Image preview - the first page of the document

>> Download Panel_AUO_G185XW01_V1_1_[DS] documenatation <<

Text preview - extract from the document

Global LCD Panel Exchange Center www.panelook.com

Product Specification G185XW01 V1
AU OPTRONICS CORPORATION

( V ) Preliminary Specification
( ) Final Specification

Module 18.5" Color TFT-LCD

Model Name G185XW01 V1

Customer Date Approved by Date

Vito Huang 2011/06/13

Approved by Prepared by

Linda Lee 2010/06/13

Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation

document version 0.2 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G185XW01 V1
AU OPTRONICS CORPORATION

Contents

1.0 Handling Precautions .................................................................................... 4
2.0 General Description....................................................................................... 5
2.1 Display Characteristics...........................................................................................................5
2.2 Optical Characteristics ...........................................................................................................6
3.0 Functional Block Diagram........................................................................... 10
4.0 Absolute Maximum Ratings ........................................................................ 11
4.1 TFT LCD Module ..................................................................................................................11
4.2 Absolute Ratings of Environment.........................................................................................11
5.0 Electrical characteristics............................................................................. 12
5.1 TFT LCD Module ................................................................................................................. 12
5.1.1 Power Specification ....................................................................................................................................... 12
5.1.2 Signal Electrical Characteristics ..................................................................................................................... 13
5.2 Backlight Unit....................................................................................................................... 14
6.0 Signal Characteristic ................................................................................... 15
6.1 Pixel Format Image ............................................................................................................. 15
6.2 The input data format .......................................................................................................... 16
6.3 Signal Description ............................................................................................................... 17
6.4 Timing Characteristics ......................................................................................................... 19
6.5 Timing diagram .................................................................................................................... 20
6.6 Power ON/OFF Sequence .................................................................................................. 21
7.0 Connector & Pin Assignment...................................................................... 22
7.1 TFT LCD Module ................................................................................................................. 22
7.2 LED Backlight Unit: LED Driver Connector ........................................................................ 22
7.3 LED Driver Connector Pin Assignment .............................................................................. 23
8.0 Reliability Test ............................................................................................. 24
9.0 Shipping Label ............................................................................................. 25
10.0 Mechanical Characteristics ....................................................................... 26

document version 0.2 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G185XW01 V1
AU OPTRONICS CORPORATION

Record of Revision

Version & Date Page Old description New Description
0.1 2011/05/13 All First Edition for Customer N/A

0.2 2011/06/13 5 Power Consumption: 14.6W (Typ) Power Consumption:15.3W (Typ)

14 Input Voltage: 5V Input Voltage: 12V
Power Consumption: Power Consumption:
14
4.5(Typ), 5.5 (Max). 10.8(Typ), 13.2 (Max).
21 Power ON/OFF Sequence Update

document version 0.2 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G185XW01 V1
AU OPTRONICS CORPORATION

1.0 Handling Precautions

1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after it was taken out from the
container, do not press the center of LED lightbar edge. Instead, press at the far ends of the LED light
bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentarily. While designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module may be
damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.

document version 0.2 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com

Product Specification G185XW01 V1
AU OPTRONICS CORPORATION

2.0 General Description
This specification applies to the 18.5 inch-wide Color a-Si TFT-LCD Module G185XW01 V1.The display
supports the WXGA [1366(H) x 768(V)] screen format and 16.7M colors (RGB 6-bits + Hi-FRC data). All
input signals are LVDS interface comaptible.

2.1 Display Characteristics
The following items are characteristics summary on the table under 25oC condition:

ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 470.1(18.51")
Active Area [mm] 409.8 (H) x 230.4 (V)
Pixels H x V 1366(x3) x 768
Pixel Pitch [um] 300 (per one triad)
