Image preview - the first page of the document
![Panel_AUO_M154EW01_V0_0_[DS]](/pics/5c36ad5d559f3.gif)
>> Download Panel_AUO_M154EW01_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
(V ) Preliminary Specifications
( ) Final Specifications
Module 15.4" WXGA Color TFT-LCD
Model Name M154EW01 V0(Glare)
Customer Date Approved by Date
Vincent CH Chen 06/27/2007
Checked &
Prepared by
Approved by
Wilson Tan 06/27/2007
Note: This Specification is subject to change without Desktop Display Business Group /
notice. AU Optronics corporation
document version 0.1 1/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Contents
*HQHUDO 'HVFULSWLRQ
2.1 General Specification.......................................................................................................................... 5
2.2 Optical Characteristics ........................................................................................................................ 6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module............................................................................................. 11
4.2 Absolute Ratings of Backlight Unit .................................................................................................. 11
4.3 Absolute Ratings of Environment ..................................................................................................... 11
(OHFWULFDO FKDUDFWHULVWLFV
5.1 TFT LCD Module ............................................................................................................................. 12
5.2 Backlight Unit ................................................................................................................................... 13
6LJQDO &KDUDFWHULVWLF
6.1 Pixel Format Image........................................................................................................................... 15
6.2 The input data format........................................................................................................................ 16
6.3 Signal Description/Pin Assignment .................................................................................................. 17
6.4 Interface Timing................................................................................................................................ 19
&RQQHFWRU 'HVFULSWLRQ
7.1 TFT LCD Module ............................................................................................................................. 21
7.2 Backlight Unit ................................................................................................................................... 21
7.3 Signal for Lamp connector................................................................................................................ 21
\ 5HOLDELOLW7 HVW
+ 0HFKDQLFDO &KDUDFWHULVWLFV
document version 0.1 2/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2007/06/27 All First Edition for AUO internal
document version 0.1 3/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or
spot.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard
surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human
earth when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was
taken out from the container, do not press the center of the CCFL reflector edge.
Instead, press at the far ends of the CCFL Reflector edge softly. Otherwise the TFT
Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt
the Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT
Module even momentary. At designing the enclosure, it should be taken into
consideration that no bending/twisting forces are applied to the TFT Module from
outside. Otherwise the TFT Module may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD
module should be supplied by power complied with requirements of Limited Power Source
(IEC60950 or UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit
(IEC60950 or UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 0.1 4/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2. General Description
M154EW01 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a
driver circuit, and backlight system. The screen format is intended to support the WXGA (1280(H) x
800(V)) screen and 262k colors (RGB 6-bits data driver). All input signals are LVDS interface
compatible. Inverter of backlight is not included.
2.1 General Specification
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 391 (15.4W")
Active Area [mm] 331.2 X 207.0
Pixels H x V 1280x3(RGB) x 800
Pixel Pitch [mm] 0.2588X0.2588
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
White Luminance (ICCFL=6.5mA) [cd/m2] 200 cd/m2 @ 6.5mA (Typ)
Luminance Uniformity 80% (9 points)
400 typ
Contrast Ratio
240 min.
Optical Rise Time/Fall Time [msec] 6/2 typ.
Nominal Input Voltage VDD [Volt] +3.3 typ.
Power Consumption [Watt] PDD=1.6W, PCFL=9.7W (Max.)
Weight [Grams] 1180 max.
Physical Size [mm] 354.12 x 227.4 x 12.0(max)
Electrical Interface 1 channel LVDS
Glare, Hardness 3H,
Surface Treatment
Reflectance 4.3%
Support Color 262K colors ( RGB 6-bit )
Temperature Range
o
Operating [ C] 0 to +50
o
Storage (Non-Operating) [ C] -20 to +60
RoHS Compliance RoHS Compliance
document version 0.1 5/24
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Unit Conditions Min. Typ. Max. Note
White Luminance
[cd/m2] 160 200 - 4
ICCFL=6.5mA
Horizontal (Right) - 45 -
CR = 10 (Left) - 45 -
Vertical (Upper) - 15 -
CR = 10 (Lower) - 35 -
Viewing Angle [degree] 1
Horizontal (Right) - 60 -
CR = 5 (Left) - 60 -
Vertical (Upper) - 35 -
CR = 5 (Lower) - 55 -
Luminance Uniformity % 9 Points 70% 80% 2,3
CR: Contrast Ratio 240 400 - 4
Cross talk % 4 5
Rising - 6 10
Response Time [msec] Falling - 2 5 4,6
Rising + Falling 8 15
Red x 0.560 0.590 0.620
Red y 0.315 0.345 0.375
Green x 0.285 0.315 0.345
Color / Chromaticity Green y 0.520 0.555 0.585
Coordinates 4
(CIE 1931) Blue x 0.125 0.155 0.185
Blue y 0.125 0.155 0.185
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
Flicker [dB] - -20 7
Note 1. Definition of viewing angle
