Image preview - the first page of the document
![Panel_AUO_M150EW02_V0_0_[DS]](/pics/5c36ad6fbbac3.gif)
>> Download Panel_AUO_M150EW02_V0_0_[DS] documenatation <<
Text preview - extract from the document
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
( V ) Preliminary Specifications
() Final Specifications
Module 15.0" WXGA Color TFT-LCD
Model Name M150EW02 V0
Customer Date Approved by Date
Checked &
Approved by Prepared by
:HL\HQ 7VHQJ 05/20/2008
Note: This Specification is subject to change without
notice. Desktop Display Business Group /
AU Optronics corporation
document version 0.1 1/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
Contents
+DQGOLQJ 3UHFDXWLRQV
*HQHUDO 'HVFULSWLRQ
2.1 Display Characteristics ....................................................................................................................... 5
2.2 Optical Characteristics ........................................................................................................................ 6
)XQFWLRQDO %ORFN 'LDJUDP
$EVROXWH 0D[LPXP 5DWLQJV
4.1 Absolute Ratings of TFT LCD Module............................................................................................. 11
4.2 Absolute Ratings of Backlight Unit .................................................................................................. 11
4.3 Absolute Ratings of Environment ..................................................................................................... 12
(OHFWULFDO FKDUDFWHULVWLFV
5.1 TFT LCD Module ............................................................................................................................. 13
5.2 Backlight Unit ................................................................................................................................... 15
6LJQDO &KDUDFWHULVWLF
6.1 Pixel Format Image........................................................................................................................... 16
6.2 The Input Data Format ...................................................................................................................... 17
6.4 Interface Timing................................................................................................................................ 20
6.5 Power ON/OFF Sequence................................................................................................................. 22
&RQQHFWRU 3LQ $VVLJQPHQW
7.1 TFT LCD Module ............................................................................................................................. 23
\ 5HOLDELOLW7 HVW
/ 6KLSSLQJ 9DEHO
0HFKDQLFDO &KDUDFWHULVWLFV
document version 0.1 2/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
Record of Revision
Version and Date Page Old description New Description Remark
0.1 2008/05/20 All First Edition for Customer N/A
document version 0.1 3/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
1. Handling Precautions
1) Since front polarizer is easily damaged, pay attention not to scratch it.
2) Be sure to turn off power supply when inserting or disconnecting from input connector.
3) Wipe off water drop immediately. Long contact with water may cause discoloration or spot.
4) When the panel surface is soiled, wipe it with absorbent cotton or other soft cloth.
5) Since the panel is made of glass, it may break or crack if dropped or bumped on hard surface.
6) Since CMOS LSI is used in this module, take care of static electricity and insure human earth
when handling.
7) Do not open or modify the Module Assembly.
8) Do not press the reflector sheet at the back of the module to any directions.
9) In case if a Module has to be put back into the packing container slot after once it was taken out
from the container, do not press the center of the CCFL reflector edge. Instead, press at the far
ends of the CCFL Reflector edge softly. Otherwise the TFT Module may be damaged.
10) At the insertion or removal of the Signal Interface Connector, be sure not to rotate nor tilt the
Interface Connector of the TFT Module.
11) After installation of the TFT Module into an enclosure, do not twist nor bend the TFT Module
even momentary. At designing the enclosure, it should be taken into consideration that no
bending/twisting forces are applied to the TFT Module from outside. Otherwise the TFT Module
may be damaged.
12) Cold cathode fluorescent lamp in LCD contains a small amount of mercury. Please follow local
ordinances or regulations for disposal.
13) Small amount of materials having no flammability grade is used in the LCD module. The LCD module
should be supplied by power complied with requirements of Limited Power Source (IEC60950 or
UL1950), or be applied exemption.
14) The LCD module is designed so that the CCFL in it is supplied by Limited Current Circuit (IEC60950 or
UL1950). Do not connect the CCFL in Hazardous Voltage Circuit.
document version 0.1 4/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
2. General Description
M150EW02 V0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a driver circuit,
and backlight system.
The screen format is intended to support the WXGA (1280(H) x 720(V)) screen and 16.7M colors. All input
signals are LVDS interface compatible and this module doesn't contain an inverter board for
backlight.
2.1 Display Characteristics
The following items are characteristics summary on the table at 25 condition:
Items Unit Specifications
Screen Diagonal [mm] 15.0"W
Active Area [mm] 332.16 (W) x 186.84 (H)
Pixels H x V 1280x3(RGB) x 720
Pixel Pitch [um] 259.5X259.5
Pixel Arrangement R.G.B. Vertical Stripe
Display Mode Normally White
2 2
White Luminance (ICCFL=7.5mA) [cd/m ] 250 cd/m @ 7.5mA (Typ)
Contrast Ratio 500 (typ)
Response Time [msec] 8 (Typ, on/off)
Nominal Input Voltage VDD [Volt] +3.3 typ.
12.6W(Typ)
Power Consumption [Watt]
(PDD=2.6W, PCFL=10W@Lamp=7.5mA)
Weight [Grams] 1160(Typ)
Physical Size(H x V x D) [mm] 354.12(W) x 210.4(H) x 12.0(D)(Typ)
Electrical Interface one channel LVDS
Surface Treatment Anti-Glare, Hardness 3H
Support Color 16.7 colors (RGB 6-bit + HiFRC)
RoHS Compliance RoHS Compliance
document version 0.1 5/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
2.2 Optical Characteristics
The optical characteristics are measured under stable conditions at 25 (Room Temperature) :
Item Unit Conditions Min. Typ. Max. Note
Horizontal (Right) 35 45 -
CR = 10 (Left) 35 45 -
Vertical (Up) 10 20 -
CR = 10 (Down) 30 40 -
Viewing Angle [degree] 1
Horizontal (Right) 45 55 -
CR = 5 (Left) 45 55 -
Vertical (Up) 20 30 -
CR = 5 (Down) 40 50 -
Luminance Uniformity [%] 9 Points 70% 80% 2,3
Rising - 6 9
Response Time [msec] Falling - 2 4 4,6
Rising + Falling 8 13
Red x 0.559 0.589 0.619
Red y 0.307 0.337 0.367
Green x 0.282 0.312 0.342
Color / Chromaticity Green y 0.522 0.552 0.582
Coordinates 4
(CIE 1931) Blue x 0.128 0.158 0.188
Blue y 0.115 0.145 0.175
White x 0.283 0.313 0.343
White y 0.299 0.329 0.359
White Luminance 2
[cd/m ] 200 250 - 4
ICCFL=7.5 mA
CR: Contrast Ratio 300 500 - 4
Cross talk [%] 1.2 1.5 5
Flicker [dB] - -20 7
Optical Equipment: BM-5A, BM-7, PR880, or equivalent
document version 0.1 6/27
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
Global LCD Panel Exchange Center www.panelook.com
Product Specification M150EW02 V0
AU OPTRONICS CORPORATION
Note 1: Definition of viewing angle
