Image preview - the first page of the document
![Panel_AUO_G150XVN01-0_0_[DS]](/pics/5c36ac7edfce7.gif)
>> Download Panel_AUO_G150XVN01-0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
(V) Preliminary Specification
() Final Specification
Module 15" XGA TFT-LCD Module
Model Name G150XVN01.0
Checked &
Customer Date Date
Approved by
Vito Huang 03/07/2013
Approved by Prepared by Date
Vivian Huang 03/07/2013
Note: This Specification is subject to change without Audio-Video Display Business Unit /
notice. AU Optronics corporation
document version 0.0 1/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .................................................................................................................. 4
2. General Description ..................................................................................................................... 5
2.1 Display Characteristics ........................................................................................................................ 5
2.2 Optical Characteristics......................................................................................................................... 6
3. Functional Block Diagram........................................................................................................... 9
4. Absolute Maximum Ratings......................................................................................................10
4.1 TFT LCD Module ............................................................................................................................. 10
4.2 Absolute Ratings of Environment ...................................................................................................... 10
5. Electrical characteristics ..........................................................................................................11
5.1 TFT LCD Module ............................................................................................................................. 11
6. Signal Characteristic .................................................................................................................14
6.1 Pixel Format Image ........................................................................................................................... 14
6.2 The Input Data Format ...................................................................................................................... 15
6.3 Signal Description ............................................................................................................................. 16
6.4 Interface Timing................................................................................................................................. 17
6.5 Power ON/OFF Sequence................................................................................................................. 19
7. Connector & Pin Assignment ...................................................................................................20
7.1 Connector .......................................................................................................................................... 20
7.2 Pin Assignmtne.................................................................................................................................. 20
8. Reliability Test ............................................................................................................................21
9. Shipping Label............................................................................................................................22
10. Packing Form............................................................................................................................22
10.1 Packaging material .......................................................................................................................... 23
10.2 Packing instruction .......................................................................................................................... 23
10.3 Palletizing ........................................................................................................................................ 23
11. Outline Drawing........................................................................................................................24
document version 0.0 2/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
Record of Revision
Version & Date Page Old Description New Description Remark
0.0 2013/03/07 All Frist Draft
document version 0.0 3/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on hard
surface.
6) To avoid ESD (Electro Static Discharde) damage, be sure to ground yourself before handling
TFT-LCD Module.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken out from
the container, do not press the center of the LED light bar edge. Instead, press at the far ends
of the LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very short
time. Please design your display product well to avoid external force applying to module by end-user
directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time and lamp ignition
voltage.
14) Continuous operating TFT-LCD display under low temperature environment may accelerate lamp
exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when LCD module is placed in landscape position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use screen
saver or shuffle content periodically if fixed pattern is displayed on the screen.
document version 0.0 4/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
2. General Description
G150XVN01.0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a driver circuit, and a
backlight system. The screen format is intended to support the XGA (1024(H) x 768(V)) screen and 16.2M colors.
All input signal is one channel LVDS interface.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 15.0"
Active Area [mm] 304.128 (H) x 228.096 (V)
Pixels H x V 1024 x 768
Pixel Pitch [mm] 0.297 (per one triad) x 0.297
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode VA, Normally Black
2
White Luminance [cd/m ] 300 (center, Typ)
Contrast Ratio 1500 : 1 (Typ)
Optical ResponseTime [msec] 35 (Typ, on/off)
Nominal Input Voltage VDD [Volt] +3.3
Power Consumption [Watt] TBD (Typ)
Weight [Grams] TBD
Physical Size (H x V x D) [mm] 326.5 (H) x 253.5 (V) x 9.6(D) (Typ)
Electrical Interface one channel LVDS
Surface Treatment Hard-coating (3H), Anti-Glare treatment
Support Color 16.2M / 262K colors
Temperature Range
o -10 to +70
Operating [ C]
o -30 to +70
Storage (Non-Operating) [ C]
RoHS Compliance RoHS Compliance
document version 0.0 5/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) .
