Image preview - the first page of the document
![Panel_AUO_G190EG02_V0_2_[DS]](/pics/5c36acffa8a15.gif)
>> Download Panel_AUO_G190EG02_V0_2_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
( ) Preliminary Specification
( V ) Final Specification
Module 19.0" SXGA Color TFT-LCD
Model Name G190EG02 V0
Checked &
Customer Date Date
Approved by
Vito Huang July 1, 2013
Approved by Prepared by
Ginger Lin July 1, 2013
Note: This Specification is subject to Desktop Display Business Group /
change without notice. AU Optronics corporation
document version 1.2 1/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
Record of Revision
Version & Date Page Old Description New Description Remark
0.1 2010/1/19 All First Edition for Customer
0.2 2010/8/05 12 New Block Function Diagram
28 New Drawing (Front)
29 New Drawing (Rear)
0.3 2010/12/10 6 New Physical Size
7,13,16 New LED Current
16 Updated Swing Voltage
22 New Power ON/OFF Sequence
27 New Drawing (Front)
28 New Drawing (Rear)
1.0 2011/040/6 27 New Drawing (Front)
28 New Drawing (Rear)
Dimming Frequency: Dimming Frequency:
Min. Typ. Max. Unit Min. Typ. Max. Unit
1.1 2011/06/20 16
18 20 [kHz] 200 - 20K [Hz]
28 Indicate connector Pin 1
Remove "Thickness 18 mm Max"
1.2 2013/07/01 24 Update 7.1.1 Connector
1.2 2013/07/01 25 Update 7.2 Backlight Connector
1.2 2013/07/01 25 Update 7.2.1 Pin#7 & #9
1.2 2013/07/01 27~29 Add Packing Form
document version 1.2 2/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
Contents
1. Handling Precautions .................................................................................................................. 4
2. General Description ..................................................................................................................... 5
2.1 Display Characteristics ........................................................................................................................ 6
3. Functional Block Diagram.........................................................................................................12
4. Absolute Maximum Ratings......................................................................................................13
4.1 Absolute Ratings of TFT LCD Module ............................................................................................. 13
4.2 Absolute Ratings of Backlight Unit ................................................................................................... 13
4.3 Absolute Ratings of Environment ...................................................................................................... 13
5. Electrical characteristics ..........................................................................................................15
5.1 TFT LCD Module ............................................................................................................................. 15
5.2 Backlight Unit.................................................................................................................................... 16
6. Signal Characteristic .................................................................................................................17
6.1 Pixel Format Image ........................................................................................................................... 17
6.2 The Input Data Format ...................................................................................................................... 18
6.4 Interface Timing................................................................................................................................. 21
6.5 Power ON/OFF Sequence................................................................................................................. 23
7. Connector & Pin Assignment ...................................................................................................24
7.1 TFT LCD Module ............................................................................................................................. 24
7.2 Backlight Unit.................................................................................................................................... 25
8. Reliability Test ............................................................................................................................26
9. Shipping Label............................................................................................................................27
10. Packing Form............................................................................................................................27
11. Mechanical Characteristic ......................................................................................................30
document version 1.2 3/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the LED reflector edge. Instead, press at the far ends
of the LED Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
13) The LCD module is designed so that the LED in it is supplied by Limited Current Circuit (IEC60950 or
UL1950).
document version 1.2 4/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
2. General Description
G190EG02 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT-LCD panel, a driver circuit,
and backlight system. The screen format is intended to support the SXGA (1280(H) x 1024(V)) screen and
16.7M colors 8-bits. All input signals are LVDS interface compatible. G190EG02 V0 is designed for a
general display unit.
document version 1.2 5/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 oC condition:
Items Unit Specifications
Screen Diagonal [mm] 482.6 (19.0" )
Active Area [mm] 376.32 (H) x 301.056 (V)
Pixels H x V 1280(x3) x 1024
Pixel Pitch [mm] 0.294 (per one triad) x 0.294
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally Black
2
White Luminance [cd/m ] 600 (center, Typ)
Contrast Ratio 2000: 1 (Typ)
Optical ResponseTime [msec] 8ms GTG (Avg. Typ.); 20 ms(Typ, on/off)
Nominal Input Voltage VDD [Volt] +5.0 V
Power Consumption [Watt] 55 W (Typ)
Weight [Grams] 2000 (Typ) ; 2100 (Max)
Physical Size (H x V x D) [mm] 396 (H) x 324 (V) x 21.35 (D) (Typ)
Electrical Interface Dual channel LVDS
Surface Treatment Hard-coating (3H), Non-Glare treatment
Support Color 16.7M colors 8-bits
Temperature Range
Operating [oC] 0 to +50
Storage (Non-Operating) [oC] -20 to +60
RoHS Compliance RoHS Compliance
document version 1.2 6/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 oC (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 75 89
-
CR = 10 (Left) 75 89
Viewing Angle [degree] 1
Vertical (Up) 75 89
-
CR = 10 (Down) 75 89
Luminance Uniformity [%] 9 Points 75 80 - 2, 3
Rising 15 25 4,6
Falling 5 15 4,6
Response time [msec]
Rising + Falling 20 40 4,6
Grey to Grey (Avg.) - 8 16 4,6
Red x 0.617 0.647 0.677
Red y 0.31 0.34 0.37
Green x 0.277 0.327 0.377
Color / Chromaticity Green y 0.571 0.601 0.641
Coordinates 4
(CIE 1931) Blue x 0.112 0.142 0.172
Blue y 0.037 0.067 0.099
White x 0.283 0.313 0.34
White y 0.299 0.329 0.359
Black Luminance
(At LED =100mA) [cd/m2 ] 0.3 0.45 4
White Luminance 2
(At LED =100mA) [cd/m ] 450 600 - 4
Contrast Ratio 1000 2000 - 4
Cross Talk (At 75Hz) [%] - - 1.5 5
Flicker [dB] - - -20 7
C.G.L u'v' - - 0.02 8
Optical Equipment: BM-5A, PR880, SR3, CS1000 or equivalent.
document version 1.2 7/31
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190EG02 V0
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle
