Image preview - the first page of the document
![Panel_AUO_G173HW01_V0_1_[DS]](/pics/5c36acc06a9e5.gif)
>> Download Panel_AUO_G173HW01_V0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
() Preliminary Specification
(V) Final Specification
Module 17.3" FHD Color TFT-LCD
Model Name G173HW01 V0
Checked &
Customer Date Date
Approved by
Vito Huang 2011/5/30
Approved by Prepared by
Vivian Huang 2011/5/30
Note: This Specification is subject to change without Audio Video Business Group /
notice. AU Optronics corporation
document version 1.0 1/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .................................................................................................................. 4
2. General Description ..................................................................................................................... 5
2.1 Display Characteristics .......................................................................................................... 5
3. Functional Block Diagram.........................................................................................................10
4. Absolute Maximum Ratings......................................................................................................11
4.1 Absolute Ratings of TFT LCD Module ................................................................................. 11
4.2 Absolute Ratings of Environment ........................................................................................ 11
5. Electrical characteristics ..........................................................................................................12
5.1 TFT LCD Module..................................................................................................................12
5.2 Backlight Unit .......................................................................................................................14
6. Signal Characteristic .................................................................................................................15
6.1 Pixel Format Image ..............................................................................................................15
6.2 The Input Data Format .........................................................................................................16
6.4 Interface Timing....................................................................................................................19
6.5 Power ON/OFF Sequence...................................................................................................20
7. Connector & Pin Assignment ...................................................................................................21
7.1 TFT LCD Module..................................................................................................................21
7.2 Backlight Unit .......................................................................................................................22
8. Reliability Test ............................................................................................................................23
9. Shipping Label............................................................................................................................24
10. Packing Form............................................................................................................................25
10.1 Packaging material ............................................................................................................25
10.2 External packaging material required................................................................................25
10.3 Palletizing sequence..........................................................................................................26
10.4 Packing instruction.............................................................................................................27
11. Outline Drawing........................................................................................................................28
document version 1.0 2/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
Record of Revision
Version & Date Page Old Description New Description
0.0 2011/1/20 All First Edition for Customer
0.1 2011/1/31 12 IDD unit: A IDD unit: mA
14 VCC Max: 12.6V VCC Max: 13.4V
14 Operation Life LED life time
2 2
1.0 2011/5/30 5 White Luminance(cd/m ): 500(Typ.) White Luminance(cd/m ): 400(Typ.)
5 Optical Response Time(ms): 8(Typ.) Optical Response Time(ms): 40(Typ.)
5 Power Consumption(Watt): TBD(Typ.) Power Consumption(Watt): 17(Typ.)
5 Weight(g): TBD(Typ.) Weight(g): 1080(Typ.)
6 Update Viewing Angle
6 Update Optical Response Time
Update Color / Chromaticity
6
Coordinates
6 Update White Luminance
12 IDD (mA): 350(Typ), 600(Max) IDD (mA): 1200(Typ), 1400(Max)
12 PDD (Watt): TBD(Typ), 2(Max) PDD (Watt): 5(Typ), 6(Max)
12 Update the diagram of Vin rising time
14 PVCC (Watt): 11.88(Typ), 13.39(Max) PVCC (Watt): 12(Typ), 15(Max)
14 Update LED Forward Voltage
14 Update Note6 description
25 Update Shipping Label
25 Update Packing Form
28 Update Outline Drawing
document version 1.0 3/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, please be cautious and not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or soft cloth.
5) Since the panel is made of glass, it may be broken or cracked if dropped or bumped on
hard surface.
6) To avoid ESD (Electro Static Discharde) damage, be sure to ground yourself before handling
TFT-LCD Module.
7) Do not open nor modify the module assembly.
8) Do not press the reflector sheet at the back of the module to any direction.
9) In case if a module has to be put back into the packing container slot after it was taken
out from the container, do not press the center of the LED light bar edge. Instead, press
at the far ends of the LED light bar edge softly. Otherwise the TFT Module may be
damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt
the Interface Connector of the TFT Module.
11) TFT-LCD Module is not allowed to be twisted & bent even force is added on module in a very
short time. Please design your display product well to avoid external force applying to module
by end-user directly.
12) Small amount of materials without flammability grade are used in the TFT-LCD module. The
TFT-LCD module should be supplied by power complied with requirements of Limited Power
Source (IEC60950 or UL1950), or be applied exemption.
13) Severe temperature condition may result in different luminance, response time and lamp
ignition voltage.
14) Continuous operating TFT-LCD display under low temperature environment may accelerate
lamp exhaustion and reduce luminance dramatically.
15) The data on this specification sheet is applicable when LCD module is placed in landscape
position.
16) Continuous displaying fixed pattern may induce image sticking. It's recommended to use
screen saver or shuffle content periodically if fixed pattern is displayed on the screen.
document version 1.0 4/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
2. General Description
G173HW01 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a LED driver
circuit, and a LED backlight system. The screen format is intended to support the FHD (1920(H) x 1080(V))
screen and 16.7M colors (RGB 6-bits + HiFRC data). All input signals are LVDS interface compatible.
Inverter card of backlight is not included.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 17.3W (17.25)
Active Area [mm] 381.888 (H) x 214.812 (V)
Pixels H x V 1920(x3) x 1080
Pixel Pitch [mm] 0.1989 (per one triad) x 0.1989
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
2
White Luminance [cd/m ] 400 (Typ.)
Contrast Ratio 600 : 1 (Typ)
Optical ResponseTime [msec] 40 (Typ, on/off)
Nominal Input Voltage VDD [Volt] 3.3 V
Power Consumption [Watt] 17 (Typ)
Weight [Grams] 1080 (Typ)
Physical Size (H x V x D) [mm] 403 (H) x 240 (V) x 12.5 (D) (Typ)
Electrical Interface Dual channel LVDS
Surface Treatment Hard-coating (3H), Glare treatment
Support Color 16.7M colors (RGB 6-bit data + HiFRC data)
Temperature Range
Operating [ ] 0 to +70
Storage (Non-Operating) [ ] -20 to +70
RoHS Compliance RoHS Compliance
document version 1.0 5/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 70 80
-
CR = 10 (Left) 70 80
Viewing Angle [degree] 1
Vertical (Up) 50 60
-
CR = 10 (Down) 70 80
Luminance Uniformity [ ] 13 Points 75 80 - 2, 3
Rising - 37 50
Optical Response Time [msec] Falling - 3 10 4, 5
Rising + Falling - 40 60
Red x 0.590 0.640 0.690
Red y 0.296 0.346 0.396
Green x 0.264 0.314 0.364
Color / Chromaticity Green y 0.574 0.624 0.674
Coordinates 4
(CIE 1931) Blue x 0.100 0.150 0.200
Blue y 0.004 0.054 0.104
White x 0.255 0.305 0.355
White y 0.268 0.318 0.368
White Luminance
[cd/m2 ] 320 400 - 4
(At LED=100mA)
Contrast Ratio 500 600 - 4
NTSC % 72
Optical Equipment: BM-5A, BM-7, PR880, or equivalent
document version 1.0 6/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle
Viewing angle is the measurement of contrast ratio 10, or 5, at the screen center, over a 180 horizontal
and 180 vertical range (off-normal viewing angles). The 180 viewing angle range is broken down as follows;
90 ( ) horizontal left and right and 90 ( ) vertical, high (up) and low (down). The measurement direction is
typically perpendicular to the display surface with the screen rotated about its center to develop the desired
measurement viewing angle.
Note 2: 13 points position
document version 1.0 7/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
Note 3:
Note 4: Measurement method
The LCD module should be stabilized at given temperature for 30 minutes to avoid abrupt temperature
change during measuring. In order to stabilize the luminance, the measurement should be executed after
lighting Backlight for 30 minutes in a stable, windless and dark room.
Photo detector
Field=1
50 cm
LCD Panel TFT-LCD Module
Center of the screen
document version 1.0 8/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
Note 5: Definition of response time:
The output signals of photo detector are measured when the input signals are changed from "Full Black" to
"Full White" (rising time), and from "Full White" to "Full Black" (falling time), respectively. The response time
is interval between the 10% and 90% of amplitudes. Please refer to the figure as below.
% Tr F Tr R
100
90
Optical
White Black White
response
10
0
document version 1.0 9/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
3. Functional Block Diagram
The following diagram shows the functional block of the 17.3 inches Color TFT-LCD Module:
document version 1.0 10/29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G173HW01 V0
AU OPTRONICS CORPORATION
4. Absolute Maximum Ratings
Absolute maximum ratings of the module are as following:
4.1 Absolute Ratings of TFT LCD Module
Item Symbol Min Max Unit
Logic/LCD Drive Voltage Vin -0.3 +3.6 [Volt]
4.2 Absolute Ratings of Environment
Item Symbol Min Max Unit
Operating Temperature TOP 0 +70 [ ]
Operation Humidity HOP 5 95 [%RH]
Storage Temperature TST -20 +70 [ ]
Storage Humidity HST 5 95 [%RH]