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 70 85
-
CR = 10 (Left) 70 85
Viewing Angle [degree] 1
Vertical (Up) 70 85
-
CR = 10 (Down) 70 85
Contrast Ratio Normal Direction 700 1500 -
Raising Time (TrR) - TBD -
Optical Response Time [msec] Falling Time (TrF) - TBD - 2
Rising + Falling - 35 -
Red x TBD TBD TBD
Red y TBD TBD TBD
Green x TBD TBD TBD
Color / Chromaticity Green y TBD TBD TBD
Coordinates
(CIE) Blue x TBD TBD TBD
Blue y TBD TBD TBD
White x 0.250 0.300 0.350
White y 0.275 0.325 0.375
Central Luminance 2
[cd/m ] 240 300 - 3
Luminance Uniformity [%] 5 Points 75 - - 4,5
NTSC % - 72 -
Optical Equipment: BM-5A, BM-7, PR880, or equivalent
document version 0.0 6/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle
Viewing angle is the measurement of contrast ratio 10, or 5, at the screen center, over a 180 horizontal and
180 vertical range (off-normal viewing angles). The 180 viewing angle range is broken down as follows; 90 ( )
horizontal left and right and 90 ( ) vertical, high (up) and low (down). The measurement direction is typically
perpendicular to the display surface with the screen rotated about its center to develop the desired measurement
viewing angle.
Note 2: Definition of response time:
The output signals of photo detector are measured when the input signals are changed from "Full Black" to "Full
White" (rising time), and from "Full White" to "Full Black" (falling time), respectively. The response time is interval
between the 10% and 90% of amplitudes. Please refer to the figure as below.
% Tf F Tr R
100
90
Optical
White Black White
response
10
0
document version 0.0 7/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
Note 3: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature change
during measuring. In order to stabilize the luminance, the measurement should be executed after lighting Backlight
for 30 minutes in a stable, windless and dark room.
Photo detector
Field=1
50 cm
LCD Panel TFT-LCD Module
Center of the screen
Note 4: 5 points position
90 % 50 % 10 %
10 %
50 %
90 %
Note 5:
document version 0.0 8/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
Minimum Luminance in 5 points (1 - 5)
Uniformity =
Maximum Luminance in 5 Points (1 - 5)
3. Functional Block Diagram
The following diagram shows the functional block of the 15.0 inches wide Color TFT-LCD Module:
+12V DC POWER
LED driver
DC/DC Gamma
Converter Correction
LVDS D1 D3072
AU ASIC
G1 Source Driver IC
Gate Driver IC
Connector
Timing
Controller TFT-LCD LED BL
+ 3.3V LVDS 1024(3)*768
Pixels
Mini-LVDS
G768
document version 0.0 9/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
4. Absolute Maximum Ratings
Absolute maximum ratings of the module are as following:
4.1 TFT LCD Module
Item Symbol Min Max Unit Conditions
Logic/LCD Drive Voltage VDD -0.3 +4.0 [Volt] Note 1,2
4.2 Absolute Ratings of Environment
Item Symbol Min. Max. Unit Conditions
o
Operating Temperature TOP -10 +70 [ C] Note 3
Operation Humidity HOP 5 95 [%RH] Note 3
o
Storage Temperature TST -30 +70 [ C]
Storage Humidity HST 5 95 [%RH]
Note 1: With in Ta (25 )
Note 2: Permanent damage to the device may occur if exceeding maximum values
Note 3: Temperature and relative humidity range are shown as the below figure.
1. 95% RH Max ( Ta
2. Max wet-bulb temperature at 39
3. No condensation
Note 4: Function Judged only
document version 0.0 10/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
5. Electrical characteristics
5.1 TFT LCD Module
5.1.1 Power Specification
Input power specifications are as follows:
Symbol Parameter Min Typ Max Unit Conditions
Logic/LCD Drive
VDD 3.0 3.3 3.6 [Volt] +/-10%
Voltage
IDD Input Current - TBD TBD [mA] VDD= 3.3V, All White Pattern At 60Hz,
PDD VDD Power - TBD TBD [Watt] VDD= 3.3V, All White Pattern At 60Hz
IRush Inrush Current - - 2 [A] Note 1
Allowable Logic/LCD
VDDrp - - 500 [mV] p-p VDD= 3.3V, All White Pattern At 60Hz
Drive Ripple Voltage
Note 1: Measurement conditions:
The duration of rising time of power input is 500us.
document version 0.0 11/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
5.1.2 Signal Electrical Characteristics
Input signals shall be low or Hi-Z state when VDD is off.
