Image preview - the first page of the document
![Panel_AUO_G190SF01_V0_1_[DS]](/pics/5c36ad225c36c.gif)
>> Download Panel_AUO_G190SF01_V0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
Preliminary Specification
Final Specification
Module 19" Color TFT-LCD (Free Shape LCD)
Model Name G190SF01 V0
Customer Date Approved by Date
Debbie Chiu 2011/02/24
Checked &
Prepared by
Approved by
Jimmy Tsai 2011/02/24
Note: This Specification is subject to change General Display Business Division / AU
without notice. Optronics corporation
document version 0.2 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
Contents
1. Operating Precautions ......................................................................................4
2. General Description ..........................................................................................5
2.1 Display Characteristics ...................................................................................................... 5
2.2 Optical Characteristics....................................................................................................... 6
3. Functional Block Diagram ................................................................................9
4. Absolute Maximum Ratings............................................................................10
4.1 Absolute Ratings of TFT LCD Module ............................................................................. 10
4.2 Absolute Ratings of Environment .................................................................................... 10
5. Electrical Characteristics................................................................................11
5.1 TFT LCD Module ..............................................................................................................11
5.2 Backlight Unit................................................................................................................... 13
6. Signal Characteristic.......................................................................................14
6.1 Pixel Format Image ......................................................................................................... 14
6.2 Signal Description............................................................................................................ 15
6.3 The Input Data Format .................................................................................................... 16
6.4 Interface Timing ............................................................................................................... 17
6.5 Power ON/OFF Sequence............................................................................................... 18
7. Connector & Pin Assignment .........................................................................19
7.1 TFT LCD Module: LVDS Connector ................................................................................ 19
7.2 Backlight Unit: LED Connector ........................................................................................ 20
8. Reliability Test .................................................................................................21
9. Mechanical Characteristics ............................................................................22
10. Label and Packaging.....................................................................................24
10.1 Shipping Label (on the rear side of TFT-LCD display)................................................... 24
10.2 Carton Package (TBD) .................................................................................................. 24
11. Safety .............................................................................................................25
11.1 Sharp Edge Requirements............................................................................................. 25
11.2 Materials ........................................................................................................................ 25
11.3 Capacitors...................................................................................................................... 25
11.4 National Test Lab Requirement...................................................................................... 25
document version 0.2 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
Record of Revision
Version and
Page Old description New Description Remark
Date
0.1 2011/01/27 All First Edition for Customer All
0.2 2011/02/24 5 Thickness 18.5 mm (max) Thickness 18.0 mm (max)
document version 0.2 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
1. Operating Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when
handling.
7) Do not open or modify the Module Assembly.
8) In case if a Module has to be put back into the packing container slot after once it was taken out from the
container, take it easily, or the TFT Module may be damaged.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
10) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even
momentary. At designing the enclosure, it should be taken into consideration that no bending/twisting forces
are applied to the TFT Module from outside. Otherwise the TFT Module may be damaged.
11) Small amount of materials having no flammability grade is used in the LCD module. The LCD module should
be supplied by power complied with requirements of Limited Power Source (IEC60950 or UL1950), or be
applied exemption.
12) Severe temperature condition may result in different luminance, response time and LED life time.
13) The data on this specification sheet is applicable when LCD module is placed in landscape position.
14) Continuous displaying fixed pattern may induce image sticking. It is recommended to use screen saver or
shuffle content periodically if fixed pattern is displayed on the screen.
document version 0.2 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
2. General Description
This specification applies to the 19 inch-wide Color TFT-LCD Module G190SF01 V0.
The display supports the 1680(H) x 342(V) screen format and 16.7M colors. All input signals are 2 Channels LVDS
interface compatible.
LED driver board is included. G190SF01 V0 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
Items Unit Specifications
Screen Diagonal [inch] 19
Active Area [mm] 473.76 (H) x 96.44(V)
Pixels H x V 1680x3(RGB) x 342
Pixel Pitch [mm] 0.282x 0.282
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode P-MVA Mode,Normally Black
Nominal Input Voltage VDD [Volt] +5.0 V
25 W (Typ)
Typical Power Consumption [Watt]
(All white pattern)
Weight [Grams] 1500 (Typ)
Physical Size [mm] 493.7(W) x 124.8(H) x 18.0(D) (Typ)
Electrical Interface Dual Channel LVDS
Surface Treatment Anti-glare, Hardness 3H
Support Color 16.7M colors (6-bits + HiFRC)
Temperature Range
o
Operating [ C] 0 to +50
o
Storage (Non-Operating) [ C] -20 to +60
RoHS Compliance RoHS Compliance
document version 0.2 5
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature):
Item Unit Conditions Min. Typ. Max. Note
[cd/m2]
White Luminance IF= 80mA 240 300 - 1
%
Uniformity 9 Points 75 80 - 1, 2, 3
Contrast Ratio 1600 2000 - 4
Cross talk %
- - 1.5 5
Rising - 15 -
Falling - 5 - 6
Response Time [msec]
Rising + Falling - 20 -
Gray to Gray - 8 -
[degree] Horizontal (Right) 75 89 -
[degree] CR = 10 (Left)
Viewing Angle 75 89 -
7
[degree] Vertical (Upper) 75 89 -
[degree] CR = 10 (Lower)
75 89 -
Red x TBD
Red y TBD
Green x TBD
Color / Chromaticity Green y TBD
Coordinates
(CIE 1931) Blue x TBD
Blue y TBD
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
Color Gamut % 68 -
Note 1: Measurement method
Equipment Pattern Generator, Power Supply, Digital Voltmeter, Luminance meter (SR_3 or equivalent)
Aperture 1 with 50cm viewing distance
Test Point Center
Environment < 1 lux
SR_3 or
LCD Module equivalent
Measuring distance
document version 0.2 6
Module Driving Equipment
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G190SF01 V0
AU OPTRONICS CORPORATION
Note 2: Definition of 9 points position (Display active area : 473.76(H) x 296.10(V))
90 % 50 % 10 %
10 %
50 %
90 %
Note 3: The luminance uniformity of 9 points is defined by dividing the minimum luminance values by the maximum
test point luminance
Minimum Brightness of nine points
W9 =
Maximum Brightness of nine points
Note 4 Definition of contrast ratio (CR):
Brightness on the "White" state
Contrast ratio (CR)=
Brightness on the "Black" state
Note 5 Definition of cross talk (CT)
