Image preview - the first page of the document
![Panel_AUO_G240HW01_V0_1_[DS]](/pics/5c36ad550e93e.gif)
>> Download Panel_AUO_G240HW01_V0_1_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification G240HW01 V0
AU OPTRONICS CORPORATION
Preliminary Specification
Final Specification
Module 24.0" Color TFT-LCD
Model Name G240HW01 V0
Customer Date Approved by Date
Debbie Chiu 2011/05/12
Checked &
Prepared by
Approved by
Jimmy Tsai 2011/05/12
Note: This Specification is subject to change General Display Business Division / AU
without notice. Optronics corporation
document version 0.3 1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G240HW01 V0
AU OPTRONICS CORPORATION
Contents
1. Operating Precautions..................................................................................... 4
2. General Description......................................................................................... 5
2.1 Display Characteristics .......................................................................................................... 5
2.2 Optical Characteristics ........................................................................................................... 6
3. Functional Block Diagram ............................................................................... 9
4. Absolute Maximum Ratings .......................................................................... 10
4.1 TFT LCD Module..................................................................................................................10
4.2 Backlight Unit .......................................................................................................................10
4.3 Absolute Ratings of Environment ........................................................................................10
5. Electrical Characteristics .............................................................................. 11
5.1 TFT LCD Module.................................................................................................................. 11
5.2 Backlight Unit .......................................................................................................................13
6. Signal Characteristic ..................................................................................... 14
6.1 Pixel Format Image ..............................................................................................................14
6.2 Signal Description ................................................................................................................15
6.3 The Input Data Format .........................................................................................................16
6.4 Interface Timing....................................................................................................................17
6.5 Power ON/OFF Sequence...................................................................................................18
7. Connector & Pin Assignment........................................................................ 19
7.1 TFT LCD Module: LVDS Connector ....................................................................................19
7.2 Backlight Unit: LED Connector ............................................................................................20
8. Reliability Test ............................................................................................... 21
9. Mechanical Characteristics ........................................................................... 22
10. Label and Packaging ................................................................................... 24
10.1 Shipping Label (on the rear side of TFT-LCD display)......................................................24
10.2 Carton Package .................................................................................................................24
11. Safety............................................................................................................ 25
11.1 Sharp Edge Requirements ................................................................................................25
11.2 Materials .............................................................................................................................25
11.3 Capacitors ..........................................................................................................................25
11.4 National Test Lab Requirement .........................................................................................25
document version 0.3 2
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G240HW01 V0
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2011/02/15 All First Edition for Customer All
0.2 2011/03/10 13 Add
0.3 2011/05/11 22 Old drawing Update to new one (adding 3 ribs)
document version 0.3 3
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G240HW01 V0
AU OPTRONICS CORPORATION
1. Operating Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spots.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth when handling.
7) Do not open or modify the Module Assembly.
8) In case if a Module has to be put back into the packing container slot after once it was taken out from the
container, take it easily, or the TFT Module may be damaged.
9) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the Interface
Connector of the TFT Module.
10) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module even momentary.
At designing the enclosure, it should be taken into consideration that no bending/twisting forces are applied to
the TFT Module from outside. Otherwise the TFT Module may be damaged.
11) Small amount of materials having no flammability grade is used in the LCD module. The LCD module should
be supplied by power complied with requirements of Limited Power Source (IEC60950 or UL1950), or be
applied exemption.
12) Severe temperature condition may result in different luminance, response time and LED life time.
13) The data on this specification sheet is applicable when LCD module is placed in landscape position.
14) Continuous displaying fixed pattern may induce image sticking. It is recommended to use screen saver or
shuffle content periodically if fixed pattern is displayed on the screen.
document version 0.3 4
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification G240HW01 V0
AU OPTRONICS CORPORATION
2. General Description
This specification applies to the 24 inch-wide Color TFT-LCD Module G240HW01 V0. The display supports the Full
HD - 1920(H) x 1080(V) screen format and 16.7M colors (RGB 8-bits data). All input signals are dual channel
LVDS interface.
LED driver board is included. G240HW01 V0 is designed for industrial display applications.
2.1 Display Characteristics
The following items are characteristics summary on the table under 25 condition:
ITEMS Unit SPECIFICATIONS
Screen Diagonal [mm] 609.7(24.0")
Active Area [mm] 531.36 (H) x 298.89 (V)
Pixels H x V 1920(x3) x 1080
Pixel Pitch [um] 276.75 (per one triad) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