Each signal characteristics are as follows;
Symbol Parameter Min Typ Max Units Condition
VCM = 1.2V
VTH Differential Input High Threshold - - +100 [mV]
Note 1
VCM = 1.2V
VTL Differential Input Low Threshold -100 - - [mV]
Note 1
VID Input Differential Voltage 100 400 600 [mV] Note 1
VTH-VTL = 200mV (max)
VCM Differential Input Common Mode Voltage +1.1 - +1.45 [V]
Note 1
Note1: LVDS Signal Waveform
document version 0.0 12/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
5.1.3 Backlight unit
Parameter guideline for LED driving is under stable conditions at 25 (Room Temperature):
Symbol Parameter Min. Typ. Max. Unit Remark
VCC Input Voltage 10.8 12 13.2 [Volt]
ICC Input Current - TBD - [A] 100% PWM Duty
PCC Power Consumption TBD TBD TBD [Watt] 100% PWM Duty
FPWM Dimming Frequency 200 - 20K [Hz]
Swing Voltage 3 3.3 5 [Volt]
Dimming duty cycle 5 - 100 %
IF LED Forward Current - 100 - [mA] Ta = 25
- - - [Volt] IF = 100mA, Ta = 0
VF LED Forward Voltage 3.2 3.6 [Volt] IF = 100mA, Ta = 25
- [Volt] IF = 100mA, Ta = 70
PLED LED Power Consumption - 8.64 9.72 [Watt] IF = 100mA, Ta = 25
LED Life Time - 50,000 - Hrs IF= 100mA, Ta= 25
Note 1: Ta means ambient temperature of TFT-LCD module.
Note 2: VCC, ICC, PCC are defined for LED backlight.(100% duty of PWM dimming)
Note 3: IF, VF are defined for one channel LED. There are three LED channel in back light unit.
Note 4: If G150XVN01.0 module is driven by high current or at high ambient temperature & humidity condition. The
operating life will be reduced.
Note 5: Operating life means brightness goes down to 50% initial brightness. Minimum operating life time is estimated data.
Note 6: LED lifetime is definition: brightness is decreased to 50% of the initial value. LED lifetime is restricted under
normal condition, ambient temperature = 25 and LED operating IF = 100mA.
document version 0.0 13/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
6. Signal Characteristic
6.1 Pixel Format Image
Following figure shows the relationship of the input signals and LCD pixel format.
1st 2nd 1023th 1024th
Pixel Pixel Pixel Pixel
st
1
R G B R G B R G B R G B
Line
th
768
R G B R G B R G B R G B
Lin
document version 0.0 14/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
6.2 The Input Data Format
SEL LVDS = "H" for 6 bits LVDS Input
SEL LVDS = "L" or NC for 8 bits LVDS Input
Note1: Please follow PSWG.
Note2: R/G/B data 7:MSB, R/G/B data 0:LSB
document version 0.0 15/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
6.3 Signal Description
The module using one LVDS receiver SN75LVDS82(Texas Instruments). LVDS is a differential signal
technology for LCD interface and high speed data transfer device. LVDS transmitters shall be
SN75LVDS83(negative edge sampling). The first LVDS port(RxOxxx) transmits odd pixels while the
second LVDS port(RxExxx) transmits even pixels.
