150XTN03.0 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 15
Active Area [mm] 304.128(H) x 228.096(V)
Pixels H x V 1024x3(RGB) x 768
Pixel Pitch [mm] 0.297 x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode TN, Normally White
Nominal Input Voltage VDD [Volt] 3.3 typ.
Typical Power Consumption [Watt] TBD
Weight [Grams] 1200g (max.)
Physical Size [mm] 326.5(H) x 253.5(V) x 12 (D) (max.)
Electrical Interface 1 channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 16.2M colors
Temperature Range
o
Operating [ C] 0 to +65 (+65 oC as panel surface temperature)
o
Storage (Non-Operating) [ C] -20 to +65
RoHS Compliance RoHS Compliance
G150XTN03.0rev. 0.0
5/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
[cd/m2]
White Luminance 200 250 - 1
%
Uniformity 9 Points 75 80 - 1, 2, 3
Contrast Ratio 400 700 - 4
Cross talk %
- 1.2 1.5 5
[msec] Rising 5.7
-
Response Time [msec] Falling - 2.3 6
[msec] Raising + Falling - 8
[degree] Horizontal (Right) 75 85 -
[degree] CR = 10 (Left)
75 85 -
Viewing Angle 7
[degree] Vertical (Upper) 70 80 -
[degree] CR = 10 (Lower)
70 80 -
Red x 0.547 0.597 0.647
Red y 0.289 0.339 0.389
Green x 0.279 0.329 0.379
Color / Chromaticity Green y 0.546 0.596 0.646
Coordinates
(CIE 1931) Blue x 0.104 0.154 0.204
Blue y 0.003 0.053 0.103
White x 0.263 0.313 0.363
White y 0.279 0.329 0.379
Color Gamut % 60 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture
Test Point Center
Environment < 1 lux
LCD Module
SR_3 or
equivalent
Measuring distance
Module Driving Equipment
G150XTN03.0rev. 0.0
6/26
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
G150XTN03.0
Note 2: Definition of 9 points position (Display active area: 304.128(H) x 228.096(V))
90 % 50 % 10 %
10 %
50 %
90 %
Note 3: The luminance uniformity of 9 points is defined by dividing the minimum luminance values by the maximum test
point luminance
Minimum Brightness of nine points
W9 =
Maximum Brightness of nine points
Note 4 Definition of contrast ratio (CR):
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 5 Definition of cross talk (CT)
