Image preview - the first page of the document
![Panel_AUO_G190EAN01-0_1_[DS]](/pics/5c36acd157166.gif)
>> Download Panel_AUO_G190EAN01-0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
Preliminary Specification
Final Specification
Module 19.0" SXGA Color TFT-LCD
Model Name G190EAN01.0
Checked &
Customer Date Date
Approved by
Vito Huang 5/29, 2012
Approved by Prepared by
Jimmy Tsai 5/29, 2012
Audio-Video Business Unit /
Note: This Specification is subject to
AU Optronics corporation
change without notice.
document version 0.1 1/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
Record of Revision
Version & Date Page Old Description New Description
0.1 2012/05/29 All Frist Edition for Customer
document version 0.1 2/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .................................................................................................................. 4
2. General Description ..................................................................................................................... 5
2.1 Display Characteristics ........................................................................................................................ 5
2.2 Optical Characteristics......................................................................................................................... 6
3. Functional Block Diagram.........................................................................................................10
4. Absolute Maximum Ratings......................................................................................................11
4.1 Absolute Ratings of TFT LCD Module ............................................................................................. 11
4.2 Absolute Ratings of Backlight Unit ................................................................................................... 11
4.3 Absolute Ratings of Environment ...................................................................................................... 11
5. Electrical characteristics ..........................................................................................................13
5.1 TFT LCD Module ............................................................................................................................. 13
5.2 Backlight Unit.................................................................................................................................... 15
6. Signal Characteristic .................................................................................................................16
6.1 Pixel Format Image ........................................................................................................................... 16
6.2 The Input Data Format ...................................................................................................................... 17
6.4 Interface Timing................................................................................................................................. 20
6.5 Power ON/OFF Sequence................................................................................................................. 22
7. Connector & Pin Assignment ...................................................................................................23
7.1 TFT LCD Module ............................................................................................................................. 23
7.2 Backlight Unit.................................................................................................................................... 24
8. Reliability Test ............................................................................................................................25
9. Shipping Label and Packaging.................................................................................................26
9.1 Shipping Label................................................................................................................................... 26
9.2 Packaging .......................................................................................................................................... 26
10. Mechanical Characteristic ......................................................................................................27
document version 0.1 3/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of LED light bar edge. Instead, press at the far ends of
LED light bar edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
document version 0.1 4/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
2. General Description
G190EAN01.0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a driver circuit,
and a backlight system. The screen format is intended to support the SXGA (1280(H) x 1024(V)) screen and
16.7M colors. All input signals are 2-channel LVDS interface compatible.
2.1 Display Characteristics
o
The following items are characteristics summary on the table under 25 C condition:
Items Unit Specifications
Screen Diagonal [mm] 482.6 (19.0" )
Active Area [mm] 376.32 (H) x 301.06 (V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.294 (per one triad) x 0.294
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally Black
2
White Luminance [cd/m ] 300 (center, Typ) @ 80mA
Contrast Ratio 1000 : 1 (Typ)
Optical ResponseTime [msec] TBD (Typ, on/off)
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption [Watt] LED: 17.28 (W) + LVDS: 4.7 (W)
Weight [Grams] 1600 (TYP)
Physical Size (H x V x D) [mm] 396 (H) x 324 (V) x 17.0 (D) (Typ)
Electrical Interface Dual channel LVDS
Surface Treatment Anti-Glare treatment
Support Color 16.7M colors
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
document version 0.1 5/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 75 89
-
CR = 10 (Left) 75 89
Viewing Angle [degree] 1
Vertical (Up) 75 89
-
CR = 10 (Down) 75 89
Luminance Uniformity [%] 9 Points 75 80 - 2, 3
Rising - TBD TBD
Optical Response Time [msec] Falling - TBD TBD 4, 6
Rising + Falling - TBD TBD
Red x TBD TBD TBD
Red y TBD TBD TBD
Green x TBD TBD TBD
Color / Chromaticity Green y TBD TBD TBD
Coordinates 4
(CIE) Blue x TBD TBD TBD
Blue y TBD TBD TBD
White x TBD 0.313 TBD
White y TBD 0.329 TBD
White Luminance 2
(At LED= 80mA) [cd/m ] 240 300 - 4
Contrast Ratio 800 1000 - 4
Cross Talk (At 60Hz) [%] - - 1.5 5
Flicker [dB] - - -20 7
document version 0.1 6/28
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EAN01.0
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle, measured by ELDIM (EZContrast 88)