DF14H-30P-1.25H (HIROSE)
Pin No. Symbol Description
1 GND Ground
2 GND Ground
3 VCC LED BL Power Supply, 12V
4 VCC LED BL Power Supply, 12V
5 GND Ground
6 On/Off LED BL On/Off (3.3-5V:On, 0V:Off)
7 PWM LED BL PWM dimming
8 GND Ground
9 VDD LCD Power Supply, 3.3V
10 VDD LCD Power Supply, 3.3V
11 GND Ground
12 GND Ground
13 Rin0- - LVDS differential data input (R0-R5, G0)
14 Rin0+ + LVDS differential data input (R0-R5, G0)
15 GND Ground
16 Rin1- - LVDS differential data input (G1-G5, B0-B1)
17 Rin1+ + LVDS differential data input (G1-G5, B0-B1)
18 GND Ground
19 Rin2- - LVDS differential data input (B2-B5, HS, VS, DE)
20 Rin2+ + LVDS differential data input (B2-B5, HS, VS, DE)
21 GND Ground
22 ClkIN- - LVDS differential clock input
23 ClkIN+ + LVDS differential clock input
24 GND Ground
25 Rin3- - LVDS differential data input (R6-R7, G6-G7,B6-B7)
26 Rin3+ - LVDS differential data input (R6-R7, G6-G7,B6-B7)
27 GND Ground
28 RL/UD H: 180 degree rotation/ L: Normal mode
29 SEL LVDS L : 8 bit / H : 6bit
30 GND Ground (Note 1)
document version 0.0 16/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
Note1: Start from left side
30 1
document version 0.0 17/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
6.4 Interface Timing
6.4.1 Timing Characteristics
Signal Item Symbol Min Typ Max Unit
Period Tv 776 - 1023 Th
Vertical
Active Tdisp(v) 768 768 768 Th
Section
Blanking Tbp(v)+Tfp(v)+PWvs 8 - 255 Th
Period Th 1064 - 2047 Tclk
Horizontal
Active Tdisp(h) 1024 1024 1024 Tclk
Section
Blanking Tbp(h)+Tfp(h)+PWhs 40 - 1023 Tclk
Clock Frequency Freq. 50 65 81 MHz
Frame Rate Frequency 1/Tv 50 60 75 Hz
Note: DE mode only
Note: Typical value refer to VESA STANDARD
6.4.2 Timing Diagram
document version 0.0 18/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
6.5 Power ON/OFF Sequence
VDD power and lamp on/off sequence are as follows. Interface signals are also shown in the chart. Signals from
any system shall be Hi-Z state or low level when VDD is off.
Value
Parameter Unit
Min. Typ. Max.
T1 0.5 - 10 [ms]
T2 30 40 50 [ms]
T3 220 - - [ms]
T4 0.5 - 10 [ms]
T5 10 - - [ms]
T6 10 - - [ms]
T7 0 - - [ms]
T8 10 - - [ms]
T9 100 - - [ms]
T10 110 - - [ms]
T11 0 16 50 [ms]
T12 - - 10 [ms]
T13 1000 - - [ms]
document version 0.0 19/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
7. Connector & Pin Assignment
Physical interface is described as for the connector on module.These connectors are capable of accommodating
the following signals and will be following components.
7.1 Connector
Connector Name / Designation Interface Connector / Interface card
Manufacturer HIROSE
Type Part Number HRS DF14H-30P-1.25H
Mating Housing Part Number HRS DF14-30S-1.25C
7.2 Pin Assignment
Pin# Signal Name Pin# Signal Name
1 GND 16 Rin1-
2 GND 17 Rin1+
3 VCC 18 GND
4 VCC 19 Rin2-
5 GND 20 Rin2+
6 On/Off 21 GND
7 PWM 22 ClkIN-
8 GND 23 ClkIN+
9 VDD 24 GND
10 VDD 25 Rin3-
11 GND 26 Rin3+
12 GND 27 GND
13 Rin0- 28 RL/UD
14 Rin0+ 29 SEL LVDS
15 GND 30 GND
document version 0.0 20/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G150XVN01.0
AU OPTRONICS CORPORATION
8. Reliability Test
Environment test conditions are listed as following table.
No. Test items Conditions Remark
1 High temperature storage Ta= 70 240Hrs
2 Low temperature storage Ta= -30 240Hrs
3 High temperature operation Tp= 70 240Hrs
4 Low temperature operation Ta= -10 240Hrs
5 High temperature and high humidity Tp= 40 , 95% RH 240Hrs
6 Thermal shock -30 /30min, 70 /30min, 50 cycles
Acceleration: 1.5 G
Wave: Random
7 Vibration
Frequency: 10 - 200 - 10 Hz
Sweep: 30 Minutes each Axis (X, Y, Z)
Acceleration: 50 G
8 Mechanical shock Wave: Half-sine
Active Time: 20 ms
Direction: ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
